Brand: Hikvision
Model No: Hikvision DS-2CD1023G0E-I 2MP Network Bullet Camera
Image Sensor: 2.7 Progressive Scan CMOS
Maximum Resolution: 1920 × 1080
Mininum Illumination: Color: 0.01 Lux (F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100, 000 s
Day And Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Focal Length FOV: 2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2° 4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
Lens Mount: M12
Iris Type: Fixed
Aperture: F2.0
Supplement Light Type: infrared radiation(IR)
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
Simultaneous Live View: Up to 6 channels
API: Open Network Video Interface, ISAPI
Host: Up to 32 users. 3 levels: administrator, operator and user
Client: iVMS-4200, Hik-Connect
Web Browser: Plug-in required live view: IE 10+, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+
Power: 12 VDC ± 25%, 0.4 A, max. 5 W, 5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Language: English
General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Product Dimension: 177.6 mm × 66.2 mm × 67.8 mm
Product Weight: 270 g (0.6 lb)
