Dell Precision 3431 Desktop Workstation
- Processor : 9th generation Intel Core i9, i7, i5, i3, and Pentium
- Intel Xeon E Processors
- Intel Pentium Gold G5420, 2 Core, 4MB Cache, 3.8 Ghz w/UHD Graphics 630
- Intel Core i3 9100, 4 Core, 6MB Cache, 3.6Ghz
- 4.2 Ghz Turbo w/UHD Graphics 630
- Intel Core i5 9500, 6 Core, 9MB Cache, 3.0Ghz
- 4.4 Ghz Turbo w/UHD Graphics 630
- Intel Core i5 9600, 6 Core, 9MB Cache, 3.1Ghz
- 4.6 Ghz Turbo w/UHD Graphics 630
- Intel Core i7 8700 (6 Core, 12MB Cache
- 3.20GHz, 4.6Ghz Turbo w/ HD Graphics 630)
- Intel Core i7 9700, 8 Core, 12MB Cache, 3.0Ghz
- 4.8 Ghz Turbo w/UHD Graphics 630
- Intel Core i9 9900, 8 Core, 16MB Cache, 3.1Ghz
- 4.9 Ghz Turbo w/UHD Graphics 630
- Intel Xeon E 2224, 4 Core, 8MB Cache, 3.4Ghz
- 4.6Ghz Turbo
- Intel Xeon E Processor E 2174G (4 Core HT, 8MB
- Cache, 3.8Ghz, 4.7GHz Turbo)
- Intel Xeon E 2236, 6 Core, 8MB Cache, 3.4Ghz
- 4.8Ghz Turbo
- Intel Xeon E 2246G, 6 Core, 8MB Cache, 3.6Ghz
- 4.8Ghz Turbo w/UHD Graphics 630
- Intel Xeon E 2224G, 4 Core, 8MB Cache, 3.5Ghz
- 4.7Ghz Turbo w/UHD Graphics 630
- Operating System : Windows 10 Professional (64 bit)
- Windows 10 Pro for Workstations (64 bit) w/ Intel Xeon processors
- Windows 10 Home (64 bit)
- Red Hat Enterprise Linux 7.5 (coming soon)
- Red Hat 8.0 (coming soon)
- Ubuntu Linux 16.04
- Ubuntu Linux 18.04
- NeoKylin 6.0 SP3 (China only)
- Chipset : Intel C246 Chipset
- Memory : 4 Dimm Slots; Up to 64GB 2666Mhz Non-ECC & ECC DDR4 Memory
- Graphics : One PCI Express® x16 Gen 3 Graphics card up to 55W
- Entry 3D cards: AMD Radeon Pro WX 4100
- AMD Radeon Pro WX 3100
- AMD Radeon Pro WX 3200 (coming soon)
- AMD Radeon Pro WX 2100
- NVIDIA Quadro P1000
- NVIDIA Quadro P620
- NVIDIA Quadro P400
- Professional 2D cards: Intel HD Graphics 630
- Storage : Support for up to (1) M.2 PCIe SSD on motherboard
- slot and Up to (1) 3.5 SATA or
- (2) 2.5 SATA. Support for
- Intel Ready Mode technology
- Support for up to (1) additional PCIe SSD on
- Dell Precision Ultra-Speed drive (x8) with
- active cooling
- 2.5, 500 GB/1 TB, 7200, SATA, HDD
- 2.5, 500 GB, 7200, SATA, HDD FIPS Self
- Storage : Encrypting Opal 2.0
- 2.5, 2 TB, 5400, SATA, HDD
- 2.5, 256 GB/512 GB/1 TB, SATA 20, SSD
- 2.5, 512 GB/1 TB, SATA, SSD SED
- 3.5, 500 GB/1 TB/2 TB/4 TB/8TB, 7200, SATA, HDD
- 3.5, 4 TB, 5400, SATA, HDD
- M.2 2280, 256 GB/512 GB/1 TB/2 TB PCIe 40, SSD
- M.2 2280, 512 GB/1 TB PCIe 50, SSD
- M.2 2280, 512 PCIe 40, SSD SED (Opal 2.0)
- Storage Controller Integrated: Intel Rapid storage Controller 12.0
- supporting SATA 6Gb/s and host based RAID 0/1
- Communications Integrated: Intel Ethernet Connection I219-LM 10/100/1000
- Optional: Intel 10/100/1000 PCIe Gigabit Networking card
- Aquantia AQtion AQN 108 5/2.5 GbE NIC Adapter
- Optional: Wireless / Bluetooth w/ vPro support
- Audio Controller : Integrated Realtek ALC3234 High Definition Audio Codec (2 Channel)
- Speakers : Internal Speaker; Optional Dell 2.0 stereo speaker
- systems available and Dell sound bar for select flatpanel displays
- Add-in cards : Thunderbolt 3 PCIe Card
- Support for up to (1) additional PCIe SSD on
- Dell Precision Ultra-Speed drive (x8) with
- active cooling
- Serial Port PCIe Card
- Parallel Port PCIe Card
- Smart Card Reader (CAC/PIV)
- Remote Access Host Card, Tera2
- USB Type-C 3.1 Gen 2 PCIe Card
- I/O Ports : Front :
- 2 USB 2.0 Type A
- 1 USB 3.1 Type A (5Gb)
- 1 USB 3.1 Type C (10Gb), data only
- 1 Universal Audio Jack
- 1 Internal SD Card reader (Optional)
- Internal :
- 3 SATA 6Gb/s
- Rear :
- 2 USB 2.0 Type A (with SmartPower)
- 4 USB 3.1 Type A (5Gb)
- 2 PS2
- 2 Display Port
- 1 Optional Port (VGA, HMDI 2.0, DP++ 1.2, Type
- C w/DP-Alt mode)
- 1 RJ45 Network Connector
- 1 Serial
- 1 Audio Line out
- 2 SMA
- Storage devices Optional: 1 optical drive: DVD-ROM; DVD+/-RW, Blu Ray Writer
- (Note: optical drive not available with Smart Card Reader (CAC/PIV))
- SD Card Reader
