Form Factor/Height :

1U rack, Height: 43mm (1.69 inches), Width: 435mm (17.13 inches), Depth: 545mm (21.5 inches)

Processors :

1-socket Intel Xeon E-2200 processors, up to 8 cores at 95W

Memory :

Up to 128GB of 2666MHz TruDDR4 ECC UDIMMs (4 slots)

Expansion Slots :

2x PCIe Gen3 x8 slots or 1x PCIe Gen3 x16 slot

1x PCIe Gen3 x8 (x4 interface) internal RAID slot

Disk Bays :

4x 3.5-inch simple- or hot-swap SATA drives

4x 2.5-inch simple-swap SATA/SAS drives

10x 2.5-inch hot-swap SATA/ SAS/ SSD drives

8 x 2.5-inch hot swap SATA/SAS/SSD drives + 2 x 2.5-inch NVMe drives

RAID Support :

Intel VROC Software RAID supports simple swap and hot swap

Multiple RAID configurations (common with ThinkSystem)

Security and Reliailability Features :

TPM 1.2/2.0; PFA; hot-swap/redundant drives, fans, and PSUs; 45°C continuous operation; light path diagnostic LEDs; front-access diagnostics via dedicated USB port

Network Interface :

2x 1GbE ports embedded, 1x 1GbE dedicated management

Power Supply:

Fixed power supply unit 300W Gold, dual redundant AC (450W, Platinum)

Systems Management :

Lenovo XClarity Administrator with mobile option, support for TPM 2.0

Systems Management :

Lenovo XClarity Administrator with mobile option, support for TPM 2.0

Operating Systems Supported :

Microsoft, Red Hat, SUSE, and VMware ESXi

Limited Warranty :

1-year or 3-year warranty
