NVIDIA GeForce RTX 2070 Super Graphics Card
GPU Engine Specs:
- NVIDIA CUDA Cores:2560
- RTX-OPS:52 T
- Giga Rays/s:7
- Boost Clock (MHz):1770
- Base Clock (MHz):1605
Memory Specs:
- Memory Speed:14 Gbps
- Standard Memory Config:8 GB GDDR6
- Memory Interface Width:256-bit
- Memory Bandwidth (GB/sec):448
Technology Support:
- Ray Tracing Cores: Yes
- Tensor Cores: Yes
- NVIDIA DLSS: Yes
- NVIDIA Adaptive Shading: Yes
- NVIDIA GeForce Experience™: Yes
- NVIDIA Ansel: Yes
- NVIDIA Highlights: Yes
- NVIDIA G-SYNC Compatible: Yes
- NVIDIA GPU Boost™:4
- NVIDIA NVLink™ (SLI-Ready):Yes With NVIDIA RTX NVLink Bridge
- Game Ready Drivers: Yes
- Microsoft DirectX® 12 Raytracing: Yes
- Vulkan RT API, OpenGL 4.6: Yes
- DisplayPort 1.4, HDMI 2.0b: Yes
- HDCP 2.2: Yes
- VR Ready: Yes
- NVIDIA Encoder (NVENC):Yes(Turing)
Display Support:
- Maximum Digital Resolution:7680x4320
- Standard Display Connectors:DisplayPort, HDMI
- Multi Monitor:4
- HDCP:2.2
Graphics Card Dimensions:
- Height:4.556” (115.7mm)
- Length: 10.5” (266.74mm)
- Width:2-Slot
Thermal Power Specs:
- Maximum GPU Temperature (in C):88
- Graphics Card Power (W):215
- Recommended System Power (W):650
- Supplementary Power Connectors:6pin+8pin
1 - 4k 12-bit HDR at 144Hz or 8k 12-bit HDR at 60Hz over one DisplayPort 1.4 connector (with DSC).
2 - DisplayPort 1.4a Ready, DSC 1.2 Ready.
3 - Recommendation is made based on PC configured with an Intel Core i7 3.2 GHz processor. Pre-built system may require less power depending on system configuration.
