NVIDIA Graphics Card
NVIDIA GeForce RTX 2060 Super Graphics Card
GPU Engine Specs:
- NVIDIA CUDA® Cores:2176
- RTX-OPS:41 T
- Giga Rays/s:6
- Boost Clock (MHz):1650
- Base Clock (MHz):1470
Memory Specs:
- Memory Speed:14 Gbps
- Standard Memory Config:8 GB GDDR6
- Memory Interface Width:256-bit
- Memory Bandwidth (GB/sec):448
Technology Support:
- Ray Tracing Cores: Yes
- Tensor Cores: Yes
- NVIDIA DLSS: Yes
- NVIDIA Adaptive Shading:Yes
- NVIDIA® GeForce Experience™: Yes
- NVIDIA Ansel: Yes
- NVIDIA Highlights: Yes
- NVIDIA G-SYNC® Compatible:Yes
- NVIDIA GPU Boost™:4
- NVIDIA NVLink™ (SLI-Ready):Yes
- Game Ready Drivers: Yes
- Microsoft DirectX® 12 Raytracing: Yes
- Vulkan RT API, OpenGL 4.6: Yes
- DisplayPort 1.4, HDMI 2.0b: Yes
- HDCP 2.2: Yes
- VR Ready: Yes
- NVIDIA Encoder (NVENC):Yes(Turing)
Display Support:
- Maximum Digital Resolution:7680x4320
- Standard Display Connectors:DisplayPort, HDMI,DVI-DL
- Multi Monitor:4
- HDCP:2.2
Graphics Card Dimensions:
- Height:4.435” (112.6mm)
- Length: 9.0” (228.60mm)
- Width:2-Slot
Thermal Power Specs:
- Maximum GPU Temperature (in C):89
- Graphics Card Power (W):175
- Recommended System Power (W):550
- Supplementary Power Connectors:8pin
1 - 4k 12-bit HDR at 144Hz or 8k 12-bit HDR at 60Hz over one DisplayPort 1.4 connector (with DSC).
2 - DisplayPort 1.4a Ready, DSC 1.2 Ready.
3 - Recommendation is made based on PC configured with an Intel Core i7 3.2 GHz processor. Pre-built system may require less power depending on system configuration.
NVIDIA GeForce RTX 2080 Super Graphics Card
GPU Engine Specs:
- NVIDIA CUDA Cores:3072
- RTX-OPS:63 T
- Giga Rays/s:8
- Boost Clock (MHz):1815
- Base Clock (MHz):1650
Memory Specs:
- Memory Speed:15.5 Gbps
- Standard Memory Config:8 GB GDDR6
- Memory Interface Width:256-bit
- Memory Bandwidth (GB/sec):496
Technology Support:
- Ray Tracing Cores: Yes
- Tensor Cores: Yes
- NVIDIA DLSS: Yes
- NVIDIA Adaptive Shading:Yes
- NVIDIA GeForce Experience™: Yes
- NVIDIA Ansel: Yes
- NVIDIA Highlights: Yes
- NVIDIA G-SYNC Compatible:Yes
- NVIDIA GPU Boost™:4
- NVIDIA NVLink™ (SLI-Ready):Yes With NVIDIA RTX NVLink Bridge
- Game Ready Drivers: Yes
- Microsoft DirectX® 12 Raytracing: Yes
- Vulkan RT API, OpenGL 4.6: Yes
- DisplayPort 1.4, HDMI 2.0b: Yes
- HDCP 2.2: Yes
- VR Ready: Yes
- NVIDIA Encoder (NVENC):Yes(Turing)
Display Support:
- Maximum Digital Resolution:7680x4320
- Standard Display Connectors: DisplayPort, HDMI
- Multi Monitor:4
- HDCP:2.2
Graphics Card Dimensions:
- Height:4.556” (115.7mm)
- Length: 10.5” (266.74mm)
- Width:2-Slot
Thermal Power Specs:
- Maximum GPU Temperature (in C):89
- Graphics Card Power (W):250
- Recommended System Power (W):650
- Supplementary Power Connectors:6pin+8pin
1 - 4k 12-bit HDR at 144Hz or 8k 12-bit HDR at 60Hz over one DisplayPort 1.4 connector (with DSC).
2 - DisplayPort 1.4a Ready, DSC 1.2 Ready.
3 - Recommendation is made based on PC configured with an Intel Core i7 3.2 GHz processor. Pre-built system may require less power depending on system configuration.
NVIDIA Quadro RTX 8000 Graphics Card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:4608
- Display Connectors:1 X DP to DVI 1 X DP to HDMI
- GPU Memory:48GB DDR6
- Memory Interface:384 Bit
- Memory Bandwidth:672GB/s
- Max Power Consumption:295W
- Warranty:3Years
NVIDIA Quadro RTX 6000 Graphics Card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:4608
- Display Connectors:1 X DP to DVI 1 X DP to HDMI
- GPU Memory:24GB DDR6
- Memory Interface:384 Bit
- Memory Bandwidth:672GB/s
- Max Power Consumption:295W
- Warranty:3Years
NVIDIA Quadro RTX 5000 Graphics Card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:3072
- Display Connectors:1 X DP to DVI 1 X DP to HDMI
- GPU Memory:16GB DDR6
- Memory Interface:256 Bit
- Memory Bandwidth:448GB/s
- Max Power Consumption:265W
- Warranty:3Years
NVIDIA Quadro RTX 4000 Graphics Card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:2304
- Display Connectors:1 X DP to DVI 1 X DP to HDMI 1 X USB C to DP
- GPU Memory:8GB DDR6
- Memory Interface:256 Bit
- Memory Bandwidth:416GB/s
- Max Power Consumption:160W
- Warranty:3Years
NVIDIA Quadro P6000 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:3840
- Display Connectors:3 X DP to DVI
- GPU Memory:24GB DDR5
- Memory Interface:384 Bit
- Memory Bandwidth:432GB/s
- Max Power Consumption:250W
- Warranty:3Years
NVIDIA Quadro P5000 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:2560
- Display Connectors:2 X DP to DVI
- GPU Memory:16GB DDR5
- Memory Interface:256 Bit
- Memory Bandwidth:288GB/s
- Max Power Consumption:180W
- Warranty:3Years
NVIDIA Quadro P4000 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:1792
- Display Connectors:2 X DP to DVI
- GPU Memory:8GB DDR5
- Memory Interface:256 Bit
- Memory Bandwidth:243GB/s
- Max Power Consumption:105W
- Warranty:3Years
NVIDIA Quadro P2000 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:1024
- Display Connectors:1 X DP to DVI
- GPU Memory:5GB DDR5
- Memory Interface:160 Bit
- Memory Bandwidth:140GB/s
- Max Power Consumption:75W
- Warranty:3Years
NVIDIA Quadro P1000 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:640
- Display Connectors:4 X Mini DP to DP
- GPU Memory:4GB DDR5
- Memory Interface:128 Bit
- Memory Bandwidth:82GB/s
- Max Power Consumption:47W
- Warranty:3Years
NVIDIA Quadro P620 Graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:512
- Display Connectors:4 X Mini DP to DP
- GPU Memory:2GB DDR5
- Memory Interface:128 Bit
- Memory Bandwidth:80GB/s
- Max Power Consumption:40W
- Warranty:3Years
NVIDIA Quadro P400 graphics card
- System Interface:PCI Express 3.0 X 16
- CUDA Cores:256
- Display Connectors:3 X Mini DP to DP
- GPU Memory:2GB DDR5
- Memory Interface:64 Bit
- Memory Bandwidth:32GB/s
- Max Power Consumption:30W
- Warranty:3Years
Nvidia Quadro RTX 4000 Graphics Card
- GPU Memory:8 GB GDDR6
- Memory Interface:256-bit
- Memory Bandwidth:Up to 416 GB/s
- NVIDIA CUDA® Cores:2304
- NVIDIA Tensor Cores:288
- NVIDIA RT Cores:36
- Single-Precision
- Performance:7.1 TFLOPS
- Tensor Performance:57.0 TFLOPS
- System Interface:PCI Express 3.0 x16
- Power Consumption:Total board power: 160 W,Total graphics power: 125 W
- Thermal Solution:Active
- Form Factor:4.4inch H x 9.5inch L, Single Slot
- Max Simultaneous Displays:4x 3840x2160 @ 120 Hz,4x 5120x2880 @ 60 Hz,2x 7680x4320 @ 60 Hz
- VR Ready:Yes
- Graphics APIs:Shader Model 5.15,OpenGL 4.66,DirectX 12.05,Vulkan 1.16Compute APIs CUDA, DirectCompute,OpenCLTM
NVIDIA Quadro RTX 5000 Graphics Card
- GPU Memory:16 GB GDDR6
- Memory Interface:256-bit
- Memory Bandwidth:Up to 448 GB/s
- ECC:Yes
- NVIDIA CUDA Cores:3,072
- NVIDIA Tensor Cores:384
- NVIDIA RT Cores:48
- Single-Precision
- Performance:11.2 TFLOPS
- Tensor Performance:89.2 TFLOPS
- NVIDIA NVLink Connects:2 Quadro RTX 5000 GPUs1
- NVIDIA NVLink bandwidth:50 GB/s (bidirectional)
- System Interface:PCI Express 3.0 x 16
- Power Consumption:Total board power: 265 W
- Total graphics power: 230 W
- Thermal Solution:Active
- Form Factor:4.4inch H x 10.5inch L,Dual Slot, Full Height
- Display Connectors 4xDP 1.4, 1x USB-C
- Max Simultaneous Displays:4x 4096x2160 @ 120 Hz,,4x 5120x2880 @ 60 Hz,,2x 7680x4320 @ 60 Hz
- Encode / Decode Engines:1X Encode, 2X Decode
- VR Ready:Yes
- Graphics APIs DirectX 12.07 Shader Model 5.17,OpenGL 4.68,Vulkan 1.18
- Compute APIs:CUDA, DirectCompute,OpenCL™
NVIDIA Quadro RTX 6000 Graphics Card
- GPU Memory:24 GB GDDR6
- Memory Interface:384-bit
- Memory Bandwidth:Up to 672 GB/s
- ECC:Yes
- NVIDIA CUDA Cores:4,608
- NVIDIA Tensor Cores:576
- NVIDIA RT Cores:72
- Single-Precision Performance:16.3 TFLOPS
- Tensor Performance:130.5 TFLOPS
- NVIDIA NVLink:Connects 2 Quadro RTX 6000 GPUs1
- NVIDIA NVLink bandwidth:100 GB/s (bidirectional)
- System Interface:PCI Express 3.0 x 16
- Power Consumption:Total board power: 295 W,Total graphics power: 260 W
- Thermal Solution:Active
- Form Factor:4.4inch H x 10.5inch L,,Dual Slot, Full Height
- Display Connectors:4xDP 1.4, 1x USB-C
- Max Simultaneous Displays:4x 4096x2160 @ 120 Hz,,4x 5120x2880 @ 60 Hz, 2x,7680x4320 @ 60 Hz
- Encode / Decode Engines:1X Encode, 1X Decode
- VR Ready:Yes
- Graphics APIs:DirectX 12.07, Shader Model 5.17, OpenGL 4.68, Vulkan 1.18
NVIDIA Quadro RTX 8000 Graphics Card
- GPU Memory:48 GB GDDR6
- Memory Interface:384-bit
- Memory Bandwidth:672 GB/s
- ECC:Yes
- NVIDIA CUDA Cores:4,608
- NVIDIA Tensor Cores:576
- NVIDIA RT Cores:72
- Single-Precision Performance:16.3 TFLOPS
- Tensor Performance:130.5 TFLOPS
- NVIDIA NVLink Connects:2 Quadro,RTX 8000 GPUs1
- NVIDIA NVLink bandwidth:100 GB/s (bidirectional)
- System Interface:PCI Express 3.0 x 16
- Power Consumption:Total board power: 295 W,Total graphics power: 260 W
- Thermal Solution:Active
- Form Factor:4.4inch H x 10.5inch L,Dual Slot, Full Height
- Display Connectors:4xDP 1.4, VirtualLink (1)
- Max Simultaneous Displays:4x 3840 x 2160 @ 120 Hz,4x 5120x2880 @ 60 Hz,2x 7680x4320 @ 60 Hz
- Encode / Decode Engines:1X Encode, 1X Decode
- VR Ready:Yes
- Graphics APIs:DirectX 12.07, Shader Model 5.17, OpenGL 4.68, Vulkan 1.18
