Access Point
Cisco Catalyst 9115 Access Point
- Three radios: 2.4GHz (4x4), 5GHz (4x4), and BLE, Supports OFDMA and MU-MIMO, Internal and external antenna
- Software: Cisco Unified Wireless Network Software Release 8.9 or later
- Cisco IOS XE Software Release 16.11 or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 4x4 downlink MU-MIMO with four spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- 802.11ax
- 4x4 downlink MU-MIMO with four spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- Integrated antenna: 2.4 GHz, peak gain 3 dBi, internal antenna, omnidirectional in azimuth
- 5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
- External antenna (sold separately)
- Cisco Catalyst 9115AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
- Cisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety of deployment scenarios
- Interfaces: 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz
- Management console port (RJ-45), USB 2.0 (enabled via future software)
- Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting brackets): C9115I: 8.0 x 8.0 x 1.5 in. (20.3 x 20.3 x 3.8 cm), C9115E: 8.0 x 8.0 x 1.7 in. (20.3 x 20.3 x 4.3 cm)
- Weight: Cisco Catalyst 9115AXI, 1.98 lb (0.9 kg)
- Cisco Catalyst 9115AXE, 2.43 lb (1.1 kg)
- System memory: 2048 MB DRAM, 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Cisco Catalyst 9120 Series Access Point
- Four radios: 2.4 GHz (4x4), 5 GHz (4x4), Cisco RF ASIC and BLE/IoT
- Cisco Flexible Radio Assignment and Cisco CleanAir Technology
- Internal and external antenna
- Software
- Cisco Unified Wireless Network Software Release 8.9.x or later
- Cisco IOS XE Software Release 16.11 with AP Device Pack, or later
- Supported wireless LAN controllers
- Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 4x4 downlink MU-MIMO with four spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- 802.11ax
- 4x4 downlink MU-MIMO with four spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- Interfaces: 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
- Management console port (RJ-45), USB 2.0 3.75W (enabled via future software)
- Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7 (21.6 x 21.6 x 4.3 cm), C9120E and C9120P: 8.5 x 8.05x 2.0 (21.6 x 21.6 x 5.1 cm)
- Weight: Cisco Catalyst 9120I, 2.87 lbs (1.3 kg)
- Cisco Catalyst 9120E/P, 3 lbs (1.36 kg)
- System memory: 2048 MB DRAM, 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Cisco Catalyst 9117 Access Point
- Three radios: 2.4GHz (4x4), 5GHz (8x8), and BLE, Supports OFDMA and MU-MIMO, Internal antenna
- Software: Cisco Unified Wireless Network Software Release 8.9 or later
- Cisco IOS XE Software Release 16.11 or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500, 5520, and 8540 Series Wireless Controllers, and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 8x8 MIMO with four spatial streams for 5 GHz band
- 4x4 MIMO with four spatial streams for 2.4 GHz band
- Maximal Ratio Combining (MRC)
- 20- and 40-MHz channels
- PHY data rates up to 600 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 8x8 downlink MU-MIMO with eight spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80, and 160 MHz channels
- PHY data rates up to 3.5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- CSD support
- 160 MHz support only on 4 spatial stream
- 802.11ax
- 8x8 MIMO with eight spatial streams for 5-GHz band
- 4x4 MIMO with four spatial streams for 2.4-GHz band
- Downlink OFDMA
- TWT
- MRC
- 802.11ax beamforming
- 20-, 40-, 80, and 160 MHz channels
- PHY data rates up to 5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- CSD support
- Integrated antenna: 2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
- 5 GHz, peak gain 6 dBi, internal antenna, omnidirectional in azimuth
- Interfaces: 1x 100, 1000, 2500, 5000 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
- Management console port (RJ-45)
- USB 2.0 with up to 4.5W (enabled via future software)
- Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting bracket and mounting features): 8.70 x 8.70 x 1.94 in. (22 x 22 x 4.93 cm)
- Access point (without mounting bracket): 8.70 x 8.70 x 2.19 in. (22 x 22 x 5.56 cm)
- Weight: 3.02 lb (1.4 kg)
- System memory: 2048 MB DRAM, 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Cisco Catalyst 9130 Series Access Point
- Four radios: 2.4 GHz (4x4), 5 GHz (8x8 and 4x4), Cisco RF ASIC, and BLE/IoT
- Cisco Flexible Radio Assignment and Cisco CleanAir Technology
- Internal and external antenna
- WiFi 6 certified
- Software: Catalyst 9130 AXI: Cisco Unified Wireless Network Software Release 8.10.x or later
- Cisco IOS XE Software Release 16.12.1 with AP Device Pack, or later
- Catalyst 9130AXE: Cisco Unified Wireless Network Software Release 8.10MR1 or later
- Cisco IOS XE Software Release 17.1.1 s or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3504, 5520, and 8540 Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g
- 20- and 40 MHz channels
- PHY data rates up to 1.5 Gbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 8x8 downlink MU-MIMO with eight spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 6.9 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
- 802.11ax
- 8x8 uplink/downlink MU-MIMO with eight spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20-, 40-, 80-, and 160-MHz channels
- PHY data rates up to 10 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
- System memory: 2048 MB DRAM, 1024 MB flash
- Interfaces
- 1x 100, 1000, 2500, 5000 Multigigabit Ethernet (RJ-45) – IEEE 802.3az
- Management console port (RJ-45)
- USB 2.0 at 4.5W (enabled via future software)
- Dimensions (W x L x H)
- Access point (without mounting brackets):
- C9130AXI: 8.9 x 8.9 x 1.88 in. (22.6 x 22.6 x 4.8 cm)
- C9130AXE: 9.17 x 9.17 x 1.58 in. (23.3 x 23.3 x 4.0 cm)
- Weight: Cisco Catalyst 9130AXI, 3.2 lb. (1.45 kg)
- Cisco Catalyst 9130AXE, 3.78 lb. (1.71 kg)
- Warranty: Limited lifetime hardware warranty
HP 425 Wireless Access Point
- Part: JG654A
- Device Type: Radio Access Point
- 1x RJ-45 10/100/1000 port
- 1x RJ-45 serial console port
- Radio: 802.11a/n, b/g/n
- Interfaces: 1 x 1000Base-T - RJ-45 ¦ 1 x management - RJ-45 ¦ 4 x aerial
- Form factor: Wall Mountable, Ceiling Mountable
- Model: IEEE 802.11n Wireless
- RAM: 128 MB
- Flash Memory: 128 MB
- PoE supported
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
- Key Features: Quality of Service (QoS), MIMO Technology, Encryption
- Network / Transport Protocol : DHCP
- Limited lifetime warranty
HP 425 Wireless 802.11n Access Point
- Part: JG688A
- Device Type: Radio Access Point
- 1x RJ-45 10/100/1000 port,1x RJ-45 serial console port
- Radio: 802.11a/n, b/g/n
- Interfaces: 1 x 1000Base-T - RJ-45 ¦ 1 x management - RJ-45 ¦ 4 x aerial
- Form factor: Wall Mountable, Ceiling Mountable
- Model: IEEE 802.11n Wireless
- RAM: 128 MB
- Flash Memory: 128 MB
- PoE supported
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
- Key Features: Quality of Service (QoS), MIMO Technology, Encryption
- Network / Transport Protocol : DHCP
- Limited lifetime warranty
HPE MSM430 Dual Radio Access Point
- Part: J9651A
- Device Type: Radio Access Point
- Connectivity: Wireless
- Radio: 802.11a/n+802.11a/b/g/n
- Antenna: (3) 5 dBi 2.4 GHz and (3) 7 dBi 5 GHz omnidirectional antennas
- Interfaces: 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x serial - console - RJ-45
- RAM: 256 MB SDRAM
- Flash Memory: 128 MB
- Form factor: External
- Power Over Ethernet Supported 12.9W
- Key Features: Auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS)
- Intrusion Prevention System (IPS), Wi-Fi Multimedia (WMM) support
- Quality of Service (QoS), Multiple SSID support, IP address filtering
- Limited lifetime warranty
HPE MSM 720 Dual Radio Access Point
- Part: J9693A
- Device Type: Radio Access Point
- Connectivity: Wireless
- Radio: 802.11a/n+802.11a/b/g/n
- Interfaces: 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x serial - console - RJ-45
- RAM: 256 MB SDRAM
- Flash Memory: 128 MB
- Form factor: External
- Power Over Ethernet Supported
- Key Features: Auto-sensing per device , Full duplex mode , Half duplex mode , Manageable , Quality of Service (QoS)
- DLP: IEEE 802.3 , IEEE 802.3ab , IEEE 802.3u
- Limited lifetime warranty
Aruba Instant IAP 103 RW Acces Point
- Part: JW190A
- Device Type: Radio Access Point
- Radio: 802.11a/b/g/n
- Interfaces: 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x management
- Form factor: In-ceiling
- Power Over Ethernet Supported (PoE+)
- Key Features: Auto-uplink (auto MDI/MDI-X), DFS support, Trusted Platform Module (TPM), reset button
- 2T2R MIMO technology, Adaptive Radio Management (ARM), Maximum Ratio Combining (MRC), dual-band 802.11n, Low Density Parity Check (LDPC)
- Direct Sequence Spread Spectrum (DSSS), optimised for Microsoft Lync, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC)
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
- Limited lifetime warranty
ARUBA INSTANT IAP 205 RW ACCESS POINT
- Part: JW212A
- Device Type: Radio Access Point
- Radio: 802.11a/b/g/n/ac, Dual Band
- Form factor: In-ceiling - Indoor
- Power Over Ethernet Supported (PoE+)
- Key Features: Auto-uplink (auto MDI/MDI-X), DFS support, Quality of Service (QoS)
- Trusted Platform Module (TPM), reset button, 2T2R MIMO technology, Adaptive Radio Management (ARM)
- Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD)
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Limited lifetime warranty
Aruba Instant IAP 215 (RW)Acces Point
- Part: JW228A
- Device Type: Radio Access Point
- Radio: 802.11a/b/g/n/ac Dual Band
- Connectivity: Wireless
- Power Over Ethernet Supported (PoE+)
- Key Features: 3T3R MIMO technology , Adaptive Radio Management (ARM)
- Advanced Cellular Coexistence (ACC) , Auto-sensing per device
- Auto-uplink (auto MDI/MDI-X) , Cyclic Delay Diversity (CDD),Transmit Beam-forming (TxBF) ready
- DLP: IEEE 802.11a , IEEE 802.11ac , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n
- Limited lifetime warranty
Aruba Instant IAP 225 (RW)Acces Point
- Part: JW240A
- Device Type: Radio Access Point
- Radio: 802.11a/b/g/n/ac Dual Band
- Connectivity: Wireless
- Interfaces: 2 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x USB 2.0 - Type A
- Form factor: In-ceiling - Indoor
- Power Over Ethernet Supported (PoE+)
- Key Features: 3T3R MIMO technology , Adaptive Radio Management (ARM)
- Advanced Cellular Coexistence (ACC) , Auto-sensing per device
- Auto-uplink (auto MDI/MDI-X) , Cyclic Delay Diversity (CDD),Transmit Beam-forming (TxBF) ready
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Limited lifetime warranty
HP M210 Wireless Access Point
- Part: JL024A
- Ports and Slots : 1 RJ-45 autosensing 10/100/1000 port
- Radios (built-in) : 802.11a/b/g/n
- Antenna : Internal 2.4/5 GHz MIMO omni-directional antennas
- Number of internal antennas : 2
- Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
- Form factor: External - Indoor
- PoE power : 7 W PoE
- DLP: IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n
- Key Features: Standalone, Auto-uplink (auto MDI/MDI-X) , IPv6 support , MIMO technology
- Spanning Tree Protocol (STP) support , Wireless Distribution System (WDS) support, Encryption
- Limited Lifetime Warranty
HP M220 Wireless Access Point
- Part: J9799A
- Device Type: Radio access point
- Form Factor: External
- Frequency Band: 2.4 GHz, 5 GHz
- Interfaces : 1 x 1000Base-T - RJ-45
- Radios (built-in) : 802.11a/b/g/n
- Antenna : Internal
- Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Key Features: Auto-uplink (auto MDI/MDI-X), IPv6 support, Wireless Distribution System (WDS) support
- MIMO technology, Spanning Tree Protocol (STP) support, IPv4 support
- Limited Lifetime Warranty
HP M230 Wireless 802.11ac Access Point
- Part: JL063A
- Device Type: Radio access point
- Form Factor: External
- Dual Radio
- RAM: 256 MB
- Flash Memory: 128 MB
- Frequency Band: 2.4 GHz, 5 GHz
- Interfaces : 1 x 1000Base-T - RJ-45
- Radios (built-in) : 802.11a/b/g/n
- Antenna : Internal
- Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
- DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
- Key Features: Auto-uplink (auto MDI/MDI-X), IPv6 support, Wireless Distribution System (WDS) support
- MIMO technology, Spanning Tree Protocol (STP) support, IPv4 support, Encryption
- Limited Lifetime Warranty
Cisco Industrial Wireless 3700 Series
Industrial outdoor 802.11ac wireless.
- Designed and certified for extreme environments.
- Rail - rolling stock shock and vibration certified.
- Chipset with best-in-class RF architecture.
Software
- Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers:
- 8.0.120.0 or later for the Cisco IW3700 Series Access Point
- Cisco IOS Software Release
- 15.3(3)JA5 or later for the Cisco IW3700 Series Access Point
802.11ac Wave 1 capabilities
- 4 x 4 MIMO with 3 spatial streams
- Maximal-Ratio Combining (MRC)
- 802.11ac beamforming
- 20- 40- and 80-MHz channels
- PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
802.11n version 2.0 (and related) capabilities
- 4 x 4 MIMO with 3 spatial streams
- Maximal-Ratio Combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
Data rates supported
- 802.11a: 6 9 12 18 24 36 48 and 54 Mbps
- 802.11g: 1 2 5.5 6 9 11 12 18 24 36 48 and 54 Mbps
Interfaces
- 10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE In (802.3af) PoE+ In (802.3at)
- 10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE Out (802.3af)
- Management console port (serial with RJ-45 connector)
Indicators
- Status LED indicates boot loader status association status operating status boot loader warnings boot loader errors
System memory
- 512 MB DRAM
- 64 MB flash
Dimensions (W x L x H)
- Access point (not including connectors): 11.3 x 8.0 x 2.3 in (28.7 x 20.3 x 5.9 cm)
- Volume: 148 cubic inches (2.4 liters)
Weight
- 6.7 lb (3.0 kg)
Warranty
- 5-year limited hardware warranty
Cisco 6300 Series Embedded Services Access Points
Embed resilient Cisco WiFi into your hardware.
- Extend intent-based networking to your solutions .
- IOx support for intelligence at the edge.
- Cisco DNA Assurance for worry-free network management.
Radio type
- 2.4 GHz: 802.11b/g/n 2x2 MIMO 2 spatial streams
- 5 GHz: 802.11a/n/ac 2x2 MIMO 2 spatial streams
802.11ac Wave 2 capabilities
- 2x2 MIMO with two spatial streams
- Multi- and single-user MIMO
- Maximal-Ratio Combining (MRC)
- 802.11ac beamforming (transmit beamforming)
- 20- 40- and 80-MHz channels
- PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
802.11n Version 2.0 (and related) capabilities
- 2x2 MIMO with two spatial streams
- Maximal-Ratio Combining (MRC)
- 20- and 40-MHz channels
- PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
Data rates supported
- 2.4-GHz radio:
- 802.11b: 1 2 5.5 11 Mbps
- 802.11g: 6 9 12 18 24 36 48 54 Mbps
- 802.11n data rates:
Interfaces
- x1 10/100/1000BASE-T auto-sensing PoE+ in (802.3at)Cisco Universal Power over Ethernet (UPOE) in
- x2 10/100/1000BASE-T auto-sensing PoE out (802.3af) PoE+ out (802.3at)
- x1 fiber SFP (fiber or electrical)
- Management console port (RJ-45)
- USB 3.0 port
- Multicolor system LED port LED
- DC power input
- Reset button
Uplink options
- Ethernet SFP and wireless mesh
Antennas : Dual band
- PoE output : 35.3 W total
- Maximum 30W per PSE port
USB interface
- USB 2.0 / USB 3.0 supported
Dimensions (H x W x L)
- 8.5 in. x 7.55 in. x 1.9 in.
Weight
- 3.1 lbs.
Warranty
- 1 year
Cisco Catalyst IW6300 Heavy Duty Series Access Points
Designed for Class I Division 2 hazardous locations
- Intelligence with intent-based networking to the IoT Edge and IOx support
- Partner IoT modules for WirelessHART ISA100
- Cisco DNA Assurance for network management
- 802.11ac Wave 1 and 2 capabilities
- 2x2 MIMO with two spatial streams
- Multi- and single-user MIMO
- Maximal-Ratio Combining (MRC)
- 802.11ac beamforming (transmit beamforming)
- 20- 40- and 80-MHz channels
- PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
802.11n Version 2.0 (and related) capabilities
- 2x2 MIMO with two spatial streams
- Maximal-Ratio Combining (MRC)
- 20- and 40-MHz channels
- PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
Data rates supported
- 2.4-GHz radio:
- 802.11b: 1 2 5.5 11 Mbps
- 802.11g: 6 9 12 18 24 36 48 54 Mbps
- 802.11n data rates:
Interfaces
- x1 10/100/1000BASE-T autosensing PoE+ In (802.3at)UPOE in
- x2 10/100/1000BASE-T autosensing PoE Out (802.3af) PoE+ out (802.3at)
- x1 fiber SFP (fiber or electrical)
- Management console port (RJ-45)
- USB3.0 port
- Multicolor system LED port LED
- DC power input (IW-6300H-DC-X-K9 IW-6300H-DCW-X-K9)
- AC power input (IW-6300H-AC-X-K9)
- Reset button
Uplink options
- Ethernet SFP and wireless mesh
Dimensions (W x L x H)
- IW-6300H-DC-X-K9: 9.7" x 11" x 3.8"
- IW-6300H-DCW-X-K9: 9.7" x 11" x 5.6"
- IW-6300H-AC-X-K9: 9.7" x 11" x 5.6"
Weight
- 13.3 lbs (IW-6300H-AC-X-K9), 9.8 lbs (IW-6300H-DC-X-K9),
- 12.7 lbs (IW-6300H-DCW-X-K9)
Warranty
- 1 year
IW 6300 Series
- IW-6300H-DC-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 44-57VDC/POE+/UPOE power input
- IW-6300H-DCW-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 10.8-36VDC/POE+/UPOE power input
- IW-6300H-AC-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 110-220VAC/POE+/UPOE power input
Cisco Business Wireless 150AX Access Point
- Brand : Cisco Systems
- Product Name : Cisco Business 150AX Wi-Fi 6 2x2 Access Point 1 GbE Port - Ceiling Mount
- Product Type : Wireless Access Point
- Network Band : Dual Band
- Frequency Band : 2.40 GHz , 5 GHz
- Antenna Form Factor : Internal
- Wireless LAN Standard : IEEE 802.11ax
- Ethernet Technology : Gigabit Ethernet
- Number of Network (RJ-45) Ports : 1
- PoE (RJ-45) Port : Yes
- Form Factor : Ceiling Mountable , Wall Mountable
- Dynamic VLAN or per port
- Traffic locally switched or tunneled back to Primary AP
- 1 GB DRAM, 256 MB flash
- 1GHz quad core processor
- AC Power Supply with region specific wall plug
TP LINK Deco X60 Wifi System
- Processor : 1 GHz Dual-Core CPU
- Faster Connections : Wi-Fi 6 speeds up to 3,000 Mbps—2,402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
- Connect More Devices : OFDMA and MU-MIMO technology quadruple capacity to enable simultaneous transmission to more devices
- Boosted Seamless Coverage : Achieve seamless whole-home coverage with a clearer and stronger whole-home Wi-Fi signal generated by Wi-Fi 6.
- Ultra-Low Latency : Greater reduction in latency enables more responsive gaming and video chatting.
- One Unified Network : Multiple units form a whole-home network that auto-selects the best connection as you move around your home.
- Total Security : WPA3 encryption and TP-Link HomeShield provide personalized features, including Parental Controls, Antivirus, and Quality of Service (QoS) to ensure a safer online experience.
- TP-Link HomeShield : Keeps your home network safe with cutting-edge features for network and IoT protection.
- Setup Made Easier Than Ever : The Deco app walks you through the setup step-by-step.
- Working Modes : Router Mode , Access Point Mode
Netgear WAC 720 Wireless Access Point
- Brand : Netgear
- Model Name : Netgear WAC 720
- Physical Specifications : Physical Dimensions (W x D x H): 197 x 197 x 40mm (7.76 x 7.76 x 1.57in)
- Weight : 726g (1.6lb)
- Color : White
- Standards : IEEE 802.11ac Wave 1 standard
- Application : WiFi
- Power Supply : POE
- Range : 1200 Mtr.
- LAN Ports : 1
- Business class with superior 802.11ac performance (up to 1.2 Gbps)
- 2 x 2 (Transmit x Receive) with 2 streams of data for 2.4 GHz (300 Mbps) and 5 GHz (867 Mbps) of reliable data delivery 802.11ac beamforming to improve range, minimizes interference while maximizing data rates.
- Internal antennas for maximum RF performance
