Firewall
FortiGate 100F Firewall
FORTIGATE 100F FORTIGATE 101F
Hardware Specifications:
- GE RJ45 Ports : 12
- GE RJ45 Management/HA/DMZ Ports : 1 / 2 / 1
- GE SFP Slots : 4
- 10 GE SFP+ Slots : 2
- GE RJ45 WAN Ports : 2
- GE RJ45 or SFP Shared Ports : 4
- USB Port : 1
- Console Port : 1
- Internal Storage : 1x 480 GB SSD
- Included Transceivers : 0
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 2.6 Gbps
- NGFW Throughput : 1.6 Gbps
- Threat Protection Throughput : 1 Gbps
System Performance:
- Firewall Throughput(1518 / 512 / 64 byte UDP packets) : 20 / 18 / 10 Gbps
- Firewall Latency (64 byte UDP packets) : 5 ?s
- Firewall Throughput (Packets Per Second) : 15 Mpps
- Concurrent Sessions (TCP) : 1.5 Million
- New Sessions/Second (TCP) : 56,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 11.5 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,500
- Client-to-Gateway IPsec VPN Tunnels : 16,000
- SSL-VPN Throughput : 1 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 500
- SSL Inspection Throughput (IPS, avg. HTTPS) : 1 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 1,800
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 135,000
- Application Control Throughput (HTTP 64K) : 2.2 Gbps
- CAPWAP Throughput (HTTP 64K) : 15 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 24
- Maximum Number of FortiAPs(Total / Tunnel Mode) : 128 / 64
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active / Active, Active / Passive, Clustering
Dimensions:
- Height x Width x Length (inches) : 1.73 x 17 x 10
- Height x Width x Length (mm) : 44 x 432 x 254
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Weight : 7.25 lbs (3.29 kg) 7.56 lbs (3.43 kg)
Environment:
- Power Required : 100–240V AC, 50-60
- Maximum Current : 100V / 1A, 240V / 0.5A
- Power Consumption (Average / Maximum) : 35.1 W / 38.7 W 35.3 W / 39.1 W
- Heat Dissipation : 119.77 BTU/h 121.13 BTU/h
- Redundant Power Supplies : Yes
Environment:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Humidity : 10–90% non-condensing
- Noise Level : 40.4 dBA
- Compliance : FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6
FortiGate 200E Firewall
FORTIGATE 200E FORTIGATE 201E
Hardware Specifications:
- GE RJ45 WAN Interfaces : 2
- GE RJ45 Management/HA Ports : 2
- GE RJ45 Ports : 14
- GE SFP Slots : 4
- USB port : 1
- Console (RJ45): 1
- Local Storage : 1x 480 GB SSD
- Included Transceivers : 0
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 2.2 Gbps
- NGFW Throughput : 1.8 Gbps
- Threat Protection Throughput : 1.2 Gbps
System Performance:
- Firewall Throughput(1518 / 512 / 64 byte UDP packets) : 20 / 20 / 9 Gbps
- Firewall Latency (64 byte UDP packets) : 3 ?s
- Firewall Throughput (Packets Per Second) : 13.5 Mpps
- Concurrent Sessions (TCP) : 2 Million
- New Sessions/Second (TCP) : 135,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 7.2 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 10,000
- SSL-VPN Throughput : 900 Mbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 500
- SSL Inspection Throughput (IPS, avg. HTTPS) : 820 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 1,000
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 240,000
- Application Control Throughput (HTTP 64K) : 3.5 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 1.5 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 64
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 256 / 128
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active / Active, Active / Passive, Clustering
Dimensions:
- Height x Width x Length (inches) : 1.75 x 17.0 x 11.9
- Height x Width x Length (mm) : 44.45 x 432 x 301
- Weight : 11.9 lbs (5.4 kg) 12.12 lbs (5.5 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
Environment:
- Power Input :100–240V AC, 50–60 Hz
- Maximum Current : 110 V / 3 A, 220 V / 0.42 A
- Power Consumption (Average / Maximum) : 70.98 / 109.9 W
- Heat Dissipation : 374.9 BTU/h
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 31.1 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6
FortiGate 900D Firewall
Interfaces and Modules :
- Hardware Accelerated : 10 GE SFP+ Slots 2
- Hardware Accelerated GE SFP Slots : 16
- Hardware Accelerated GE RJ45 Ports : 16
- GE RJ45 Management / HA Ports : 2
- USB Ports (Client / Server) : 1 / 2
- Console Port : 1
- Onboard Storage : 1x 256 GB SSD
- Included Transceivers : 0
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 4.2 Gbps
- NGFW Throughput : 4 Gbps
- Threat Protection Throughput : 3 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 52 / 52 / 33 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 86 byte, UDP) : 52 / 52 / 33 Gbps
- Firewall Latency (64 byte, UDP) : 3 ?s
- Firewall Throughput (Packet per Second) : 49.5 Mpps
- Concurrent Sessions (TCP) : 11 Million
- New Sessions/Second (TCP) : 280,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 25 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 3.6 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 10,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 3.9 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 2,400
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 800,000
- Application Control Throughput (HTTP 64K) : 10 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 11 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 64
- Maximum Number of FortiAPs (Total / Tunnel) : 1024 / 512
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
Dimensions and Power:
- Height x Width x Length (inches): 1.75 x 17.22 x 18.24
- Height x Width x Length (mm) : 44.45 x 437.5 x 463.2
- Weight : 20.24 lbs (9.18 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Input : 100–240V AC, 50–60 Hz, 300 W Redundant
- Power Consumption (Average / Maximum): 135 W / 187.2 W
- Current (Maximum): 100V/5A, 240V/3A
- Heat Dissipation:638.75 BTU/h
- Redundant Power Supplies: Yes (Hot Swappable)
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 49.9 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
SonicWall TZ500 Firewall
Performance Overview:
- Security Processor: 4x 1 GHz
- Memory (RAM): 1 GB
- 1 GbE Copper interfaces : 8
- Expansion : USB
- Firewall inspection throughput: 1.4 Gbps
- Full DPI throughput: 400 Mbps
- Application inspection throughput:1.0 Gbps
- IPS throughput : 1.0 Gbps
- Anti-malware inspection throughput : 400 Mbps
- IMIX throughput : 700 Mbps
- SSL Inspection and Decryption (DPI SSL) :150 Mbps
- VPN throughput : 1.0 Gbps
- Connections per second : 8,000
- Maximum connections (SPI) : 125,000
- Maximum connections (DPI) : 100,000
- Single Sign-On (SSO) Users : 500
- VLAN interfaces : 50
- SonicPoints supported (Maximum) : 16
VPN :
- Site-to-Site VPN Tunnels : 25
- IPSec VPN clients (Maximum) : 2 (25)
- SSL VPN licenses (Maximum) : 2 (150)
- Virtual assist bundled (Maximum) : 1 (30-day trial)
- Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14
- Route-based VPN : RIP, OSPF
- Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
- NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
- Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware : McAfee®
- Comprehensive Anti-Spam Service : Supported
- Application Intelligence and Control : Yes
- Application Visualization : Yes
Networking:
- IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
- Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- Local user database : 150
- VoIP : Full H.323v1-5, SIP
- Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : VPNC, IPv6 (Phase 2)
- Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
- Common Access Card (CAC) : Supported
- High Availability : Active/Standby with stateful synchronization
Hardware:
- Form factor : Desktop
- Power Supply (W) : 36W external
- Maximum power consumption (W) : 13.4 / 17.7
- Input power : 100 to 240 VAC, 50-60 Hz, 1 A
- Total heat dissipation : 45.9 / 60.5 BTU
- Dimensions : 3.5x15x22.5cm
- Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
- WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
- Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
- MTBF (Years) : 20 / 12
- Environment : 40-105° F, 0-40° C
- Humidity : 5-95% non-condensing
SonicWall TZ400 Firewall
Performance Overview:
- Security Processor: 4x 800 MHz
- Memory (RAM): 1 GB
- 1 GbE Copper interfaces : 7
- Expansion : USB
- Firewall inspection throughput: 1.3 Gbps
- Full DPI throughput:300Mbps
- Application inspection throughput:900Mbps
- IPS throughput : 900Mbps
- Anti-malware inspection throughput : 300Mbps
- IMIX throughput : 500Mbps
- SSL Inspection and Decryption (DPI SSL) : 100Mbps
- VPN throughput : 900 Mbps
- Connections per second : 6,000
- Maximum connections (SPI) : 100,000
- Maximum connections (DPI) : 90,000
- Single Sign-On (SSO) Users :500
- VLAN interfaces : 50
- SonicPoints supported (Maximum) : 16
VPN :
- Site-to-Site VPN Tunnels : 20
- IPSec VPN clients (Maximum) : 2 (25)
- SSL VPN licenses (Maximum) : 2 (100)
- Virtual assist bundled (Maximum) : 1 (30-day trial)
- Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14
- Route-based VPN : RIP, OSPF
- Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
- NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
- Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware : McAfee®
- Comprehensive Anti-Spam Service : Supported
- Application Intelligence and Control : Yes
- Application Visualization : Yes
Networking:
- IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
- Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- Local user database : 250
- VoIP : Full H.323v1-5, SIP
- Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : VPNC, IPv6 (Phase 2)
- Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
- Common Access Card (CAC) : Supported
- High Availability : Active/Standby
Hardware:
- Form factor : Desktop
- Power Supply (W) : 24W external
- Maximum power consumption (W) : 9.2 / 13.8
- Input power : 100 to 240 VAC, 50-60 Hz, 1 A
- Total heat dissipation : 31.3 / 47.1 BTU
- Dimensions : 3.6x14.1x19cm
- Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
- WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
- Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
- MTBF (Years) : 27 / 13
- Environment : 40-105° F, 0-40° C
- Humidity : 5-95% non-condensing
FortiGate 300E Firewall
FORTIGATE 300E FORTIGATE 301E
Interfaces and Modules:
- GE RJ45 Interfaces : 16
- GE SFP Slots : 16
- GE RJ45 Management Ports : 2
- USB Ports : 2
- RJ45 Console Port : 1
- Local Storage : 2x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 5 Gbps
- NGFW Throughput : 3.5 Gbps
- Threat Protection Throughput : 3 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 20 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 20 Gbps
- Firewall Latency (64 byte, UDP) : 3 ?s
- Firewall Throughput (Packet per Second) : 30 Mpps
- Concurrent Sessions (TCP) : 4 Million
- New Sessions/Second (TCP) : 300,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 2.5 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode):5,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 3.9 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 2,500
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 340,000
- Application Control Throughput (HTTP 64K) : 7 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 5 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 72
- Maximum Number of FortiAPs (Total / Tunnel) : 512 / 256
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
Dimensions and Power:
- Height x Width x Length (inches) : 1.75 x 17.0 x 15.0
- Height x Width x Length (mm) : 44.45 x 432 x 380
- Weight : 16.1 lbs (7.3 kg) 16.6 lbs (7.6 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Consumption (Average / Maximum) : 90 W / 173 W 95 W / 180 W
- Power Input : 100V–240V AC, 50–60Hz
- Current (Maximum) : 6A
- Heat Dissipation : 570 BTU/h 614 BTU/h
- Redundant Power Supplies (Hot Swappable) : optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 48 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
FortiGate 400E Firewall
FORTIGATE 400E FORTIGATE 401E
Interfaces and Modules:
- GE RJ45 Interfaces : 16
- GE SFP Slots : 16
- GE RJ45 Management Ports : 2
- USB Ports : 2
- RJ45 Console Port : 1
- Local Storage : 2x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 7.8 Gbps
- NGFW Throughput : 6 Gbps
- Threat Protection Throughput : 5 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 24 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 24 Gbps
- Firewall Latency (64 byte, UDP) : 3 ?s
- Firewall Throughput (Packet per Second) : 36 Mpps
- Concurrent Sessions (TCP) : 4 Million
- New Sessions/Second (TCP) : 450,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 4.5 Gbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) : 5,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 4.8 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 4,000
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 300,000
- Application Control Throughput (HTTP 64K) : 12 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 14.8 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 72
- Maximum Number of FortiAPs (Total / Tunnel) : 512 / 256
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
FORTIGATE 400E FORTIGATE 401E
Dimensions and Power:
- Height x Width x Length (inches) : 1.75 x 17.0 x 15.0
- Height x Width x Length (mm) : 44.45 x 432 x 380
- Weight : 16.4 lbs (7.4 kg) 16.9 lbs (7.9 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Consumption (Average / Maximum) : 109 W / 214 W 115 W / 221 W
- Power Input : 100–240V, 50–60Hz
- Current (Maximum) : 6A
- Heat Dissipation : 730 BTU/h 754 BTU/h
- Redundant Power Supplies (Hot Swappable) : optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 48 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
FortiGate 500E Firewall
FORTIGATE 500E FORTIGATE 501E
Interfaces and Modules:
- 10 GE SFP+ Slots : 2
- GE RJ45 Interfaces : 8
- GE SFP Slots : 8
- GE RJ45 Management Ports : 2
- USB Ports : 2
- RJ45 Console Port : 1
- Local Storage : 2x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 7.9 Gbps
- NGFW Throughput : 5 Gbps
- Threat Protection Throughput : 4.7 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 36 / 36 / 22 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 36 / 36 / 22 Gbps
- Firewall Latency (64 byte, UDP) : 2 ?s
- Firewall Throughput (Packet per Second) : 33 Mpps
- Concurrent Sessions (TCP) : 8 Million
- New Sessions/Second (TCP) : 300,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 5 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode):10,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 5.7 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 3,500
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 800,000
- Application Control Throughput (HTTP 64K) : 14 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 18 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 72
- Maximum Number of FortiAPs (Total / Tunnel) : 512 / 256
- Maximum Number of FortiTokens : 5,000
- Maximum Number of Registered Endpoints : 2,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
FORTIGATE 500E FORTIGATE 501E
Dimensions and Power :
- Height x Width x Length (inches) : 1.75 x 17.0 x 15.0
- Height x Width x Length (mm) : 44.45 x 432 x 380
- Weight : 16.1 lbs (7.3 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Consumption (Average / Maximum) : 95 W / 193 W 105 W / 200 W
- Power Input : 100–240V, 50–60Hz
- Current (Maximum) : 6A
- Heat Dissipation : 613 BTU/h
- Redundant Power Supplies (Hot Swappable) : optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 43 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
FortiGate 600E Firewall
Interfaces and Modules:
- 10 GE SFP+ Slots : 2
- GE RJ45 Interfaces : 8
- GE SFP Slots : 8
- GE RJ45 Management Ports : 2
- USB Ports : 2
- RJ45 Console Port : 1
- Local Storage : 2x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 10 Gbps
- NGFW Throughput : 9.5 Gbps
- Threat Protection Throughput : 7 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP):36 / 36 / 27 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 64 byte, UDP):36 / 36 / 27 Gbps
- Firewall Latency (64 byte, UDP) : 2 ?s
- Firewall Throughput (Packet per Second) : 40.5 Mpps
- Concurrent Sessions (TCP) : 8 Million
- New Sessions/Second (TCP) : 450,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 7 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) :10,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 8 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 5,500
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 800,000
- Application Control Throughput (HTTP 64K) : 15 Gbps
- CAPWAP Throughput (HTTP 64K) : 18 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 96
- Maximum Number of FortiAPs (Total / Tunnel) : 1,024 / 512
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
Dimensions and Power :
- Height x Width x Length (inches) : 1.75 x 17.0 x 15.0
- Height x Width x Length (mm) : 44.45 x 432 x 380
- Weight : 16.1 lbs (7.3 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Consumption (Average / Maximum) : 129 W / 244 W
- Power Source : 100–240V 50–60Hz
- Current (Maximum) : 6A @ 100V
- Heat Dissipation : 832 BTU/h
- Redundant Power Supplies (Hot Swappable) : optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 59 dBA
- Operating Altitude Up to : 9,843 ft (3,000 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
Fortinet FortiGate 60D Rugged Firewall
- FORTIGATE 60E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45 ) : 1
- Internal Storage : 0
- FORTIGATE 60E-POE
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2
- GE RJ45 Internal Ports : 0
- GE RJ45 PoE/+ Ports : 8
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIWIFI 60E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports :2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 802.11 a/b/g/n/ac
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIGATE 61E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1x 128 GB SSD
- FORTIWIFI 61E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 802.11 a/b/g/n/ac
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1x 128 GB SSD
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 400 Mbps
- NGFW Throughput : 250 Mbps
- Threat Protection Throughput : 200 Mbps
- System Performance:
- Firewall Throughput (1518 / 512 / 64 byte UDP packets) : 3 / 3 / 3 Gbps
- Firewall Latency (64 byte UDP packets) : 3 ?s
- Firewall Throughput (Packets Per Second) : 4.5 Mpps
- Concurrent Sessions (TCP) : 1.3 Million
- New Sessions/Second (TCP) : 30,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 2 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 500
- SSL-VPN Throughput : 150 Mbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput (IPS, avg. HTTPS) : 135 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 135
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 75,000
- Application Control Throughput (HTTP 64K) : 650 Mbps
- CAPWAP Throughput (HTTP 64K) : 890 Mbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 16
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 30 / 10
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active / Active, Active / Passive, Clustering
- Dimensions
- Height x Width x Length (inches) 1.5 x 8.5 x 6.3
- Height x Width x Length (mm) 38 x 216 x 160
- Weight 1.9 lbs (0.9 kg)
- Form Factor : Desktop
Fortinet FortiGate 50E Next Generation Firewall
- Hardware Specifications
- GE RJ45 Switch Ports : 5
- GE RJ45 WAN Ports : 2
- USB Ports : 1
- Console (RJ45) : 1
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 350 Mbps
- NGFW Throughput : 220 Mbps
- Threat Protection Throughput : 160 Mbps
- System Performance :
- Firewall Throughput : 2.5 Gbps
- Firewall Latency (64 byte UDP packets) : 180 ?s
- Firewall Throughput (Packets Per Second): 375 Kpps
- Concurrent Sessions (TCP) : 1.8 Million
- New Sessions/Second (TCP) : 21,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 90 Mbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 250
- SSL-VPN Throughput : 100 Mbps
- Concurrent SS-VPN Users (Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput (IPS, avg. HTTPS) : 150 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 140
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 75,000
- Application CoLntrol Throughput (HTTP 64K) : 450 Mbps
- CAPWAP Throughput (HTTP 64K) : 1.2 Gbps
- Virtual Domains (Default / Maximum) : 5 / 5
- Maximum Number of FortiSwitches Supported : 8
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 10 / 5
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active/Active, Active/Passive, Clustering
- Dimensions :
- Height x Width x Length (inches) : 1.44 x 8.52 x 5.5
- Height x Width x Length (mm) : 36.5 x 216 x 140
- Weight : 2.015 lbs(0.914 kg)
- Form Factor : Desktop
Fortinet FortiGate 60F Next Generation Firewall
- FORTIGATE 60F
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIGATE 61F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1 x 128 GB SSD
- FORTIWIFI 60F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports 7
- GE RJ45 FortiLink Ports 2
- Wireless Interface : 802.11 a/b/g/n/ac-W2
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIWIFI 61F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 802.11 a/b/g/n/ac-W2
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1 x 128 GB SSD
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 1.4 Gbps
- NGFW Throughput : 1 Gbps
- Threat Protection Throughput : 700 Mbps
- System Performance :
- Firewall Throughput(1518 / 512 / 64 byte UDP packets) : 10/10/6 Gbps
- Firewall Latency (64 byte UDP packets) : 4 ?s
- Firewall Throughput (Packets Per Second) : 9 Mpps
- Concurrent Sessions (TCP) : 700,000
- New Sessions/Second (TCP) : 35,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 6.5 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 500
- SSL-VPN Thro 9ughput :00 Mbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput(IPS, avg. HTTPS) : 750 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 400
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 55,000
- Application Control Throughput (HTTP 64K) : 1.8 Gbps
- CAPWAP Throughput (HTTP 64K) : 8 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 16
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 30 / 10
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active / Active, Active / Passive, Clustering
- Dimensions :
- Height x Width x Length (inches) : 1.5 x 8.5 x 6.3
- Height x Width x Length (mm) : 38.5 x 216 x 160 mm
- Weight : 2.23 lbs (1.01 kg)
- Form Factor : Desktop
SonicWall NSA 2600 Series
Firewall general :
- Operating system : SonicOS 6.5.1
- Security processing cores : 4
- Interfaces :
- 8 x 1-GbE,
- 1 GbE Management,
- 1 Console
- Expansion:1 Expansion Slot (Rear)*, SD Card*
- Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
- SSO users : 30,000
- Maximum access points supported : 32
- Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
- Firewall inspection throughput : 1.9 Gbps
- Full DPI throughput : 300 Mbps
- Application inspection throughput : 700 Mbps
- IPS throughput : 700 Mbps
- Anti-malware inspection throughput : 400 Mbps
- IMIX throughput : 600 Mbps
- TLS/SSL decryption and inspection (DPI SSL) : 200 Mbps
- VPN throughput : 1.1 Gbps
- Connections per second : 15,000/sec
- Maximum connections (SPI) : 500,000
- Maximum connections (DPI) : 250,000
- Default/Maximum connections (DPI SSL) : 1,000/1,000
VPN :
- Site-to-site VPN tunnels : 250
- IPSec VPN clients (max) : 10 (250)
- SSL VPN NetExtender clients (max) : 2 (250)
- Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN : RIP, OSPF, BGP
Networking :
- IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
- NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
- VLAN interfaces : 256
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
- VoIP : Full H323-v1-5, SIP
- Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
- High availability : Active/Passive with State Sync
Hardware :
- Power supply : Single, Fixed 200W
- Fans : Dual, Fixed
- Input power : 100-240 VAC, 60-50 Hz
- Maximum power consumption (W) : 49.4
- MTBF @25ºC in hours : 176,540
- MTBF @25ºC in years : 20.15
- Form factor : 1U Rack Mountable
- Dimensions : 1.75 x 10.25 x 17 in(4.5 x 26 x 43 cm)
- Weight : 10.1 lb (4.6 kg)
- WEEE weight : 11.0 lb (5.0 kg)
- Shipping weight : 14.3 lb (6.5 kg)
- Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
- Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
- Humidity : 10-90% non-condensing
SonicWall NSA 3600 Series
Firewall general :
- Operating system : SonicOS 6.5.1
- Security processing cores : 6
- Interfaces :
- 2 x 10-GbE SFP+,
- 4 x 1-GbE SFP,
- 12 x 1-GbE,
- 1 GbE Management,
- 1 Console
- Expansion:1 Expansion Slot (Rear)*, SD Card*
- Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
- SSO users : 40,000
- Maximum access points supported : 48
- Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
- Firewall inspection throughput : 3.4 Gbps
- Full DPI throughput : 500 Mbps
- Application inspection throughput : 1.1 Gbps
- IPS throughput : 1.1 Gbps
- Anti-malware inspection throughput : 600 Mbps
- IMIX throughput : 900 Mbps
- TLS/SSL decryption and inspection (DPI SSL) : 300 Mbps
- VPN throughput : 1.5 Gbps
- Connections per second : 20,000/sec
- Maximum connections (SPI) : 750,000
- Maximum connections (DPI) : 375,000
- Default/Maximum connections (DPI SSL) : 2,000/2,750
VPN :
- Site-to-site VPN tunnels : 1,000
- IPSec VPN clients (max) : 50 (1,000)
- SSL VPN NetExtender clients (max) : 2 (350)
- Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN : RIP, OSPF, BGP
Networking :
- IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
- NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
- VLAN interfaces : 256
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
- VoIP : Full H323-v1-5, SIP
- Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
- High availability : Active/Passive with State Sync, Active/Active Clustering
Hardware :
- Power supply : Single, Fixed 250W
- Fans : Dual, Fixed
- Input power : 100-240 VAC, 60-50 Hz
- Maximum power consumption (W) : 74.3
- MTBF @25ºC in hours : 146,789
- MTBF @25ºC in years : 16.76
- Form factor : 1U Rack Mountable
- Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
- Weight : 13.56 lb (6.15 kg)
- WEEE weight : 14.24 lb (6.46 kg)
- Shipping weight : 20.79lb (9.43 kg)
- Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
- Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
- Humidity : 10-90% non-condensing
SonicWall NSA 4600 Series
Firewall general :
- Operating system : SonicOS 6.5.1
- Security processing cores : 8
- Interfaces :
- 2 x 10-GbE SFP+,
- 4 x 1-GbE SFP,
- 12 x 1-GbE,
- 1 GbE Management,
- 1 Console
- Expansion:1 Expansion Slot (Rear)*, SD Card*
- Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
- SSO users : 50,000
- Maximum access points supported : 64
- Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
- Firewall inspection throughput : 6.0 Gbps
- Full DPI throughput : 800 Mbps
- Application inspection throughput : 2.0 Gbps
- IPS throughput : 2.0 Gbps
- Anti-malware inspection throughput : 1.1 Gbps
- IMIX throughput : 1.6 Gbps
- TLS/SSL decryption and inspection (DPI SSL) : 500 Mbps
- VPN throughput : 3.0 Gbps
- Connections per second : 40,000/sec
- Maximum connections (SPI) : 1,000,000
- Maximum connections (DPI) : 500,000
- Default/Maximum connections (DPI SSL) : 3,000/4,500
VPN :
- Site-to-site VPN tunnels : 3,000
- IPSec VPN clients (max) : 500 (3,000)
- SSL VPN NetExtender clients (max) : 2 (500)
- Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN : RIP, OSPF, BGP
Networking :
- IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
- NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
- VLAN interfaces : 256
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
- VoIP : Full H323-v1-5, SIP
- Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
- High availability : Active/Passive with State Sync, Active/Active Clustering
Hardware :
- Power supply : Single, Fixed 250W
- Fans : Dual, Fixed
- Input power : 100-240 VAC, 60-50 Hz
- Maximum power consumption (W) : 86.7
- MTBF @25ºC in hours : 139,783
- MTBF @25ºC in years : 15.96
- Form factor : 1U Rack Mountable
- Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
- Weight : 13.56 lb (6.15 kg)
- WEEE weight : 14.24 lb (6.46 kg)
- Shipping weight : 20.79lb (9.43 kg)
- Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
- Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
- Humidity : 10-90% non-condensing
SonicWall NSA 5600 Series
Firewall general :
- Operating system : SonicOS 6.5.1
- Security processing cores : 10
- Interfaces :
- 2 x 10-GbE SFP+,
- 4 x 1-GbE SFP,
- 12 x 1-GbE,
- 1 GbE Management,
- 1 Console
- Expansion:1 Expansion Slot (Rear)*, SD Card*
- Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
- SSO users : 60,000
- Maximum access points supported : 96
- Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
- Firewall inspection throughput : 9.0 Gbps
- Full DPI throughput : 1.6 Gbps
- Application inspection throughput : 3.0 Gbps
- IPS throughput : 3.0 Gbps
- Anti-malware inspection throughput : 1.7 Gbps
- IMIX throughput : 2.4 Gbps
- TLS/SSL decryption and inspection (DPI SSL) : 800 Mbps
- VPN throughput : 4.5 Gbps
- Connections per second : 60,000/sec
- Maximum connections (SPI) : 1,500,000
- Maximum connections (DPI) : 1,000,000
- Default/Maximum connections (DPI SSL) : 4,000/8,500
VPN :
- Site-to-site VPN tunnels : 4,000
- IPSec VPN clients (max) : 2,000 (4,000)
- SSL VPN NetExtender clients (max) : 2 (1,000)
- Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN : RIP, OSPF, BGP
Networking :
- IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
- NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
- VLAN interfaces : 400
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
- VoIP : Full H323-v1-5, SIP
- Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
- High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering
Hardware :
- Power supply : Single, Fixed 250W
- Fans : Dual, Fixed
- Input power : 100-240 VAC, 60-50 Hz
- Maximum power consumption (W) : 90.9
- MTBF @25ºC in hours : 134,900
- MTBF @25ºC in years : 15.40
- Form factor : 1U Rack Mountable
- Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
- Weight : 13.56 lb (6.15 kg)
- WEEE weight : 14.24 lb (6.46 kg)
- Shipping weight : 20.79lb (9.43 kg)
- Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
- Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
- Humidity : 10-90% non-condensing
SonicWall NSA 6600 Series
Firewall general :
- Operating system : SonicOS 6.5.1
- Security processing cores : 24
- Interfaces :
- 4 x 10-GbE SFP+,
- 8 x 1-GbE SFP,
- 8 x 1-GbE,
- 1 GbE Management,
- 1 Console
- Expansion:1 Expansion Slot (Rear)*, SD Card*
- Management :CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
- SSO users:70,000
- Maximum access points supported : 128
- Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
- Firewall inspection throughput : 12.0 Gbps
- Full DPI throughput : 3.0 Gbps
- Application inspection throughput : 4.5 Gbps
- IPS throughput : 4.5 Gbps
- Anti-malware inspection throughput : 3.0 Gbps
- IMIX throughput : 3.5 Gbps
- TLS/SSL decryption and inspection (DPI SSL) : 1.3 Gbps
- VPN throughput : 5.0 Gbps
- Connections per second : 90,000/sec
- Maximum connections (SPI) : 1,500,000
- Maximum connections (DPI) : 1,000,000
- Default/Maximum connections (DPI SSL) : 6,000/10,500
VPN :
- Site-to-site VPN tunnels : 6,000
- IPSec VPN clients (max) : 2,000 (6,000)
- SSL VPN NetExtender clients (max) : 2 (1,500)
- Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN : RIP, OSPF, BGP
Networking :
- IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
- NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
- VLAN interfaces : 256
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
- VoIP : Full H323-v1-5, SIP
- Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
- High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering
Hardware :
- Power supply : Single, Fixed 250W
- Fans : Dual, redundant, hot swappable
- Input power : 100-240 VAC, 60-50 Hz
- Maximum power consumption (W) : 113.1
- MTBF @25ºC in hours : 116,477
- MTBF @25ºC in years : 13.30
- Form factor : 1U Rack Mountable
- Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
- Weight : 14.93 lb (6.77 kg)
- WEEE weight : 19.78 lb (8.97 kg)
- Shipping weight : 26.12 lb (11.85 kg)
- Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
- Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
- Humidity : 10-90% non-condensing
SonicWall TZ300 Firewall
Performance Overview:
- Operating system : SonicOS 6.2.x
- Security Processor: 2x 800 MHz
- Memory (RAM): 1 GB
- 1 GbE Copper interfaces : 5
- Expansion : USB
- Firewall inspection throughput: 750 Mbps
- Full DPI throughput:100 Mbps
- Application inspection throughput:300 Mbps
- IPS throughput : 300 Mbps
- Anti-malware inspection throughput : 100 Mbps
- IMIX throughput : 200 Mbps
- SSL Inspection and Decryption (DPI SSL) :45 Mbps
- VPN throughput : 300 Mbps
- Connections per second : 5,000
- Maximum connections (SPI) : 50,000
- Maximum connections (DPI) : 50,000
- Single Sign-On (SSO) Users :500
- VLAN interfaces : 25
- SonicPoints supported (Maximum) : 8
VPN :
- Site-to-Site VPN Tunnels : 10
- IPSec VPN clients (Maximum) : 1 (10)
- SSL VPN licenses (Maximum) : 1 (50)
- Virtual assist bundled (Maximum) : 1 (30-day trial)
- Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14
- Route-based VPN : RIP, OSPF
- Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
- NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
- Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware : McAfee®
- Comprehensive Anti-Spam Service : Supported
- Application Intelligence and Control : Yes
- Application Visualization : Yes
Networking:
- IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
- Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- Local user database : 150
- VoIP : Full H.323v1-5, SIP
- Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : VPNC, IPv6 (Phase 2)
- Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
- Common Access Card (CAC) : Supported
- High Availability : Active/Standby
Hardware:
- Form factor : Desktop
- Power Supply (W) : 24W external
- Maximum power consumption (W) : 6.9 / 12.0
- Input power : 100 to 240 VAC, 50-60 Hz, 1 A
- Total heat dissipation : 23.5 / 40.9 BTU
- Dimensions : 3.5x13.4x19cm
- Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
- WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
- Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
- MTBF (Years) : 28 / 14
- Environment : 40-105° F, 0-40° C
- Humidity : 5-95% non-condensing
SonicWall TZ SOHO Firewall
Performance Overview:
- Operating system : SonicOS 5.9.x – Wired / SonicOS 6.2.x – Wireless
- Security Processor: 2x400 MHz (Wired) / 2x800 MHz (Wireless)
- Memory (RAM): 512 MB (Wired) /1 GB (Wireless)
- 1 GbE Copper interfaces : 5
- Expansion : USB
- Firewall inspection throughput: 300 Mbps
- Full DPI throughput:50 Mbps
- Application inspection throughput:0
- IPS throughput : 100 Mbps
- Anti-malware inspection throughput : 50 Mbps
- IMIX throughput : 60 Mbps
- SSL Inspection and Decryption (DPI SSL) :15 Mbps
- VPN throughput : 100 Mbps
- Connections per second : 1,800
- Maximum connections (SPI) : 10,000
- Maximum connections (DPI) : 10,000
- Single Sign-On (SSO) Users :250
- VLAN interfaces : 25
- SonicPoints supported (Maximum) : 2
VPN :
- Site-to-Site VPN Tunnels : 10
- IPSec VPN clients (Maximum) : 1 (5)
- SSL VPN licenses (Maximum) : 1 (10)
- Virtual assist bundled (Maximum) : No
- Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14
- Route-based VPN : RIP, OSPF
- Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
- NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
- Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware : McAfee®
- Comprehensive Anti-Spam Service : Supported
- Application Intelligence and Control : Yes
- Application Visualization : No
Networking:
- IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
- Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- Local user database : 150
- VoIP : Full H.323v1-5, SIP
- Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : VPNC, IPv6 (Phase 2)
- Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
- Common Access Card (CAC) : Supported
- High Availability : No
Hardware:
- Form factor : Desktop
- Power Supply (W) : 24W external
- Maximum power consumption (W) : 6.4 / 11.3
- Input power : 100 to 240 VAC, 50-60 Hz, 1 A
- Total heat dissipation : 21.8 / 38.7 BTU
- Dimensions : 3.6x14.1x19cm
- Weight : 0.34 Kg / 0.75 lbs & 0.48 Kg / 1.06 lbs
- WEEE weight : 0.80 Kg / 1.76 lbs & 0.94 Kg / 2.07 lbs
- Shipping weight : 1.20 Kg / 2.64 lbs & 1.34 Kg / 2.95 lbs
- MTBF (Years) : 30 / 15
- Environment : 40-105° F, 0-40° C
- Humidity : 5-95% non-condensing
FortiGate 800D Firewall
Interfaces and Modules:
- Hardware Accelerated 10 GE SFP+ Slots : 2
- Hardware Accelerated GE SFP Slots : 8
- Hardware Accelerated GE RJ45 Ports : 20
- Accelerated GE RJ45 Bypass Interfaces : 4
- GE RJ45 Management / HA Ports : 2
- USB Ports (Client / Server) : 1 / 2
- Console Port : 1
- Onboard Storage : 1x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 4.2 Gbps
- NGFW Throughput : 4 Gbps
- Threat Protection Throughput : 3 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP):36 / 36 / 22 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 86 byte, UDP):36 / 36 / 22 Gbps
- Firewall Latency (64 byte, UDP) : 3 ?s
- Firewall Throughput (Packet per Second) : 33 Mpps
- Concurrent Sessions (TCP) : 5 Million
- New Sessions/Second (TCP) : 280,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels: 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 2.2 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 5,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 3.9 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 2,400
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 380,000
- Application Control Throughput (HTTP 64K) : 9 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 5.5 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 64
- Maximum Number of FortiAPs (Total / Tunnel) : 1024 / 512
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
Dimensions and Power:
- Height x Width x Length (inches) : 1.75 x 17.0 x 16.4
- Height x Width x Length (mm): 44.45 x 432 x 416
- Weight : 19.0 lbs (8.6 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Wall Mountable : No
- Power Input : 100–240V AC, 50–60 Hz
- Power Consumption (Average / Maximum) : 128 W / 187 W
- Current (Maximum) : 110V/7A, 220V/3.5A
- Heat Dissipation : 636 BTU/h
- Redundant Power Supplies (Hot Swappable) optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 55 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
Fortinet FortiGate 80E Series
- Brand: Fortinet
- Model: FG-80E-BDL
- Item Weight: 1.2 Kg
- Product Dimensions: 17.8 x 21.6 x 4.2 cm
- Item model number: FG-80E-BDL
- Operating System: None
- Colour Screen: No
- Wattage: 20 Watts
- Batteries Included: No
- Batteries Required: No
- Wireless Type: 802.11abg
Fortinet FortiGate 60E Series
- Brand: Fortinet
- Model: FortiGate-60E
- Item Weight: 1.74 Kg
- Package Dimensions: 30.5 x 21.1 x 12.2 cm
- Item model number: FortiGate 60E
- Batteries Included: No
- Batteries Required: No
FortiGate 6500F Firewall
FG-6500F/6501F
Interfaces and Modules:
- 40/100 GE QSFP28 Slots : 4
- 1/10/25 GE SFP28 Slots : 24
- 10 GE SFP+ Slots : 3
- GE RJ45 Management Ports : 2
- USB Ports : 1
- Console Port : 1
- Internal Storage : 2x 1 TB NVMe (for 6301F and 6501F only)
- Included Transceivers : 2x SFP+ (SR 10 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 170 Gbps
- NGFW Throughput : 150 Gbps
- Threat Protection Throughput : 100 Gbps
System Performance and Capacity :
- Firewall Throughput(1518 / 512 / 64 byte, UDP) : 239 / 238 / 135 Gbps
- Firewall Latency (64 byte, UDP) : 5 ?s
- Firewall Throughput (Packet per Second) : 202.5 Mpps
- Concurrent Sessions (TCP) : 200 Million
- New Sessions/Sec (TCP) : 3 Million
- Firewall Policies : 200,000
- IPsec VPN Throughput (512 byte) : 160 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 16,000
- Client-to-Gateway IPsec VPN Tunnels : 90,000
- SSL-VPN Throughput :9 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 30,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 110 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 50,000
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 18 Million
- Application Control Throughput (HTTP 64K) : 220 Gbps
- CAPWAP Throughput (1444 byte, UDP) : N/A
- Virtual Domains (Default / Maximum) : 10 / 500
- Maximum Number of FortiSwitches Supported : 256
- Maximum Number of FortiAPs(Total / Tunnel Mode) : N/A
- High Availability Configurations : Supported
Dimensions and Power:
- Height x Width x Length (inches): 5.20 x 17.20 x 26.18 5.3 x 17.2 x 27.3
- Height x Width x Length (mm) : 132 x 437 x 665 133 x 437 x 694
- Weight : 78.26 lbs (35.5 kg) / 79.59 lbs (36.1 kg)
- Form Factor (supports EIA/non-EIA standards) : Rack Mount, 3 RU
- AC Power Supply : 100–240V AC, 50–60 Hz
- Power Consumption (Average / Maximum) : (1,308 / 1,548 W) / (1,328 / 1,568 W)
- Current (Maximum) : 20A@240VAC
- Redundant Power Supplies : 2+1 Redundant, Hot Swappable
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 57.43 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
FortiGate 6300F Firewall
FG-6300F/6301F
Interfaces and Modules:
- 40/100 GE QSFP28 Slots : 4
- 1/10/25 GE SFP28 Slots : 24
- 10 GE SFP+ Slots : 3
- GE RJ45 Management Ports : 2
- USB Ports : 1
- Console Port : 1
- Internal Storage : 2x 1 TB NVMe (for 6301F and 6501F only)
- Included Transceivers : 2x SFP+ (SR 10 GE)
System Performance — Enterprise Traffic Mix :
- IPS Throughput : 110 Gbps
- NGFW Throughput : 90 Gbps
- Threat Protection Throughput : 60 Gbps
System Performance and Capacity:
- Firewall Throughput (1518 / 512 / 64 byte, UDP) : 239 / 238 / 135 Gbps
- Firewall Latency (64 byte, UDP) : 5 ?s
- Firewall Throughput (Packet per Second): 202.5 Mpps
- Concurrent Sessions (TCP) 120 Million : 200 Million
- New Sessions/Sec (TCP) : 2 Million
- Firewall Policies : 200,000
- IPsec VPN Throughput (512 byte) : 96 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 16,000
- Client-to-Gateway IPsec VPN Tunnels : 90,000
- SSL-VPN Throughput : 9 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 30,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 66 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 30,000
- SSL Inspection Concurrent Session(IPS, avg. HTTPS) : 10 Million
- Application Control Throughput (HTTP 64K) : 150 Gbps
- CAPWAP Throughput (1444 byte, UDP) : N/A
- Virtual Domains (Default / Maximum) : 10 / 500
- Maximum Number of FortiSwitches Supported : 256
- Maximum Number of FortiAPs (Total / Tunnel Mode) : N/A
- High Availability Configurations : Supported
Dimensions and Power:
- Height x Width x Length (inches) : 5.20 x 17.20 x 26.185.3 x 17.2 x 27.3
- Height x Width x Length (mm) : 132 x 437 x 665
- Weight : 67.68 lbs (30.7 kg)
- Form Factor (supports EIA/non-EIA standards) : Rack Mount, 3 RU
- AC Power Supply : 100–240V AC, 50–60 Hz
- Redundant Power Supplies : 2+1 Redundant, Hot Swappable
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 57.43 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
FortiGate 100E Firewall
Specifications
FORTIGATE 100E
Hardware Specifications:
- GE RJ45 Ports : 14
- GE RJ45 Management/HA/DMZ Ports : 1 / 2
- GE SFP Slots : 0
- GE RJ45 PoE/+ Ports : 0
- GE RJ45 WAN Ports : 2
- GE RJ45 or SFP Shared Ports : 2
- USB Port : 1
- Console Port : 1
- Internal Storage : 0
- Included Transceivers : 0
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 500 Mbps
- NGFW Throughput : 360 Mbps
- Threat Protection Throughput : 250 Mbps
System Performance:
- Firewall Throughput (1518 / 512 / 64 byte UDP packets) : 7.4 / 7.4 / 4.4 Gbps
- Firewall Latency (64 byte UDP packets) : 3 ?s
- Firewall Throughput (Packets Per Second) : 6.6 Mpps
- Concurrent Sessions (TCP) : 2 Million
- New Sessions/Second (TCP) : 30,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 4 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 10,000
- SSL-VPN Throughput : 250 Mbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 500
- SSL Inspection Throughput (IPS, avg. HTTPS) : 130 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 130
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 125,000
- Application Control Throughput (HTTP 64K) : 1 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 1.5 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 24
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 64 / 32
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active / Active, Active / Passive, Clustering
Dimensions:
- Height x Width x Length (inches) : 1.75 x 17 x 10 1.75 x 17 x 10 1.75 x 17 x 10 1.75 x 17 x 15.5
- Height x Width x Length (mm) : 44.45 x 432 x 254 44.45 x 432 x 254 44.45 x 432 x 254 44.45 x 432 x 394
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU Rack Mount, 1 RU Rack Mount, 1 RU Rack Mount, 1 RU
- Weight : 7.28 lbs (3.3 kg) 7.28 lbs (3.3 kg) 7.28 lbs (3.3 kg) 12.4 lbs (5.6 kg)
Environment:
- Power Input : 100–240V AC, 50–60 Hz
- Maximum Current : 100V / 0.52A, 240V / 0.22A 100V / 0.59A, 240V / 0.25A 100V / 0.52A, 240V / 0.22A 100V / 5A
- Total Available PoE Power Budget* — — — 400 W
- Power Consumption (Average / Maximum) : 23.0 W / 28.6 W; 51.9 VA 24.8 W / 33.8 W; 59.2 VA 24.4 W / 28.6 W; 51.9 VA 477.1 W / 500.0 W
- Heat Dissipation : 97.6 BTU/h 115.3 BTU/h 97.6 BTU/h 1706.07 BTU/h
FORTIGATE 50E FIREWALL
The Fortinet Enterprise Firewall Solution :
The FortiGate 100E series delivers next generation firewall capabilities for mid-sized to
large enterprises, with the flexibility to be deployed at the campus or enterprise branch.
Protect against cyber threats with security processor powered high performance, security
efficacy and deep visibility.
Security :
Protects against known exploits, malware and malicious websites using continuous
threat intelligence provided by FortiGuard Labs security services
Identify thousands of applications including cloud applications for deep inspection into network traffic
Detects unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using
purpose built-security processor (SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers an extensive routing, switching, wireless controller and high performance IPsec
VPN capabilities to consolidate networking and security functionality
Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
FORTIGATE 7000E SERIES FIREFALL
Overview :
Protects against known exploits, malware and malicious URLs using continuous threat
intelligence provided by FortiGuard Labs security services
Protects against unknown attacks using dynamic analysis and provides automated
mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using
purpose-built security processor(SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers extensive network interface flexibility with multiple high-speed interface modules
High performance VPN capabilities to inter-connect on-premise
data centers with hosted data center resources in hybrid or public cloud
Enables flexible deployment modes that fit into organizations’evolving network infrastructure
Security Fabric :
Enables Fortinet and Fabric-ready partners’ products to collaboratively integrate and
provide end-to-end security across the entire attack surface
FORTIGATE 7060E CHASSIS FIREFALLS
Overview :
The FortiGate 7060E is a 8U 19-inch rackmount 6-slot chassis with a 80Gbps fabric and 1Gbps base backplane designed by Fortinet. The fabric backplane provides network data communication and the base backplane provides management and synch communication among the chassis slots.
FortiGate 7060E front panel :
The chassis is managed by two redundant management modules. Each module includes an Ethernet connection as well as two switchable console ports that provide console connections to the modules in the chassis slots. The active management module controls chassis cooling and power management and provides an interface for managing the modules installed in the chassis
FIM modules
- FIM modules are hot swappable interface modules that provide data and management interfaces, base
- backplane switching and fabric backplane session-aware load balancing for the chassis. The FIM modules
- include an integrated switch fabric and DP2 processors to load balance millions of data sessions over the chassis
- fabric backplane to FPM processor modules. The following FIM modules are available:
- The FIM-7901E includes thirty-two front panel 10GigE SFP+ fabric channel interfaces (A1 to A32). These interfaces are connected to 10Gbps networks. These interfaces can also be configured to operate as Gigabit Ethernet
- interfaces using SFP transceivers.
- The FIM-7904E includes eight front panel 40GigE QSFP+ fabric channel interfaces (B1 to B8). These interfaces are
- connected to 40Gbps networks. Using 40GBASE-SR4 multimode QSFP+ transceivers, each QSFP+ interface can
- also be split into four 10GBASE-SR interfaces and connected to 10Gbps networks.
- The FIM-7910E (shown in FIM modules on page 6) includes four front panel 100GigE CFP2 fabric channel
- interfaces (C1 to C4). These interfaces can be connected to 100Gbps networks. Using 100GBASE-SR10 multimode
- CFP2 transceivers, each CFP2 interface can also be split into ten 10GBASE-SR interfaces and connected to 10Gbps networks.
- The FIM-7920E includes four front panel 100GigE QSFP28 fabric channel interfaces (C1 to C4). These interfaces can be connected to 100Gbps networks. Using a 100GBASE-SR4 QSFP28 or 40GBASE-SR4 QSFP+ transceiver, each QSFP28 interface can also be split into four 10GBASE-SR interfaces and connected to 10Gbps networks
FORTIGATE 7040E SYSTEM GUIDE FIREFALL
FortiGate 7040E Chassis :
The FortiGate 7040E is a 6U 19-inch rackmount 4 slot chassis with a 80Gbps fabric and 1Gbps base backplane designed by Fortinet. The fabric backplane provides network data communication and the base backplane provides management and synch communication among the chassis slots. Power is provided to the chassis using three hot swappable 2+1 redundant 100 240 VAC, 50-60 Hz power supply units (PSUs). You can also optionally add a fourth PSU. The FortiGate 7040E can also be equipped with three or four DC PSUs allowing you to connect the chassis to 48V DC power.
FPM 7620E FPM modules :
The FPM-7620E modules are hot swappable processor modules that provide FortiOS firewalling and security services. The FPM modules function as workers, processing sessions load balanced to them by the FIM modules.FPM modules include multiple NP6 network processors and CP9 content processors to accelerate traffic.
FortiGate 7040E back panel :
The FortiGate-7040E chassis back panel provides access to three hot swappable cooling fan trays and three hot swappable AC or DC PSUs. A fourth slot is available for including a fourth PSU for additional redundancy. At least two PSUs (PWR1 and PWR2) must be connected to power. PWR4 is a backup power supply. You can add
FORTIGATE 7030E FIREFALL
FortiGate 7030E :
The FortiGate 7030E is a 6U 19 inch rackmount 3-slot chassis with a 80Gbps fabric and 1Gbps base backplane designed by Fortinet. The fabric backplane provides network data communication and the base backplane provides management and synch communication among the chassis slots.
FortiGate 7030E front panel :
The FortiGate 7030E chassis is managed by a single management module that includes an Ethernet connection as well as two switchable console ports that provide console connections to the modules in the chassis slots. The management module controls chassis cooling and power management and provides an interface for managing the modules installed in the chassis. The standard configuration of the FortiGate-7030E includes one FIM (interface) module in chassis slot 1 and two FPM (processing) modules in chassis slots 3 and 4. The front panel also includes a sealed blank panel. Breaking the seal or removing the panel voids your FortiGate 7030E warranty.
FortiGate 7030E schematic :
The FortiGate 7030E chassis schematic below shows the communication channels between chassis components including the management module (MGMT), the FIM (called FIM1) and the FPMs (FPM3 and FPM4).
The management module (MGMT, with Intelligent Platform Management Bus (IPMB) address 0x20) communicates with all modules in the chassis over the base backplane. Each module, including the management module includes a Shelf Management Controller (SMC). These SMCs support IPMB communication between the management module and the FIM and FPMs for storing and sharing sensor data that the management module uses to control chassis cooling and power distribution. The base backplane also supports serial communications to allow console access from the management module to all modules, and 1Gbps Ethernet communication for management and heartbeat communication between modules.
FIM1 (IPMB address 0x82) is the FIM in slot 1. The interfaces of this module connect the chassis to data networks and can be used for Ethernet management access to chassis components. The FIM includes DP2 processors that distribute sessions over the Integrated Switch Fabric (ISF) to the NP6 processors in the FPMs. Data sessions are communicated to the FPMs over the 80Gbps chassis fabric backplane.
FPM3 and FPM4 (IPMB addresses 0x86 and 0x88) are the FPM processor modules in slots 3 and 4. These worker modules process sessions distributed to them by the FIM. FPMs include NP6 processors to offload sessions from the FPM CPU and CP9 processors that accelerate content processing.
FORTIGATE 5001E SECURITY SYSTEM GUIDE FIREFALL
FortiGate 5001E and FortiGate 5001E1 security system :
The FortiGate 5001E security system is a high-performance Advanced Telecommunications Computing Architecture (ATCA) compliant FortiGate security system that can be installed in any ATCA chassis that can provide sufficient power and cooling. The FortiGate-5001E1 security system adds an internal 480 GByte SSD log disk. In all other ways the FortiGate-5001E and the FortiGate-5001E1 are identical.
The FortiGate 5001E security system contains two front panel 40GigE QSFP+ fabric channel interfaces, two front panel 10GigE SFP+ fabric channel interfaces, two base backplane 1Gbps base channel interfaces, and two fabric backplane 40Gbps interfaces. The front panel SFP+ interfaces can also operate as Gigabit Ethernet interfaces using SFP transceivers. Use the front panel interfaces for connections to your networks and the backplane interfaces for communication across the ATCA chassis backplane. The FortiGate-5001E also includes two front panel 10/100/1000BASE-T out of band management Ethernet interfaces, one RJ45 front panel serial console port, and one front panel USB port.
Front panel components :
From the FortiGate-5001E front panel you can view the status of the front panel LEDs to verify that the board is functioning normally. You also connect the FortiGate-5001E to your 40-gigabit network using the front panel QSFP+ connectors and to your 10-gigabit network using the front panel SFP+ or SFP connectors. The front panel also includes two Ethernet management interfaces, an RJ-45 console port for connecting to the FortiOS CLI and a USB port. The USB port can be used with any USB key for backing up and restoring configuration files.
FORTIGATE 3960E FIREWALL
Overview :
The FortiGate 3900E series delivers high performance threat protection for mid-sized to large enterprises and service providers, with the flexibility to be deployed at the Internet or cloud edge, in the data center core or internal segments. The multiple high-speed interfaces, high port density, industry-leading security efficacy and high throughput of the 3900E series keeps your network connected and secure.
Security :
Protects against known exploits, malware and malicious URLs using continuous threat intelligence provided by FortiGuard Labs security services
Protects against unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
- Delivers industry's best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
- Unprecedented 1 Terabit/second network firewall throughput in an appliance form factor for FortiGate 3980E
- Provides industry-leading performance and protection for SSL encrypted traffic
Certification :
- Independently tested and validated best security effectiveness and performance
- Received unparalleled third-party certifications from NSS Labs, ICSA, Virus Bulletin and AV Comparatives
Networking :
- Delivers extensive routing, high-speed interfaces, and high performance VPN capabilities to address performance and connectivity needs of large-scale data center and cloud applications
- Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
FORTIGATE 6300F FIREFALL
Overview:
Ultra High-Performance Network Security
Digital enterprises are processing vast amounts of encrypted traffic and content rich data along with an increased emphasis on optimized user experiences. The digital attack surface has spawned new, complex forms of attacks that require advanced protection to be applied at anytime, anywhere the threat is discovered. Today’s next-generation firewalls (NGFWs) must reliably handle large volumes of network and cloud traffic, provide consolidated advanced security in a smaller, more efficient physical footprint, and accommodate new security requirements such as extensive inspection of encrypted traffic for sophisticated malware without impacting performance.
The new FortiGate 6000 NGFW appliances feature the latest Fortinet innovation, to deliver leading edge security, performance, and connectivity for the most demanding network needs. The 6000 series combines unprecedented threat protection and SSL inspection performance in an easy to manage, compact appliance.
FORTINET FORTIGATE 6500F FIREWALL
Overview:
Ultra High-Performance Network Security
Digital enterprises are processing vast amounts of encrypted traffic and content rich data along with an increased emphasis on optimized user experiences. The digital attack surface has spawned new, complex forms of attacks that require advanced protection to be applied at anytime, anywhere the threat is discovered. Today’s next-generation firewalls (NGFWs) must reliably handle large volumes of network and cloud traffic, provide consolidated advanced security in a smaller, more efficient physical footprint, and accommodate new security requirements such as extensive inspection of encrypted traffic for sophisticated malware without impacting performance.
The new FortiGate 6000 NGFW appliances feature the latest Fortinet innovation, to deliver leading edge security, performance, and connectivity for the most demanding network needs. The 6000 series combines unprecedented threat protection and SSL inspection performance in an easy to manage, compact appliance.
FORTIGATE 3980E FIREWALL
Security Fabric :
The Security Fabric allows security to dynamically expand andadapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environment throughout the network. FortiGates are the foundation of Security Fabric, expanding security via visibility and control by tightly integrating with other Fortinet security products and Fabric-Ready Partner solutions.
FortiOS :
Control all the security and networking capabilities across the entire FortiGate platform with one intuitive operating system. Reduce operating expenses and save time with a truly consolidated nextgeneration security platform.
- Powered by SPU
- Custom SPU processors deliver the power you need to detect malicious content at multi-Gigabit speeds
- Other security technologies cannot protect against today’s wide range of content- and connection-based
- threats because they rely on general-purpose CPUs, causing a dangerous performance gap SPU processors provide the performance needed to block emerging threats, meet rigorous third-party certifications, and ensure that your network security solution does not become a network bottleneck
FORTIGATE 3800D FIREWALL
Overview:
Fortinet's FortiGate 3800D Series are the only security appliances capable of delivering an unprecedented 300+ Gbps throughput, while also featuring 100 GE interface ports and IPv4 to IPv6 performance parity integral in supporting next generation fabric.
Fortinet Enterprise Firewall Solution :
The Fortinet Enterprise Firewall Solution delivers end-to-end network security with one platform, one network security operating system and unified policy management with a single pane of glass — for the industry's best protection against the most advanced security threats and targeted attacks.
Future-Proofing the Next Generation Data Center :
They deliver their breakthrough performance and protection in a compact 3U form factor with six 100 GE interfaces that preserve scarce rack space while maximizing capacity. Powered by the new FortiASIC NP6 processor, the FortiGate 3800D Series allow customers to build 100G data centers without worrying about high speed connectivity or throughput of the core firewall.
- Flexible Deployment
- The FortiGate 3800D Series give you the flexibility to choose the firewall personality that best fits your requirements at the Edge or Core. You can take advantage of the high port density for physical segmentation of your network, as well as the virtual domains (VDOMs) for virtual segmentation.
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
FORTIGATE 3700D FIREWALL
Overview:
The FortiGate 3700D high performance, high capacity data center firewall provides exceptional performance of 160 Gbps and ultra-low latency, ensuring your data center security solution doesn't become your data center bottleneck.
Eliminate Security Bottlenecks
It delivers this breakthrough performance and protection in a compact 3U form factor with four 40 GE and 28 10 GE interfaces that preserves scarce rack space while maximizing capacity. Powered by the new FortiASIC NP6 processor, the FortiGate 3700D is the first data center appliance to deliver performance parity for IPv4 and IPv6 traffic and dramatically increases VPN performance, enabling you to keep pace with your evolving network.
Flexible Deployment
The FortiGate 3700D gives you the flexibility to choose the firewall personality that best fits your requirements at the Edge or Core. You can take advantage of the high port density for physical segmentation of your network, as well as the virtual domains (VDOMs) for virtual segmentation.
- Performance and Reliability for High Bandwidth Networks
- Breakthrough IPv4 to IPv6 firewall performance parity
- Flexible firewall personalities enable deployment at the Edge or Core
- Compact 3U footprint conserves rack space and minimizes energy consumption
- Freedom to add integrated security technologies (such as IPS, App Control, VPN)
- Cloud-ready multi-tenant support and APIs for rapid orchestration
- FortiOS 5 delivers the most complete, battle-tested set of security functions to protect your network and data
FORTIGATE 3100D FIREWALL
Overview :
Today’s data centers require security appliances that deliver exceptional performance, deployment flexibility and extensive security features, to protect the most demanding network environments. The FortiGate 3100D device is ideally suited for network segmentation and internal network threat protection in data centers with its 32 10 GE interfaces.
10 Times Data Center Firewall Performance :
The FortiGate 3100D appliance provides up to 80 Gbps of firewall throughput through the use of innovative FortiASIC processors and the latest generation of multi-core CPUs. Impressive consolidated security performance and support for a variety of configurations ensure that essential security functions keep up with the rest of your network.
Future-proof Security :
The system also provides technologies that include robust networking capabilities and extensible security features, all managed from an intuitive management console with deep insight offerings, enabling you to keep pace with your evolving network.
Features & Benefits ;
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
FORTIGATE 3000D FIREWALL
Overview :
Today’s data centers require security appliances that deliver exceptional performance, deployment flexibility and extensive security features, to protect the most demanding network environments. The FortiGate 3100D device is ideally suited for network segmentation and internal network threat protection in data centers with its 32 10 GE interfaces.
10 Times Data Center Firewall Performance :
The FortiGate 3100D appliance provides up to 80 Gbps of firewall throughput through the use of innovative FortiASIC processors and the latest generation of multi-core CPUs. Impressive consolidated security performance and support for a variety of configurations ensure that essential security functions keep up with the rest of your network.
Future-proof Security :
The system also provides technologies that include robust networking capabilities and extensible security features, all managed from an intuitive management console with deep insight offerings, enabling you to keep pace with your evolving network.
Features & Benefits :
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
FORTIGATE 2500E FIREWALL
Security Fabric
The Security Fabric allows security to dynamically expand and adapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environments throughout the network. FortiGates are the foundation of Security Fabric, expanding security via visibility and control by tightly integrating with other Fortinet security products and Fabric-Ready Partner solutions
FortiOS :
Control all the security and networking capabilities across the entire FortiGate platform with one intuitive operating system. Reduce operating expenses and save time with a truly consolidated nextgeneration security platform.
FORTIGATE 2000E FIREWALL
Overview :
The FortiGate network appliances represent the enterprise firewall platforms. FortiGate is based on FortiASIC, a purpose-built integrated architecture, that provides extremely high throughput and exceptionally low latency, while delivering excellent security effectiveness and consolidation. Targeted for large enterprises, the FortiGate 2000E delivers high NGFW and SSL inspection performance along with high port density and dual power supply for maximum flexibility.
FORTIGATE 1500D FIREWALL
Overview:
Every day you’re on the lookout for sophisticated attacks designed to penetrate your organization and steal valuable information. At the same time, you need to increase network speeds and capacities to accommodate the proliferation of consumergrade applications and devices. To adequately defend against threats across such a broad range of applications and devices- without slowing down your network- you need a high performance next generation/edge firewall (NGFW) appliance for deep inspection, visibility and control.
Breakthrough Performance:
The FortiGate-1500D high performance next generation/edge firewall delivers best in class performance with an exceptional 80 Gbps of firewall and 11 Gbps of next generation threat protection. Custom hardware, including the latest FortiASIC™ NP6 processors, and the consolidated security features of the FortiOS™ 5 network security platform make the difference in enabling protection of your applications and network without affecting availability or performance.
Deeper Visibility:
With powerful intrusion prevention, application control and antimalware intelligence, the FortiGate-1500D allows you to look deeper into your content, applications, user and device behavior. Rich console views and reports together with a flexible policy engine provide the visibility and control you need to empower employees yet secure your enterprise.
- Next Generation Visibility and Control
- Powerful application and threat inspection
- Breakthrough performance, and superior cost per gigabit protected
- User- and device-based views and policies
- Freedom to add more functions like Advanced Threat
- Protection and Secure Web Gateway
- FortiOS 5, the most complete, battletested set of security functions to protect your network and data
FORTIGATE 1200D FIREWALL
Overview:
Enterprises require a high-speed, high-capacity firewall to stay ahead of ever-increasing network performance requirements as well as continued evolution of the threat landscape, at data center and campus locations.
Eliminate Security Bottlenecks
With 52 Gbps of firewall throughput and low latency, the FortiGate 1200D represents an excellent entry model for small data centers and delivers a high-performance, high-capacity data center firewall. IPv6 parity, 10 GE ports and dramatic increases in VPN performance enable you to keep pace with your evolving network.
Deeper Visibility
At the same time, 11 Gbps of next generation threat prevention performance allows you to run top-rated intrusion prevention, application control and antimalware capabilities for deeper inspection of content, applications, user and device activity. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
Breakthrough Performance
This breakthrough performance — including 10x data center and 5x next generation performance — is made possible by custom hardware, including the latest FortiASIC™ NP6 and CP8 processors, as well as the consolidated security features of the FortiOS network security platform.
- High Performance, Reliability and Security
- 10x data center and 5x next generation performance
- Top rated security capabilities
- Flexible firewall personalities for core or edge deployment
- Low latency and IPv6 parity
FORTIGATE 1000D FIREWALL
NP Direct :
By removing the Internal Switch Fabric, the NP Direct architecture provides direct access to the SPU-NP for the lowest latency forwarding. NGFW deployments require some attention to network design to ensure optimal use of this technology
Content Processor :
The SPU CP8 content processor works outside of the direct flow of traffic, providing high-spee cryptography and content inspection
services including:
Signature-based content inspection acceleration
Encryption and decryption offloading
FortiOS :
Control all the security and networking capabilities across the entire FortiGate platform with one intuitive operating system. Reduce operating expenses and save time with a truly consolidated next generation security platform.
FortiCare Support Services :
Our FortiCare customer support team provides global technical support for all Fortinet products. With support staff in the Americas, Europe, Middle East and Asia, FortiCare offers services to meet the needs of enterprises of all sizes:
Enhanced Support — For customers who need support during local business hours only.
Comprehensive Support — For customers who need aroundthe-clock mission critical support, including advanced exchange hardware replacement.
Advanced Services — For global or regional customers who need an assigned Technical Account Manager, enhanced service level agreements, extended software support, priority
escalation, on-site visits and more.
Professional Services — For customers with more complex security implementations that require architecture and design services, implementation and deployment services, operational services and more.
SONICWALL NSSP 12400 FIREWALL
- Firewall throughput : 59 Gbps
- IPS throughput : 26 Gbps
- Anti-malware throughput : 16 Gbps
- Full DPI throughput : 17 Gbps
- IMIX throughput : 14 Gbps
- Maximum DPI connections : 6,000,000
- New connections/sec : 430,000/sec
- Storage module : 2 x 480 GB
SONICWALL NSSP 12800 FIREWALL
- Stateful inspection firewall throughput :300 Mbps
- Stateful inspection firewall throughput (multiprotocol) :50 Gbps
- Concurrent firewall connections :55 million
- Firewall latency (UDP 64B microseconds):3.5
- New connections per second : 800,000
- IPsec VPN throughput (450B UDP L2L test) : 15 Gbps
- IPsec/Cisco AnyConnect/Apex site-to-site VPN peers :20,000
- Security contexts (included; maximum) :10; 250
- High availability: active/standby
FORTIGATE 900D FIREWALL
Overview:
With network bandwidth requirements doubling every 18 months and increases in sophisticated cyber threats, enterprise organizations with large branch offices know they need high-speed network security that also delivers highly effective next generation security.
5 Times Next Generation Firewall Performance :
The FortiGate 900D appliance delivers superior performance through a combination of purpose-built FortiASIC™ processors, high port density with 10 GE ports and consolidated security features from the FortiOS™ operating system. It delivers 5 times better next generation firewall performance compared to alternate products and provides the best price/performance in the industry.
Deeper Visibility and Top-rated Security :
This breakthrough threat prevention performance allows organizations to run NSS Labs Recommended intrusion prevention and application control and VB100 certified antimalware capabilities for deeper inspection. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
Finally, these features of the FortiGate FortiOS Network Security Platform are routinely validated by independent real-world tests and are consistently getting superior ratings in security effectiveness.
Features & Benefits :
- 5 times faster hardware accelerated next generation firewall offers best-in-class price/performance ratio
- Integrated high port density delivers maximum flexibility and scalability
- NSS Labs Recommended NGFW and NGIPS with consolidated security delivers top-rated protection
- Application control plus identity and device-based policy enforcement provides more granular protection
- Intuitive management interface enables broad and deep visibility that scales from a single FortiGate to thousands
FORTIGATE 800D FIREWALL
Overview :
With network bandwidth requirements doubling every 18 months and increases in sophisticated cyber threats, enterprise organizations with large branch offices know they need high-speed network security that also delivers highly effective next generation security.
Superior Next Generation Firewall Performance :
The FortiGate 800D appliance delivers superior performance through a combination of purpose-built FortiASIC processors, high port density with 10 GE ports and consolidated security features from the FortiOS operating system. It delivers better next generation firewall performance compared to alternate products and provides the best price/performance in the industry.
Deeper Visibility and Top-rated Security :
- This breakthrough threat prevention performance allows organizations to run NSS Labs Recommended intrusion prevention and application control and VB100 certified antimalware capabilities for deeper inspection. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
- Finally, these features of the FortiGate FortiOS Network Security Platform are routinely validated by independent real-world tests and are consistently getting superior ratings in security effectiveness.
FORTIGATE 600D FIREWALL
Overview :
With network bandwidth requirements doubling every 18 months and increases in sophisticated cyber threats, enterprise organizations with large branch offices know they need high-speed network security that also delivers highly effective next generation security.
Superior Next Generation Firewall Performance :
The FortiGate 800D appliance delivers superior performance through a combination of purpose-built FortiASIC processors, high port density with 10 GE ports and consolidated security features from the FortiOS operating system. It delivers better next generation firewall performance compared to alternate products and provides the best price/performance in the industry.
Deeper Visibility and Top-rated Security :
- This breakthrough threat prevention performance allows organizations to run NSS Labs Recommended intrusion prevention and application control and VB100 certified antimalware capabilities for deeper inspection. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
- Finally, these features of the FortiGate FortiOS Network Security Platform are routinely validated by independent real-world tests and are consistently getting superior ratings in security effectiveness.
FORTIGATE 300E FIREWALL
Security :
Protects against known exploits, malware and malicious websites using continuous threat intelligence provided by FortiGuard Labs security services
Identify thousands of applications including cloud applications for deep inspection into network traffic
Protects against unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers extensive routing, switching, wireless controller and high performance IPsec VPN capabilities to consolidate networking and security functionality
Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
Management :
Single Pane of Glass with Network Operations Center (NOC) view provides 360° visibility to identify issues quickly and intuitively
Predefined compliance checklist analyzes the deployment and highlights best practices to improve overall security posture
FORTIGATE 200E FIREWALL
Security :
Protects against known exploits, malware and malicious websites using continuous threat intelligence provided by FortiGuard Labs security services
Identify thousands of applications including cloud applications for deep inspection into network traffic
Protects against unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers extensive routing, switching, wireless controller and high performance IPsec VPN capabilities to consolidate networking and security functionality
Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
Management :
Single Pane of Glass with Network Operations Center (NOC) view provides 360° visibility to identify issues quickly and intuitively
Predefined compliance checklist analyzes the deployment and highlights best practices to improve overall security posture
FORTIGATE 100E FIREWALL
Overview:
The Fortinet Enterprise Firewall Solution
The FortiGate 100E series delivers next generation firewall capabilities for mid-sized to large enterprises, with the flexibility to be deployed at the campus or enterprise branch. Protect against cyber threats with security processor powered high performance, security efficacy and deep visibility.
Security :
Protects against known exploits, malware and malicious websites using continuous threat intelligence provided by FortiGuard Labs security services
Identify thousands of applications including cloud applications for deep inspection into network traffic
Detects unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using purpose built-security processor (SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers an extensive routing, switching, wireless controller and high performance IPsec VPN capabilities to consolidate networking and security functionality
Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
SONICWALL NSA 2650 FIREWALL
Overview:
The SonicWall Network Security services platform (NSsp) High-End Firewall series takes an innovative approach to threat detection and prevention by combining appliance-based protection with cloud intelligence in a reliable, high-performance platform. Designed for large distributed enterprises, data centers and service providers, the NSsp High-End series consolidates advanced security technologies that deliver proven, scalable protection for millions of connections from the most advanced threats without slowing performance.
SUPERIOR THREAT PREVENTION AND PERFORMANCE :
- Block more attacks with patent-pending Real-Time Deep Memory Inspection (RTDMITM) & Patented Real-Free Deep Packet Inspection (RFDPI®) technology
- Combine cloud-based and on-box threat prevention featuring multi-engine sandboxing
- industry-validated high security effectiveness
- Get high-speed performance with 40-Gigabit Ethernet ports
- Security that scales to protect millions of encrypted connections
- Decrypt and inspect TLS/SSL and SSH traffic in real time
NETWORK CONTROL AND FLEXIBILITY :
- Leverage powerful SonicOS operating system
- Gain application intelligence and control
- Segment your network into zones
- Deploy at the network edge or data center core
SONICWALL NSA 3650 FIREWALL
Overview:
The SonicWall Network Security services platform (NSsp) High-End Firewall series takes an innovative approach to threat detection and prevention by combining appliance-based protection with cloud intelligence in a reliable, high-performance platform. Designed for large distributed enterprises, data centers and service providers, the NSsp High-End series consolidates advanced security technologies that deliver proven, scalable protection for millions of connections from the most advanced threats without slowing performance.
SUPERIOR THREAT PREVENTION AND PERFORMANCE :
- Block more attacks with patent-pending Real-Time Deep Memory Inspection (RTDMITM) & Patented Real-Free Deep Packet Inspection (RFDPI®) technology
- Combine cloud-based and on-box threat prevention featuring multi-engine sandboxing
- Industry-validated high security effectiveness
- Get high-speed performance with 40-Gigabit Ethernet ports
- Security that scales to protect millions of encrypted connections
- Decrypt and inspect TLS/SSL and SSH traffic in real time
NETWORK CONTROL AND FLEXIBILITY :
- Leverage powerful SonicOS operating system
- Gain application intelligence and control
- Segment your network into zones
- Deploy at the network edge or data center core
SONICWALL NSA 4650 FIREWALL
Overview:
The SonicWall Network Security appliance (NSa) series provides organizations that range in scale from mid-sized networks to distributed enterprises and data centers with advanced threat prevention in a highperformance security platform. Utilizing innovative deep learning technologies in the SonicWall Capture Cloud Platform, the NSa series delivers the automated real-time breach detection and prevention organizations need.
Network control and flexibility :
At the core of the NSa series is SonicOS, SonicWall’s feature-rich operating system. SonicOS provides organizations with the network control and flexibility they require through application intelligence and control, real-time visualization, an intrusion prevention system (IPS) featuring sophisticated anti-evasion technology, high-speed virtual private networking (VPN) and other robust security features. Using application intelligence and control, network administrators can identify and categorize productive applications from those that are unproductive or potentially dangerous, and control that traffic through powerful applicationlevel policies on both a per-user and a per-group basis (along with schedules and exception lists). Business-critical applications can be prioritized and allocated more bandwidth while non essential applications are bandwidthlimited. Real-time monitoring and visualization provides a graphical representation of applications, users and bandwidth usage for granular insight into traffic across the network.
Secure, High-speed Wireless :
Combine an NSa series next-generation firewall with a SonicWall SonicWave 802.11ac Wave 2 wireless access point to create a highspeed wireless network security solution. NSa series firewalls and SonicWave access points both feature 2.5 GbE ports that enable multi-gigabit wireless throughput offered in Wave 2 wireless technology. The firewall scans all wireless traffic coming into and going out of the network using deep packet inspection technology and then removes harmful threats such as malware and intrusions, even over encrypted connections. Additional security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection can be run on the wireless network to provide added layers of protection.
SONICWALL NSA 5650 FIREWALL
Overview:
The SonicWall Network Security appliance (NSa) series provides organizations that range in scale from mid-sized networks to distributed enterprises and data centers with advanced threat prevention in a highperformance security platform. Utilizing innovative deep learning technologies in the SonicWall Capture Cloud Platform, the NSa series delivers the automated real-time breach detection and prevention organizations need.
Network control and flexibility :
At the core of the NSa series is SonicOS, SonicWall’s feature-rich operating system. SonicOS provides organizations with the network control and flexibility they require through application intelligence and control, real-time visualization, an intrusion prevention system (IPS) featuring sophisticated anti-evasion technology, high-speed virtual private networking (VPN) and other robust security features. Using application intelligence and control, network administrators can identify and categorize productive applications from those that are unproductive or potentially dangerous, and control that traffic through powerful applicationlevel policies on both a per-user and a per-group basis (along with schedules and exception lists). Business-critical applications can be prioritized and allocated more bandwidth while non essential applications are bandwidthlimited. Real-time monitoring and visualization provides a graphical representation of applications, users and bandwidth usage for granular insight into traffic across the network.
Secure, High-speed Wireless :
Combine an NSa series next-generation firewall with a SonicWall SonicWave 802.11ac Wave 2 wireless access point to create a highspeed wireless network security solution. NSa series firewalls and SonicWave access points both feature 2.5 GbE ports that enable multi-gigabit wireless throughput offered in Wave 2 wireless technology. The firewall scans all wireless traffic coming into and going out of the network using deep packet inspection technology and then removes harmful threats such as malware and intrusions, even over encrypted connections. Additional security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection can be run on the wireless network to provide added layers of protection.
SONICWALL NSA 6650 FIREWALL
Overview:
The SonicWall Network Security appliance (NSa) series provides organizations that range in scale from mid-sized networks to distributed enterprises and data centers with advanced threat prevention in a highperformance security platform. Utilizing innovative deep learning technologies in the SonicWall Capture Cloud Platform, the NSa series delivers the automated real-time breach detection and prevention organizations need.
Network control and flexibility :
At the core of the NSa series is SonicOS, SonicWall’s feature-rich operating system. SonicOS provides organizations with the network control and flexibility they require through application intelligence and control, real-time visualization, an intrusion prevention system (IPS) featuring sophisticated anti-evasion technology, high-speed virtual private networking (VPN) and other robust security features. Using application intelligence and control, network administrators can identify and categorize productive applications from those that are unproductive or potentially dangerous, and control that traffic through powerful applicationlevel policies on both a per-user and a per-group basis (along with schedules and exception lists). Business-critical applications can be prioritized and allocated more bandwidth while non essential applications are bandwidthlimited. Real-time monitoring and visualization provides a graphical representation of applications, users and bandwidth usage for granular insight into traffic across the network.
Secure, High-speed Wireless :
Combine an NSa series next-generation firewall with a SonicWall SonicWave 802.11ac Wave 2 wireless access point to create a highspeed wireless network security solution. NSa series firewalls and SonicWave access points both feature 2.5 GbE ports that enable multi-gigabit wireless throughput offered in Wave 2 wireless technology. The firewall scans all wireless traffic coming into and going out of the network using deep packet inspection technology and then removes harmful threats such as malware and intrusions, even over encrypted connections. Additional security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection can be run on the wireless network to provide added layers of protection.
SONICWALL NSA 9250 FIREWALL
Overview:
The SonicWall Network Security appliance (NSa) series provides organizations that range in scale from mid-sized networks to distributed enterprises and data centers with advanced threat prevention in a highperformance security platform. Utilizing innovative deep learning technologies in the SonicWall Capture Cloud Platform, the NSa series delivers the automated real-time breach detection and prevention organizations need.
Network control and flexibility :
At the core of the NSa series is SonicOS, SonicWall’s feature-rich operating system. SonicOS provides organizations with the network control and flexibility they require through application intelligence and control, real-time visualization, an intrusion prevention system (IPS) featuring sophisticated anti-evasion technology, high-speed virtual private networking (VPN) and other robust security features. Using application intelligence and control, network administrators can identify and categorize productive applications from those that are unproductive or potentially dangerous, and control that traffic through powerful applicationlevel policies on both a per-user and a per-group basis (along with schedules and exception lists). Business-critical applications can be prioritized and allocated more bandwidth while non essential applications are bandwidthlimited. Real-time monitoring and visualization provides a graphical representation of applications, users and bandwidth usage for granular insight into traffic across the network.
Secure, High-speed Wireless :
Combine an NSa series next-generation firewall with a SonicWall SonicWave 802.11ac Wave 2 wireless access point to create a highspeed wireless network security solution. NSa series firewalls and SonicWave access points both feature 2.5 GbE ports that enable multi-gigabit wireless throughput offered in Wave 2 wireless technology. The firewall scans all wireless traffic coming into and going out of the network using deep packet inspection technology and then removes harmful threats such as malware and intrusions, even over encrypted connections. Additional security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection can be run on the wireless network to provide added layers of protection.
FORTIGATE 90E FIREWALL
Install in Minutes with FortiExplorer :
The FortiExplorer wizard enables easy setup and configuration coupled with easy-to-follow instructions. FortiExplorer runs on popular mobile devices like Android and iOS. Using FortiExplorer is as simple as starting the application and connecting to the appropriate USB port on the FortiGate. By using FortiExplorer, you can be up and running and protected in minutes.
3G/4G WAN Connectivity :
The FortiGate 90E includes USB ports that allow you to plug in a compatible third-party 3G/4G USB modem, providing additional WAN connectivity or a redundant link for maximum reliability
Compact and Reliable Form Factor :
Designed for small environments, you can simply place the FortiGate 90E on a desktop. It is small, lightweight yet highly reliable with superior MTBF (Mean Time Between Failure), minimizing the chance of a network disruption.
Security Fabric :
The Security Fabric allows security to dynamically expand and adapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environments throughout the network.
FORTIGATE 80E FIREWALL
Overview :
The Fortinet Enterprise Firewall Solution
The FortiGate 100E series delivers next generation firewall capabilities for mid-sized to large enterprises, with the flexibility to be deployed at the campus or enterprise branch. Protect against cyber threats with security processor powered high performance, security efficacy and deep visibility.
Security :
Protects against known exploits, malware and malicious websites using continuous threat intelligence provided by FortiGuard Labs security services
Identify thousands of applications including cloud applications for deep inspection into network traffic
Detects unknown attacks using dynamic analysis and provides automated mitigation to stop targeted attacks
Performance :
Delivers industry’s best threat protection performance and ultra-low latency using purpose built-security processor (SPU) technology
Provides industry-leading performance and protection for SSL encrypted traffic
Networking :
Delivers an extensive routing, switching, wireless controller and high performance IPsec VPN capabilities to consolidate networking and security functionality
Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
FORTIGATE 60E FIREWALL
Install in Minutes with FortiExplorer :
The FortiExplorer wizard enables easy setup and configuration coupled with easy-to-follow instructions. FortiExplorer runs on popular mobile devices like Android and iOS. Using FortiExplorer is as simple as starting the application and connecting to the appropriate USB port on the FortiGate. By using FortiExplorer, you can be up and running and protected in minutes.
3G/4G WAN Connectivity :
The FortiGate 90E includes USB ports that allow you to plug in a compatible third-party 3G/4G USB modem, providing additional WAN connectivity or a redundant link for maximum reliability
Compact and Reliable Form Factor :
Designed for small environments, you can simply place the FortiGate 90E on a desktop. It is small, lightweight yet highly reliable with superior MTBF (Mean Time Between Failure), minimizing the chance of a network disruption.
Security Fabric :
The Security Fabric allows security to dynamically expand and adapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environments throughout the network.
FORTIGATE 30E FIREWALL
Overview:
The FortiGate/FortiWiFi 30E are compact, cost effective, all-in-one security appliances that deliver Fortinet’s Connected UTM. Ideal for small business, remote, customer premise equipment (CPE) and retail networks, these appliances offer the network security, connectivity and performance you need.
High Performance Network Security :
Built on the foundation FortiOS 5, the FortiGate/FortiWiFi 30E series provides an integrated set of essential security technologies to protect all of your applications and data. You get advanced threat protection, including firewall, application control, advanced threat protection, IPS, VPN, and web filtering, all from one device that’s easy to deploy and manage. With our FortiGuard® security subscription services you’ll have automated protection against today’s sophisticated threats.
Advanced Features :
The FortiGate/FortiWiFi 30E offers beyond the industry’s best firewall with the latest in Advanced Threat Protection including Sandboxing and anti-bot protection, Feature Select Options for simplifying configurations and deployments, and Contextual Visibility for enhanced reporting and management.
VDOMs on the FortiGate/FortiWiFi 30E let you segment networks to enable guest and employee access, or protect things like cardholder data. You get the flexibility to match your business needs and meet compliance standards like PCI and HIPAA.
FORTIGATE 60D RUGGED FIREWALL
Security Fabric :
The Security Fabric allows security to dynamically expand and adapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environments throughout the network. FortiGates are the foundation of Security Fabric, expanding security via visibility and control by tightly integrating with other Fortinet security products and Fabric-Ready Partner solutions.
FortiOS :
Control all the security and networking capabilities across the entire FortiGate platform with one intuitive operating system. Reduce operating expenses and save time with a truly consolidated nextgeneration security platform.
SONICWALL TZ300 SERIES FIREWALL
Overview:
Exceptional security and stellar performance at a disruptively low TCO
- The SonicWALL TZ series of next generation firewalls (NGFW) is ideally suited for any organization that requires enterprise-grade network protection.
- SonicWALL TZ series firewalls provide broad protection with advanced security services consisting of onbox and cloud-based anti-malware, anti-spyware, application control, intrusion prevention system (IPS), and URL filtering. To counter the trend of encrypted attacks, the SonicWALL TZ series has the processing power to inspect encrypted SSL connections against the latest threats.
- Backed by the SonicWALL Global Response Intelligent Defense (GRID) network, the SonicWALL TZ series delivers continuous updates to maintain a strong network defense against cybercriminals. The SonicWALL TZ series is able to scan every byte of every packet on all ports and protocols with almost zero latency and no file size limitations.
- The SonicWALL TZ series features Gigabit Ethernet ports, optional integrated 802.11ac wireless, IPSec and SSL VPN, failover through integrated 3G/4G support, load balancing and network segmentation. The SonicWALL TZ series UTM firewalls also provide fast, secure mobile access over Apple iOS, Google Android, Amazon Kindle, Windows, MacOS and Linux platforms.
- The SonicWALL Global Management System (GMS) enables centralized deployment and management of SonicWALL TZ series firewalls from a single system.
Managed security for distributed environments :
Schools, retail shops, remote sites, branch offices and distributed enterprises need a solution that integrates with their corporate firewall. SonicWALL TZ series firewalls share the same code base—and same protection—as our flagship SuperMassive next-generation firewalls. This simplifies remote site management, as every administrator sees the same user interface (UI). GMS enables network administrators to configure, monitor and manage remote SonicWALL firewalls through a single pane of glass. By adding highspeed, secure wireless, the SonicWALL TZ series extends the protection perimeter to include customers and guests frequenting the retail site or remote
SONICWALL TZ SOHO SERIES FIREWALL
The SOHO offers affordable UTM firewalls for home and small businesses :
Protect your organization with highly effective intrusion prevention, anti-malware, content/URL filtering and application control with the business-grade SonicWall TZ Series Unified Threat Management (UTM) firewalls. Eliminate network bottlenecks and increase productivity while also providing secure access to a broad range of mobile devices, including laptops, smartphones and tablets. Confidently deploy this secure, sophisticated small-business firewall appliance in a wide range of organizations, such as retail, branch/remote offices or home offices. With a SonicWall TZ Series firewall, you can be assured your wired and wireless networks are protected by a secure, sophisticated and widely deployed security platform.
Features :
SonicWall TZ Series Unified Threat Management (UTM) firewalls deliver high performance and proven best-in-class protection to small businesses with integrated intrusion prevention, anti-malware and content/URL filtering capabilities.
Full-featured, advanced security :
Deliver full-featured security that combines intrusion prevention, gateway anti-virus, anti-spyware, content filtering and anti-spam services, with intuitive, easy-to-use SonicWall TZ Series firewalls.
Fast, reliable, enhanced performance :
Examine all wired and wireless traffic for threats, without slowing down your network, using the patented1 SonicWall Reassembly-Free Deep Packet Inspection (RFDPI) technology. TZ Series firewalls also ensure bandwidth for critical business applications, while blocking unproductive applications.
Broad, flexible, remote access :
Provide mobile users with native VPN remote access clients for Apple iOS, Google Android, Windows 8.1, Mac OS® X, Kindle Fire and Linux, via your small-business firewall. This unique client also supports the firewall's capability to decontaminate threats from VPN traffic.
SONICWALL TZ400 SERIES FIREWALL
Overview:
Exceptional security and stellar performance at a disruptively low TCO
The SonicWALL TZ series of next generation firewalls (NGFW) is ideally suited for any organization that requires enterprise-grade network protection.
SonicWALL TZ series firewalls provide broad protection with advanced security services consisting of onbox and cloud-based anti-malware, anti-spyware, application control, intrusion prevention system (IPS), and URL filtering. To counter the trend of encrypted attacks, the SonicWALL TZ series has the processing power to inspect encrypted SSL connections against the latest threats.
Backed by the SonicWALL Global Response Intelligent Defense (GRID) network, the SonicWALL TZ series delivers continuous updates to maintain a strong network defense against cybercriminals. The SonicWALL TZ series is able to scan every byte of every packet on all ports and protocols with almost zero latency and no file size limitations.
The SonicWALL TZ series features Gigabit Ethernet ports, optional integrated 802.11ac wireless, IPSec and SSL VPN, failover through integrated 3G/4G support, load balancing and network segmentation. The SonicWALL TZ series UTM firewalls also provide fast, secure mobile access over Apple iOS, Google Android, Amazon Kindle, Windows, MacOS and Linux platforms.
The SonicWALL Global Management System (GMS) enables centralized deployment and management of SonicWALL TZ series firewalls from a single system.
Managed security for distributed environments :
Schools, retail shops, remote sites, branch offices and distributed enterprises need a solution that integrates with their corporate firewall. SonicWALL TZ series firewalls share the same code base—and same protection—as our flagship SuperMassive next-generation firewalls. This simplifies remote site management, as every administrator sees the same user interface (UI). GMS enables network administrators to configure, monitor and manage remote SonicWALL firewalls through a single pane of glass. By adding highspeed, secure wireless, the SonicWALL TZ series extends the protection perimeter to include customers and guests frequenting the retail site or remote
SONICWALL TZ500 SERIES FIREWALL
Overview:
The Dell SonicWALL TZ is an affordable, yet high-performing, line of enterprise-level firewalls designed for small and medium-sized businesses, remote and branch offices, and retail point-of-sale locations. SonicWALL TZ series offer these use cases an abundance of protection features as well as advanced security services that leverage on-box and cloud-based anti-malware, antispyware, intrusion prevention system, and URL filtering. Dell’s new line of firewalls are also specced to handle encrypted attacks as it is equipped with the processing punch needed to inspect encrypted SSL connections against the most recent threats.
For this review, we will be looking at the TZ500, which is one of the models Dell targets towards SMB buyers. SonicWALL, which was acquired by Dell back in 2012, has been a market leader in advanced network security, secure remote access, email security for quite some time now, so their newest firewall is a welcomed addition to the StorageReview lab. Compared to the top offering TZ600 model, it features slightly lower throughput, less 1 GbE Copper interfaces (8 vs. 10), and doesn’t have a rear expansion slot. That being said, it certainly offers enough enterprise-grade protection and performance to halt cyberattacks all the while helping to expend to control of your company’s network. The SonicWALL TZ series also features Dell’s Global Management System (GMS), which allows administrators to deploy and manage SonicWALL TZ series firewalls from a single system at the central office.
The SonicWALL TZ500 comes equipped with optional integrated 802.11ac wireless, IPSec and SSL VPN, failover through integrated 3G/4G support, load balancing and network segmentation, all of which combine advanced networking features with advanced security to boast a pretty impressive package.
SONICWALL TZ600 SERIES FIREWALL
Overview:
The Dell SonicWALL TZ is an affordable, yet high-performing, line of enterprise-level firewalls designed for small and medium-sized businesses, remote and branch offices, and retail point-of-sale locations. SonicWALL TZ series offer these use cases an abundance of protection features as well as advanced security services that leverage on-box and cloud-based anti-malware, antispyware, intrusion prevention system, and URL filtering. Dell’s new line of firewalls are also specced to handle encrypted attacks as it is equipped with the processing punch needed to inspect encrypted SSL connections against the most recent threats.
For this review, we will be looking at the TZ500, which is one of the models Dell targets towards SMB buyers. SonicWALL, which was acquired by Dell back in 2012, has been a market leader in advanced network security, secure remote access, email security for quite some time now, so their newest firewall is a welcomed addition to the StorageReview lab. Compared to the top offering TZ600 model, it features slightly lower throughput, less 1 GbE Copper interfaces (8 vs. 10), and doesn’t have a rear expansion slot. That being said, it certainly offers enough enterprise-grade protection and performance to halt cyberattacks all the while helping to expend to control of your company’s network. The SonicWALL TZ series also features Dell’s Global Management System (GMS), which allows administrators to deploy and manage SonicWALL TZ series firewalls from a single system at the central office.
The SonicWALL TZ500 comes equipped with optional integrated 802.11ac wireless, IPSec and SSL VPN, failover through integrated 3G/4G support, load balancing and network segmentation, all of which combine advanced networking features with advanced security to boast a pretty impressive package.
CISCO ASA 5500 X WITH FIREPOWER SERVICES FIREWALL
Simplified management and lower costs :
Get visibility into and control over activity across your network. Gain insight into users, apps, devices, threats, files, and vulnerabilities.
Unified security services and task automation :
Our integrated approach to threat defense reduces capital and operating costs as well as administrative complexity by consolidating multiple security services in a single platform. Automate security tasks to increase agility and speed remediation.
Wide range of sizes and form factors :
We have the platform for you: standalone options for small and midsize businesses, ruggedized appliances for extreme environments, midsize appliances for security at the Internet edge, and high-performance appliances for enterprise data centers.
Highly effective in threat protection :
Highly effective threat prevention and a full contextual awareness of users, infrastructure, applications, and content help you detect multi vector threats and automate the defense response.
Low cost of ownership :
Effective breach detection with low total cost of ownership offers protection value. Discover, understand, and stop malware and emerging threats missed by other security layers.
CISCO FIREPOWER 2100 SERIES FIREWALL
Superior business resiliency and protection :
Gain business resiliency through superior security with sustained performance. The Firepower 2100 Series has an innovative dual multicore CPU architecture that optimizes firewall, cryptographic, and threat inspection functions simultaneously. Now, achieving security doesn’t come at the expense of network performance.
Optimized performance and port density :
Firewall throughput speeds from 2 Gbps to 8.5 Gbps. Support for sixteen (16) 1 GE ports on the low-end models. The high-end models support up to twenty-four (24) 1 GE ports or up to sixteen (16) 10 GE ports. All in a 1RU form factor.
Innovative architecture :
With its unique dual-CPU, multicore architecture, the 2100 maintains throughput performance when threat inspection is activated by routing different workloads to different chips. And enabling the threat protection features does not affect the firewall throughput.
Management to meet your needs :
Cisco Firepower NGFW is now even less time-consuming to configure and less costly to manage. You can choose from local, centralized, and cloud-based managers that fit your environment and the way you work.
CISCO FIREPOWER 4100 SERIES FIREWALL
Better security, faster speeds, smaller footprint :
Stop more threats with our fully integrated next-generation firewall (NGFW) platform. The 4100 Series’ 1-rack-unit size is ideal at the Internet edge and in high-performance environments. It shows you what’s happening on your network, detects attacks earlier so you can act faster, and reduces management complexity.
Performance and density optimized :
Key capabilities include support for 1/10/40 Gigabit Ethernet interfaces, up to 60 Gbps stateful firewall throughput, low latency, and a 1 RU form factor.
Unified management :
Reduce complexity and simplify operations. Consolidate all security functions in a single management interface. It automatically prioritizes security events, recommends tailored security protections, and tracks and contains malware infections.
CISCO FIREPOWER 9000 SERIES FIREWALL
Modular security platform for service providers :
This carrier-grade platform is ideal for data centers and other high-performance settings that require low latency and high throughput. Deliver scalable, consistent security to workloads and data flows across physical, virtual, and cloud environments. With tightly integrated services, the Firepower 9000 Series lowers costs and supports open, programmable networks.
Scalable multiservice security :
Eliminate security gaps. Integrate and provision multiple Cisco and Cisco partner security services dynamically across the network fabric. See and correlate policy, traffic, and events across multiple services.
Expandable security modules :
Flexibly scale your security performance. Meet business agility needs and enable rapid provisioning.
Carrier-grade performance :
NEBS-compliant configurations available. Elevate threat defense and network performance with low-latency, large flow handling, and orchestration of security services. Protect Evolved Programmable Network, Evolved Services Platform, and Application Centric Infrastructure architectures.
CISCO ASA 5555-X WITH FIREPOWER FIREWALL
Overview:
Meet the industry’s first adaptive, threat-focused next-generation firewall (NGFW) designed for a new era of threat and advanced malware protection. Cisco ASA with FirePOWER Services delivers integrated threat defense for the entire attack continuum - before, during, and after an attack - by combining the proven security capabilities of the Cisco ASA firewall with the industry-leading Sourcefire threat and advanced malware protection features together in a single device. The solution uniquely extends the capabilities of the Cisco ASA 5500-X Series Next-Generation Firewalls beyond what today’s NGFW solutions are capable of.
Superior Multilayered Protection :
Cisco ASA with FirePOWER Services brings distinctive threat-focused next-generation security services to the Cisco ASA 5500-X Series Next-Generation Firewalls and Cisco ASA 5585-X Adaptive Security Appliance firewall products. It provides comprehensive protection from known and advanced threats, including protection against targeted and persistent malware attacks (Figure 1). Cisco ASA with FirePOWER Services features these comprehensive capabilities:
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
CISCO ASA 5545 X WITH FIREPOWER FIREWALL
Unprecedented Network Visibility
- Cisco ASA with FirePOWER Services is centrally managed by the Cisco FireSIGHT Management Center. Management Center provides security teams with comprehensive visibility into and control over activity within the network. Such visibility includes users, devices, communication between virtual machines, vulnerabilities, threats, client-side applications, files, and websites. Holistic, actionable indications of compromise (IoCs) correlate detailed network and endpoint event information and provide further visibility into malware infections.
- Management Center also provides content awareness with malware file trajectory that aids infection scoping and root cause determination to speed time to remediation.
- Cisco Security Manager provides scalable and centralized network operations workflow management. It integrates a powerful suite of capabilities; including policy and object management, event management, reporting, and troubleshooting for Cisco ASA firewall functions. For small-scale and simple deployments, the Cisco Adaptive Security Device Manager (ASDM) is available to provide on-device, GUI-based firewall network operations management.
- Cisco’s enterprise-class management tools help administrators reduce complexity with unmatched visibility and control across NGFW deployments.
Reduced Costs and Complexity
- Cisco ASA with FirePOWER Services incorporates an integrated approach to threat defense, reducing capital and operating costs and administrative complexity. It smoothly integrates with the existing IT environment, work stream, and network fabric. The purpose-built appliance family is highly scalable, performs at up to multigigabit speeds, and provides consistent and robust security across branch, Internet edge, and data centers in both physical and virtual environments.
- With Cisco FireSIGHT Management Center, administrators can streamline operations to correlate threats, assess their impact, automatically tune security policy, and easily attribute user identities to security events. Management Center continually monitors how the network is changing over time. New threats are automatically assessed to determine which can affect your business. Response efforts are then focused on remediation, and network defenses are adapted to changing threat conditions. Critical security activities such as policy tuning are automated, saving time and effort, while protections and countermeasures are maintained in an optimal state.
- Cisco FireSIGHT Management Center integrates easily with third-party security solutions through the eStreamer API to streamline operation workflows and fit existing network fabrics.
CISCO ASA 5525-X WITH FIREPOWER FIREWALL
Overview:
Meet the industry’s first adaptive, threat-focused next-generation firewall (NGFW) designed for a new era of threat and advanced malware protection. Cisco ASA with FirePOWER Services delivers integrated threat defense for the entire attack continuum - before, during, and after an attack - by combining the proven security capabilities of the Cisco ASA firewall with the industry-leading Sourcefire threat and advanced malware protection features together in a single device. The solution uniquely extends the capabilities of the Cisco ASA 5500-X Series Next-Generation Firewalls beyond what today’s NGFW solutions are capable of.
Superior Multilayered Protection
Cisco ASA with FirePOWER Services brings distinctive threat-focused next-generation security services to the Cisco ASA 5500-X Series Next-Generation Firewalls and Cisco ASA 5585-X Adaptive Security Appliance firewall products. It provides comprehensive protection from known and advanced threats, including protection against targeted and persistent malware attacks (Figure 1). Cisco ASA with FirePOWER Services features these comprehensive capabilities:
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
CISCO ASA 5508-X WITH FIREPOWER FIREWALL
Superior Multilayered Protection
Cisco ASA with FirePOWER Services brings distinctive threat-focused next-generation security services to the Cisco ASA 5500-X Series Next-Generation Firewalls and Cisco ASA 5585-X Adaptive Security Appliance firewall products. It provides comprehensive protection from known and advanced threats, including protection against targeted and persistent malware attacks (Figure 1). Cisco ASA with FirePOWER Services features these comprehensive capabilities:
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
Unprecedented Network Visibility
Cisco ASA with FirePOWER Services is centrally managed by the Cisco FireSIGHT Management Center. Management Center provides security teams with comprehensive visibility into and control over activity within the network. Such visibility includes users, devices, communication between virtual machines, vulnerabilities, threats, client-side applications, files, and websites. Holistic, actionable indications of compromise (IoCs) correlate detailed network and endpoint event information and provide further visibility into malware infections.
CISCO ASA 5506H-X WITH FIREPOWER FIREWALL
Overview:
Meet the industry’s first adaptive, threat-focused next-generation firewall (NGFW) designed for a new era of threat and advanced malware protection. Cisco ASA with FirePOWER Services delivers integrated threat defense for the entire attack continuum - before, during, and after an attack - by combining the proven security capabilities of the Cisco ASA firewall with the industry-leading Sourcefire threat and advanced malware protection features together in a single device. The solution uniquely extends the capabilities of the Cisco ASA 5500-X Series Next-Generation Firewalls beyond what today’s NGFW solutions are capable of
Superior Multilayered Protection :
Cisco ASA with FirePOWER Services brings distinctive threat-focused next-generation security services to the Cisco ASA 5500-X Series Next-Generation Firewalls and Cisco ASA 5585-X Adaptive Security Appliance firewall products. It provides comprehensive protection from known and advanced threats, including protection against targeted and persistent malware attacks (Figure 1). Cisco ASA with FirePOWER Services features these comprehensive capabilities:
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
Reduced Costs and Complexity :
Cisco ASA with FirePOWER Services incorporates an integrated approach to threat defense, reducing capital and operating costs and administrative complexity. It smoothly integrates with the existing IT environment, work stream, and network fabric. The purpose-built appliance family is highly scalable, performs at up to multigigabit speeds, and provides consistent and robust security across branch, Internet edge, and data centers in both physical and virtual environments.
CISCO ASA 5506W X WITH FIREPOWER FIREWALL
Unprecedented Network Visibility :
Cisco ASA with FirePOWER Services is centrally managed by the Cisco FireSIGHT Management Center. Management Center provides security teams with comprehensive visibility into and control over activity within the network. Such visibility includes users, devices, communication between virtual machines, vulnerabilities, threats, client-side applications, files, and websites. Holistic, actionable indications of compromise (IoCs) correlate detailed network and endpoint event information and provide further visibility into malware infections.
Management Center also provides content awareness with malware file trajectory that aids infection scoping and root cause determination to speed time to remediation.
Cisco Security Manager provides scalable and centralized network operations workflow management. It integrates a powerful suite of capabilities; including policy and object management, event management, reporting, and troubleshooting for Cisco ASA firewall functions. For small-scale and simple deployments, the Cisco Adaptive Security Device Manager (ASDM) is available to provide on-device, GUI-based firewall network operations management.
Cisco’s enterprise-class management tools help administrators reduce complexity with unmatched visibility and control across NGFW deployments.
Reduced Costs and Complexity :
Cisco ASA with FirePOWER Services incorporates an integrated approach to threat defense, reducing capital and operating costs and administrative complexity. It smoothly integrates with the existing IT environment, work stream, and network fabric. The purpose-built appliance family is highly scalable, performs at up to multigigabit speeds, and provides consistent and robust security across branch, Internet edge, and data centers in both physical and virtual environments.
With Cisco FireSIGHT Management Center, administrators can streamline operations to correlate threats, assess their impact, automatically tune security policy, and easily attribute user identities to security events. Management Center continually monitors how the network is changing over time. New threats are automatically assessed to determine which can affect your business. Response efforts are then focused on remediation, and network defenses are adapted to changing threat conditions. Critical security activities such as policy tuning are automated, saving time and effort, while protections and countermeasures are maintained in an optimal state.
Cisco FireSIGHT Management Center integrates easily with third-party security solutions through the eStreamer API to streamline operation workflows and fit existing network fabrics.
CISCO ASA 5506-X WITH FIREPOWER FIREWALL
Overview:
Meet the industry’s first adaptive, threat-focused next-generation firewall (NGFW) designed for a new era of threat and advanced malware protection. Cisco ASA with FirePOWER Services delivers integrated threat defense for the entire attack continuum - before, during, and after an attack - by combining the proven security capabilities of the Cisco ASA firewall with the industry-leading Sourcefire threat and advanced malware protection features together in a single device. The solution uniquely extends the capabilities of the Cisco ASA 5500-X Series Next-Generation Firewalls beyond what today’s NGFW solutions are capable of
Superior Multilayered Protection :
Cisco ASA with FirePOWER Services brings distinctive threat-focused next-generation security services to the Cisco ASA 5500-X Series Next-Generation Firewalls and Cisco ASA 5585-X Adaptive Security Appliance firewall products. It provides comprehensive protection from known and advanced threats, including protection against targeted and persistent malware attacks (Figure 1). Cisco ASA with FirePOWER Services features these comprehensive capabilities:
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
Reduced Costs and Complexity :
Cisco ASA with FirePOWER Services incorporates an integrated approach to threat defense, reducing capital and operating costs and administrative complexity. It smoothly integrates with the existing IT environment, work stream, and network fabric. The purpose-built appliance family is highly scalable, performs at up to multigigabit speeds, and provides consistent and robust security across branch, Internet edge, and data centers in both physical and virtual environments.
CISCO FIREPOWER 2110 SECURITY FIREWALL
Superior business resiliency and protection :
Gain business resiliency through superior security with sustained performance. The Firepower 2100 Series has an innovative dual multicore CPU architecture that optimizes firewall, cryptographic, and threat inspection functions simultaneously. Now, achieving security doesn’t come at the expense of network performance.
Optimized performance and port density :
Firewall throughput speeds from 2 Gbps to 8.5 Gbps. Support for sixteen (16) 1 GE ports on the low-end models. The high-end models support up to twenty-four (24) 1 GE ports or up to sixteen (16) 10 GE ports. All in a 1RU form factor.
Innovative architecture :
With its unique dual-CPU, multicore architecture, the 2100 maintains throughput performance when threat inspection is activated by routing different workloads to different chips. And enabling the threat protection features does not affect the firewall throughput.
Integration adds value :
Further strengthen your defenses. Share intelligence, context, and policy controls by integration with third-party and other Cisco security solutions. Enable automatic device quarantining and rapid threat containment with Cisco ISE.
SONICWALL NSV 100 FIREWALL
Features :
SonicOS Platform The SonicOS architecture is at the core of every SonicWall physical and virtual firewall including the NSv and NSa Series, SuperMassive Series and TZ Series. Refer to the SonicWall SonicOS Platform datasheet for the complete list of features and capabilities. Automated breach prevention NSv delivers complete advanced threat protection, including high-performance intrusion and malware prevention, and cloud-based sandboxing with SonicWall’s RTDMI technology
Zone protection :
NSv strengthens internal security by enabling segmentation of the network into multiple security zones, with intrusion prevention service keeping threats from propagating across the zone boundaries. Creating and applying access rules and NAT policies to traffic passing through the various interfaces, it can allow or deny internal or external network access based on various criteria.
Secure communication :
NSv ensures the data exchange between groups of virtual machines is done securely, including isolation, confidentiality, integrity, and information flow control within these networks via the use of segmentation.
Data confidentiality :
NSv blocks information theft and illegitimate access to protected data and services.
SONICWALL SONICWAVE 432E FIREWALL
Overview:
Superior user experience
SonicWave APs take advantage of the capabilities in 802.11ac Wave 2 plus features such as band steering and a built-in 2.5 GbE port to deliver highspeed wireless performance. Other features, including 4x4 MU-MIMO and beamforming, improve performance in higher density environments when using bandwidth-intensive applications such as HD multimedia, and cloud and mobile apps.
Each SonicWave access point includes three radios. One operates in the less crowded 5 GHz frequency band, reducing interference from other devices while strengthening signal reliability. Another operates in the 2.4 GHz band to support legacy 802.11b/g/n clients. The third radio is dedicated to security and performs rogue AP detection, passive scanning and packet capturing. With four transmitting and four receiving antennas plus support for 4x4 MU-MIMO, SonicWave APs are engineered to optimize signal quality, range and reliability for wireless devices including Wave 2-enabled clients.
For organizations with a substantial long-term investment in 802.11n, the SonicWALL SonicPoint N2 features an enterprise wireless chipset, dual radios, high-speed performance and all the advantages that SonicWALL Wireless Network Security solutions offer.
Comprehensive threat prevention :
SonicWall firewalls scan all wireless traffic coming into and going out of the network using deep packet inspection technology and then remove harmful threats such as malware and intrusions, even over SSL/ TLS encrypted connections. Other security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection provide added layers of protection. The Wireless Network Security solution also integrates additional security-related features including wireless intrusion detection and prevention, virtual access point segmentation, wireless guest services, RF monitoring and wireless packet capture.
SONICWALL SONICWAVE 432I FIREWALL
Overview:
Superior user experience :
SonicWave APs take advantage of the capabilities in 802.11ac Wave 2 plus features such as band steering and a built-in 2.5 GbE port to deliver highspeed wireless performance. Other features, including 4x4 MU-MIMO and beamforming, improve performance in higher density environments when using bandwidth-intensive applications such as HD multimedia, and cloud and mobile apps.
Each SonicWave access point includes three radios. One operates in the less crowded 5 GHz frequency band, reducing interference from other devices while strengthening signal reliability. Another operates in the 2.4 GHz band to support legacy 802.11b/g/n clients. The third radio is dedicated to security and performs rogue AP detection, passive scanning and packet capturing. With four transmitting and four receiving antennas plus support for 4x4 MU-MIMO, SonicWave APs are engineered to optimize signal quality, range and reliability for wireless devices including Wave 2-enabled clients.
For organizations with a substantial long-term investment in 802.11n, the SonicWALL SonicPoint N2 features an enterprise wireless chipset, dual radios, high-speed performance and all the advantages that SonicWALL Wireless Network Security solutions offer.
Comprehensive threat prevention :
SonicWall firewalls scan all wireless traffic coming into and going out of the network using deep packet inspection technology and then remove harmful threats such as malware and intrusions, even over SSL/ TLS encrypted connections. Other security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection provide added layers of protection. The Wireless Network Security solution also integrates additional security-related features including wireless intrusion detection and prevention, virtual access point segmentation, wireless guest services, RF monitoring and wireless packet capture.
SONICWALL SONICWAVE 432O FIREWALL
Overview:
Superior user experience :
SonicWave APs take advantage of the capabilities in 802.11ac Wave 2 plus features such as band steering and a built-in 2.5 GbE port to deliver highspeed wireless performance. Other features, including 4x4 MU-MIMO and beamforming, improve performance in higher density environments when using bandwidth-intensive applications such as HD multimedia, and cloud and mobile apps.
Each SonicWave access point includes three radios. One operates in the less crowded 5 GHz frequency band, reducing interference from other devices while strengthening signal reliability. Another operates in the 2.4 GHz band to support legacy 802.11b/g/n clients. The third radio is dedicated to security and performs rogue AP detection, passive scanning and packet capturing. With four transmitting and four receiving antennas plus support for 4x4 MU-MIMO, SonicWave APs are engineered to optimize signal quality, range and reliability for wireless devices including Wave 2-enabled clients.
For organizations with a substantial long-term investment in 802.11n, the SonicWALL SonicPoint N2 features an enterprise wireless chipset, dual radios, high-speed performance and all the advantages that SonicWALL Wireless Network Security solutions offer.
Comprehensive threat prevention :
SonicWall firewalls scan all wireless traffic coming into and going out of the network using deep packet inspection technology and then remove harmful threats such as malware and intrusions, even over SSL/ TLS encrypted connections. Other security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection provide added layers of protection. The Wireless Network Security solution also integrates additional security-related features including wireless intrusion detection and prevention, virtual access point segmentation, wireless guest services, RF monitoring and wireless packet capture.
SONICWALL SONICPOINT ACE FIREWALL
SonicWall wireless firewalling :
When a wireless device uses a SonicWall SonicPoint ACe wireless access point to communicate with a wireless device on anothersubnet or on a completely different network, traffic between the devices is forced to traverse the SonicWall network security appliance. This traversal enables security services to be enforced by SonicOS. Standard practice for wireless firewalling (where one wireless client is communicating with another) bypasses many of the critical security services. The following illustration shows the standard practice for wireless firewalling.
Deployment requirements :
SonicOS firmware
• SonicWall SonicPoint ACe access points are centrally managed by SonicWall network security appliances running the following versions of SonicOS:
• SonicOS 5.9.1.6 or a higher 5.9 release
• SonicOS 6.2.5.1 or higher
Power source :
• Use the supplied power adaptor or an 802.3at compliant PoE injector or a PoE switch capable of providing 25 watts of power to each SonicPoint ACe.
Internet connectivity
• An active Internet connection is required for your firewall to download the latest SonicPoint firmware.
Gigabit Ethernet connectivity
• 802.11ac wireless hardware requires more bandwidth than a single (or even dual) 10/100 Ethernet connection can handle. Gigabit Ethernet connectivity between the WLAN and the LAN is required to take full advantage of 802.11ac speed.
SONICWALL SONICPOINT ACI FIREWALL
FIREWALLS :
SonicWall next-generation firewalls ensure that every byte of every packet coming into and going out of your network is inspected while maintaining high performance and low latency. By leveraging the SonicWall Capture Threat Network, we deliver superior protection for today and tomorrow.
Wireless Network Security :
Build a high-speed wireless network security solution that safeguards your wireless traffic from threats and delivers wired-like network security and performance.
Security Subscriptions :
Protect your organization from advanced security threats, gain greater security control, enhance productivity and lower costs with SonicWall network security services and add-ons to our firewall hardware.
WAN Acceleration :
Eliminate performance bottlenecks from data and file sharing applications and give users LAN-like application performance over your WAN by optimizing the bandwidth you already have.
Cloud App Security :
SonicWall Cloud App Security is a cloud service that provides CASB-like functionality, delivering real-time discovery, visibility and control of cloud application usage on the network.
SONICWALL SONICPOINT N2 FIREWALL
Overview:
Build a secure wireless network that safeguards your wireless traffic from threats and optimizes performance, with the SonicPoint Wireless Security Access Point Series. Combine SonicPoint Series 802.11ac wireless access points with industry-leading SonicWall firewalls to create a wireless network security solution that delivers wired-like network security and performance.
GET FAST PERFORMANCE
SonicPoint Series wireless access points give you fast wireless access with enhanced signal quality and reliability. Take advantage of the capabilities in 802.11ac to achieve gigabit wireless performance. With support for IEEE 802.11a/b/g/n/ac standards, the SonicPoint Series enables your organization to use apps such as video and voice in higher density environments.
SIMPLIFY DEPLOYMENT AND MANAGEMENT
SonicPoints are simple to deploy into your new or existing network. SonicWall firewalls have a built-in wireless controller that automatically detects and configures SonicPoints across your network, easing setup. SonicPoints integrate tightly with SonicWall firewalls to offer a single pane of glass for wireless management and monitoring.
CYBEROAM CR500ING XP FIREWALL
Overview:
The mobilization of workforce has led to demand for anytime-anywhere access to network resources. This, along with increasing number of users like customers and partners connecting to an enterprise network from outside, and trends like rise in number of network users and devices, application explosion, virtualization, and more are leading to loss of security controls for enterprises over their networks. Cyberoam Next-Generation Firewalls (NGFW) with Layer 8 Identity-based technology offer actionable intelligence and controls to enterprises that allow complete security controls over L2-L8 for their future-ready security. Cyberoam’s Human Layer 8 acts like a standard abstract layer that binds with real Layers 2-7, enabling organizations to regain lost security controls.
Cyberoam CR500iNG-XP offers inline application inspection and control, website filtering, HTTPS inspection, Intrusion Prevention System, VPN (IPSec and SSL) and granular bandwidth controls. Additional security features like WAF, Gateway Anti- Virus, Anti-Spam are also available. The FleXi Ports (XP) available in CR500iNG-XP appliances offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance.
Cyberoam security appliances offer high performance, assured Security, Connectivity and Productivity and an Extensible Security Architecture (ESA) for future-ready security in enterprises.
CYBEROAM CR750ING XP FIREWALL
Overview:
The mobilization of workforce has led to demand for anytime-anywhere access to network resources. This, along with increasing number of users like customers and partners connecting to an enterprise network from outside, and trends like rise in number of network users and devices, application explosion, virtualization, and more are leading to loss of security controls for enterprises over their networks. Cyberoam Next-Generation Firewalls (NGFW) with Layer 8 Identity-based technology offer actionable intelligence and controls to enterprises that allow complete security controls over L2- L8 for their future-ready security. Cyberoam’s Human Layer 8 acts like a standard abstract layer that binds with real Layers 2-7, enabling organizations to regain lost security controls.
Cyberoam CR750iNG-XP offers inline application inspection and control, website filtering, HTTPS inspection, Intrusion Prevention System, VPN (IPSec and SSL) and granular bandwidth controls. Additional security features like WAF, Gateway AntiVirus, Anti-Spam are also available. The FleXi Ports (XP) available in CR750iNG-XP appliances offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance.
CYBEROAM CR1000ING XP FIREWALL
Overview:
The mobilization of workforce has led to demand for anytime-anywhere access to network resources. This, along with increasing number of users like customers and partners connecting to an enterprise network from outside, and trends like rise in number of network users and devices, application explosion, virtualization, and more are leading to loss of security controls for enterprises over their networks. Cyberoam Next-Generation Firewalls (NGFW) with Layer 8 Identity-based technology offer actionable intelligence and controls to enterprises that allow complete security controls over L2-L8 for their future-ready security. Cyberoam’s Human Layer 8 acts like a standard abstract layer that binds with real Layers 2-7, enabling organizations to regain lost security controls.
Cyberoam CR1000iNG-XP offers inline application inspection and control, website filtering, HTTPS inspection, Intrusion Prevention System, VPN (IPSec and SSL) and granular bandwidth controls. Additional security features like WAF, Gateway Anti- Virus, Anti-Spam are also available. The FleXi Ports (XP) available in CR1000iNG-XP appliances offer flexible network connectivity with I/O slots that allow additional Copper 1G, Fiber 1G/10G ports on the same security appliance.
Cyberoam security appliances offer high performance, assured Security, Connectivity and Productivity and an Extensible Security Architecture (ESA) for future-ready security in enterprises.
CYBEROAM CR1500ING XP FIREWALL
Overview:
The mobilization of workforce has led to demand for anytime-anywhere access to network resources. This, along with increasing number of users like customers and partners connecting to an enterprise network from outside, and trends like rise in number of network users and devices, application explosion, virtualization, and more are leading to loss of security controls for enterprises over their networks. Cyberoam Next-Generation Firewalls (NGFW) with Layer 8 Identity-based technology offer actionable intelligence and controls to enterprises that allow complete security controls over L2- L8 for their future-ready security. Cyberoam’s Human Layer 8 acts like a standard abstract layer that binds with real Layers 2-7, enabling organizations to regain lost security controls.
Cyberoam CR1500iNG-XP offers inline application inspection and control, website filtering, HTTPS inspection, Intrusion Prevention System, VPN (IPSec and SSL) and granular bandwidth controls. Additional security features like WAF, Gateway Anti- Virus, Anti-Spam are also available. The FleXi Ports (XP) available in CR1500iNG-XP appliances offer flexible network connectivity with I/O slots that allow additional Copper 1G, Fiber 1G/10G ports on the same security appliance.
Cyberoam security appliances offer high performance, assured Security, Connectivity and Productivity and an Extensible Security Architecture (ESA) for future-ready security in enterprises.
CYBEROAM CR2500ING XP FIREWALL
Overview:
The mobilization of workforce has led to demand for anytime-anywhere access to network resources. This, along with increasing number of users like customers and partners connecting to an enterprise network from outside, and trends like rise in number of network users and devices, application explosion, virtualization, and more are leading to loss of security controls for enterprises over their networks. Cyberoam Next-Generation Firewalls (NGFW) with Layer 8 Identity-based technology offer actionable intelligence and controls to enterprises that allow complete security controls over L2- L8 for their future-ready security. Cyberoam’s Human Layer 8 acts like a standard abstract layer that binds with real Layers 2-7, enabling organizations to regain lost security controls.
Cyberoam CR1500iNG-XP offers inline application inspection and control, website filtering, HTTPS inspection, Intrusion Prevention System, VPN (IPSec and SSL) and granular bandwidth controls. Additional security features like WAF, Gateway Anti- Virus, Anti-Spam are also available. The FleXi Ports (XP) available in CR1500iNG-XP appliances offer flexible network connectivity with I/O slots that allow additional Copper 1G, Fiber 1G/10G ports on the same security appliance.
Cyberoam security appliances offer high performance, assured Security, Connectivity and Productivity and an Extensible Security Architecture (ESA) for future-ready security in enterprises.
CYBEROAM 8-PORT 1 GBE COPPER MODULE FIREWALL
Overview:
Cyberoam FleXi Ports (XP) are available in Cyberoam’s NG series FleXi Port security appliances (UTM, Next Generation Firewalls) starting CR200iNG-XP appliance model. As new technologies enter organizational networks, the limited I/O interfaces in security appliances result in connectivity options becoming a bottleneck in network upgrades. Organizations are either forced to design their networks around their existing security appliance or spend huge amount as security cost to adopt new connectivity options. Cyberoam’s FleXi Ports offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance, allowing organizations to upgrade to new technologies easily and cost-effectively, making them future-ready.The FleXi Ports consolidate number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced operational costs and ensure investment protection in future for organizations.
Business Benefits
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
CYBEROAM 4 PORT 1 GBE COPPER MODULE FIREWALL
Overview:
Cyberoam FleXi Ports (XP) are available in Cyberoam’s NG series FleXi Port security appliances (UTM, Next Generation Firewalls) starting CR200iNG-XP appliance model. As new technologies enter organizational networks, the limited I/O interfaces in security appliances result in connectivity options becoming a bottleneck in network upgrades. Organizations are either forced to design their networks around their existing security appliance or spend huge amount as security cost to adopt new connectivity options. Cyberoam’s FleXi Ports offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance, allowing organizations to upgrade to new technologies easily and cost-effectively, making them future-ready.The FleXi Ports consolidate number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced operational costs and ensure investment protection in future for organizations.
Business Benefits
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
CYBEROAM 4 PORT 10 GBE FIBER MODULE FIREWALL
Overview:
Cyberoam FleXi Ports (XP) are available in Cyberoam’s NG series FleXi Port security appliances (UTM, Next Generation Firewalls) starting CR200iNG-XP appliance model. As new technologies enter organizational networks, the limited I/O interfaces in security appliances result in connectivity options becoming a bottleneck in network upgrades. Organizations are either forced to design their networks around their existing security appliance or spend huge amount as security cost to adopt new connectivity options. Cyberoam’s FleXi Ports offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance, allowing organizations to upgrade to new technologies easily and cost-effectively, making them future-ready.The FleXi Ports consolidate number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced operational costs and ensure investment protection in future for organizations.
Business Benefits
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
CYBEROAM CR2500ING FIREWALL
Overview:
The Cyberoam CR2500iNG UTM Firewall offers Next-Generation Firewall (NGFW) capabilities with high performance. The Cyberoam CR2500iNG UTM Firewall offers inline application inspection and control, HTTPS inspection, Intrusion Prevention System, malware protection, secure remote access via VPN (IPSec and SSL) and granular bandwidth controls. The inline Layer 8 Identity-based controls with on-appliance reporting offer complete control & real-time visibility over user and network activities.
Features
- 14x10/100/1000 Ethernet ports
- 4x1GbE SFP(Mini GBIC) Ports
- 2 x 10GbE SFP(Mini GBIC) Ports
- 36000 Mbps Firewall Throughput
- 4000 Mbps UTM Throughput
Based on best-in-class hardware along with software to match, the NG series enables unprecedented throughput speeds for future-ready security in large enterprise networks. The Cyberoam NG series for large enterprises offer assured Security, Connectivity and Productivity. Its Extensible Security Architecture(ESA) supports feature enhancements that can be developed rapidly and deployed with minimum efforts, offering future-ready security to organisations.
CYBEROAM CR10ING FIREWALL
Overview:
Cyberoam FleXi Ports (XP) are available in Cyberoam’s NG series FleXi Port security appliances (UTM, Next Generation Firewalls) starting CR200iNG-XP appliance model. As new technologies enter organizational networks, the limited I/O interfaces in security appliances result in connectivity options becoming a bottleneck in network upgrades. Organizations are either forced to design their networks around their existing security appliance or spend huge amount as security cost to adopt new connectivity options. Cyberoam’s FleXi Ports offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance, allowing organizations to upgrade to new technologies easily and cost-effectively, making them future-ready.The FleXi Ports consolidate number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced operational costs and ensure investment protection in future for organizations.
Business Benefits
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
CYBEROAM CR10WING FIREWALL
Powerful Hardware
The NG series appliances come with a powerful hardware consisting of Gigahertz processors for nano second security processing along with Gigabit Ethernet ports and high port density. A complete overhaul of the appliance design has resulted into an unmatched performance gain with next-generation memory and more storage capacity.
The all new Firmware CyberoamOS
The NG series appliances are based on CyberoamOS– the most intelligent and powerful Cyberoam firmware till date. The new firmware tightly integrates with the hardware for network and crypto acceleration to deliver high performance. The CyberoamOS also extracts the highest level of performance from a multi-core platform, along with offering minimum latency and improved processing speed with use of optimized Interrupt Rates and Fast Path technology. Its next-generation security features offer protection against newly evolving threats.
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features and performance required for future networks. The NG series for SOHO offer “the fastest UTMs made for SMBs” to small offices. The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR15ING FIREWALL
Powerful Hardware
The NG series appliances come with a powerful hardware consisting of Gigahertz processors for nano second security processing along with Gigabit Ethernet ports and high port density. A complete overhaul of the appliance design has resulted into an unmatched performance gain with next-generation memory and more storage capacity.
The all new Firmware CyberoamOS
The NG series appliances are based on CyberoamOS– the most intelligent and powerful Cyberoam firmware till date. The new firmware tightly integrates with the hardware for network and crypto acceleration to deliver high performance. The CyberoamOS also extracts the highest level of performance from a multi-core platform, along with offering minimum latency and improved processing speed with use of optimized Interrupt Rates and Fast Path technology. Its next-generation security features offer protection against newly evolving threats.
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features and performance required for future networks. The NG series for SOHO offer “the fastest UTMs made for SMBs” to small offices. The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR15WING FIREWALL
Overview:
CR15wiNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices with high performance security over WLAN. CR15wiNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance . It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
Cyberoam's Layer 8 technology that treats user-identity as the 8th Layer or the HUMAN layer in the protocol stack, works even in WLAN environments, to allow Identity-based security policies in dynamic IP environment.
CYBEROAM CR25ING FIREWALL
Overview:
CR25iNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices with high performance security over WLAN. CR25iNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance . It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
Cyberoam's Layer 8 technology that treats user-identity as the 8th Layer or the HUMAN layer in the protocol stack, works even in WLAN environments, to allow Identity-based security policies in dynamic IP environment.
CYBEROAM CR25WING FIREWALL
Overview:
CR25wiNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices, with high performance security over WLAN. CR25wiNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance. It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR35ING FIREWALL
Overview:
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features and performance required for future networks. The NG series for SOHO offer “the fastest UTMs made for SMBs” to small offices. The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
With Cyberoam NG series, businesses get assured Security, Connectivity and Productivity. The Layer 8 Technology treats User-Identity as the 8th Layer or the HUMAN layer in the protocol stack. It attaches User-Identity to security, which adds speed to an organization’s security by offering instant visibility into the source of attacks by username rather than only IP address. Cyberoam’s Extensible Security Architecture (ESA) supports feature enhancements that can be developed rapidly and deployed with minimum efforts, offering future-ready security to organizations.
CYBEROAM CR35WING FIREWALL
Overview:
CR35wiNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices, with high performance security over WLAN. CR35wiNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance. It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR50ING FIREWALL
Overview:
CR50iNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices, with high performance security over WLAN. CR50iNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance. It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR100ING FIREWALL
Overview:
CR100iNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices, with high performance security over WLAN. CR100iNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance. It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR200ING FIREWALL
Overview:
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features along with performance required for future networks. The NG series for SMEs are the “fastest UTMs” made for this segment. The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security to SMEs. With Cyberoam NG series, businesses get assured Security, Connectivity and Productivity. The Layer 8 Technology treats User-Identity as the 8th Layer or the HUMAN layer in the protocol stack. It attaches User-Identity to security, which adds speed to an organization’s security by offering instant visibility into the source of attacks by username rather than only IP address. Cyberoam’s Extensible Security Architecture (ESA) supports feature enhancements that can be developed rapidly and deployed with minimum efforts, offering future-ready security to organizations.
CYBEROAM CR300ING FIREWALL
Overview:
CR300iNG is the Next-Generation Unified Threat Management appliance with Wi-Fi access points that offer “the fastest UTMs made for SMBs” to small offices, with high performance security over WLAN. CR300iNG appliances come with 3x3 MIMO technology that greatly enhances wireless range and performance. It supports 802.11n/b/g wireless standards. Combined with security over wired networks offered by its range of UTM appliances, Cyberoam enables organizations to overcome the physical limitations of securely accessing network resources and offers more user flexibility, user productivity and lower network ownership costs.
The best-in-class hardware along with software to match, enables the NG series to offer unmatched throughput speeds, compared to any other UTM appliance in this market segment. This assures support for future IT trends in organizations like high-speed Internet and rising number of devices in organizations – offering future-ready security for small office networks.
CYBEROAM CR200ING-XP FIREWALL
Overview:
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features along with performance required for future networks. The NG series for SMEs are the “fastest UTMs” made for this segment, offering unmatched throughput speeds compared to any other UTM appliance in this market. The FleXi Ports (XP) available in CR200iNG-XP UTM appliances offer flexible network connectivity with I/O slot that allows additional Copper/Fiber 1G/10G ports on the same security appliance. To SMEs who want to shift to Fiber 1GbE/10GbE connectivity, FleXi Ports give freedom from forced purchase of higher end security appliances to get desired I/O interfaces. FleXi Ports consolidate the number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced OPEX.
With Cyberoam NG series, businesses get assured Security, Connectivity and Productivity. The Layer 8 Technology treats User-Identity as the 8th Layer or the HUMAN layer in the protocol stack. It attaches UserIdentity to security, which adds speed to an organization’s security by offering instant visibility into the source of attacks by username rather than only IP address. Cyberoam’s Extensible Security Architecture ( ESA) suppor t s f eat ur e enhancements that can be developed rapidly and deployed with minimum efforts, offering future-ready security to organizations.
CYBEROAM CR300ING-XP FIREWALL
Overview:
Cyberoam NG series of Unified Threat Management appliances are the Next-Generation network security appliances that include UTM security features along with performance required for future networks. The NG series for SMEs are the “fastest UTMs” made for this segment, offering unmatched throughput speeds compared to any other UTM appliance in this market. The FleXi Ports (XP) available in CR300iNG-XP UTM appliances offer flexible network connectivity with I/O slot that allows additional Copper/Fiber 1G/10G ports on the same security appliance. To SMEs who want to shift to Fiber 1GbE/10GbE connectivity, FleXi Ports give freedom from forced purchase of higher end security appliances to get desired I/O interfaces. FleXi Ports consolidate the number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced OPEX.
With Cyberoam NG series, businesses get assured Security, Connectivity and Productivity. The Layer 8 Technology treats User-Identity as the 8th Layer or the HUMAN layer in the protocol stack. It attaches UserIdentity to security, which adds speed to an organization’s security by offering instant visibility into the source of attacks by username rather than only IP address. Cyberoam’s Extensible Security Architecture ( ESA) suppor t s f eat ur e enhancements that can be developed rapidly and deployed with minimum efforts, offering future-ready security to organizations
CYBEROAM 8 PORT 1 GBE FIBER MODULE FIREWALL
Overview:
Cyberoam FleXi Ports (XP) are available in Cyberoam’s NG series FleXi Port security appliances (UTM, Next Generation Firewalls) starting CR200iNG-XP appliance model. As new technologies enter organizational networks, the limited I/O interfaces in security appliances result in connectivity options becoming a bottleneck in network upgrades. Organizations are either forced to design their networks around their existing security appliance or spend huge amount as security cost to adopt new connectivity options. Cyberoam’s FleXi Ports offer flexible network connectivity with I/O slots that allow additional Copper/Fiber 1G/10G ports on the same security appliance, allowing organizations to upgrade to new technologies easily and cost-effectively, making them future-ready.The FleXi Ports consolidate number of devices in a network, offering benefits of power efficiency, reduced network complexity and reduced operational costs and ensure investment protection in future for organizations.
Business Benefits
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
CRIV 1C SUPPORT UPTO 1 VCPU
Cyberoam virtual network security appliance range includes :
- CRiV-2C (Support upto 2 vCPU)
- CRiV-4C (Support upto 4 vCPU)
- CRiV-8C (Support upto 8 vCPU)
- CRiV-12C (Support upto 12 vCPU)
The virtual platforms supported by Cyberoam virtual network security appliances:
- VMware ESX/ESXi
- VMware Workstation
- VMware Player
- Hyper-V
- KVM
- Citrix XenServer
CRIV-2C SUPPORT UPTO 2 VCPU
Cyberoam virtual network security appliance range includes :
- CRiV-2C (Support upto 2 vCPU)
- CRiV-4C (Support upto 4 vCPU)
- CRiV-8C (Support upto 8 vCPU)
- CRiV-12C (Support upto 12 vCPU)
The virtual platforms supported by Cyberoam virtual network security appliances:
- VMware ESX/ESXi
- VMware Workstation
- VMware Player
- Hyper-V
- KVM
- Citrix XenServer
WATCHGUARD FIREBOX T15 FIREWALL
Overview
WatchGuard Firebox T15 delivers complete enterprise-level network security for small office/home office and retail environments. Offering optional web filtering, intrusion prevention, antivirus and more. It can be used as a stand-alone solution or centrally managed from corporate headquarters. Flexible management tools and WatchGuard’s RapidDeploy technology enable administrators to quickly set up the Firebox T15 at remote locations so businesses can ensure that they protect where they connect. Firebox T15 provides 400 Mbps firewall throughput and three 1-Gigabit Ethernet ports. WatchGuard Dimension provides visibility into network activity and security events at no additional cost. Wireless models are available.
Details
The WatchGuard Firebox T Series appliances bring enterprise-level network security to the small office/branch office and small retail environments that matches the reality of today's distributed work style. They can be used as a stand-alone solution or centrally managed from corporate headquarters. Flexible management tools and WatchGuard's RapidDeploy technology enable administrators to quickly set up a T Series device at remote locations so businesses can ensure that they protect everywhere they connect. T Series appliances sustain up to 1.2 Gbps firewall throughput and come in wired and wireless versions. WatchGuard Dimension, which provides real-time visibility into network activity and security events, is included at no additional cost.
- Ideal for Small office/home office and small retail environments
- Recommended User Count: 5
- Firewall Throughput: 400 Mbps
- VPN Throughput: 150 Mbps
- UTM Throughput: 90 Mbps
- Concurrent Sessions: 100,000
- 1 Year Standard Support
WATCHGUARD FIREBOX T35 FIREWALL
TOTAL NETWORK PROTECTION
Small businesses and remote locations have long been thought of as soft targets for attackers. WatchGuard Firebox T35 and T55 tabletop appliances bring enterprise-level network security to those small office/branch office and small retail environments that matches the reality of today’s distributed work style. Our unique product architecture enables smaller businesses to leverage best-in-class security services – from URL filtering and intrusion prevention to application control and data loss prevention – minus the cost and complexity of managing multiple single-point solutions.
QUICK AND SIMPLE DEPLOYMENT
Cloud-based RapidDeploy technology, a configuration and deployment tool that comes standard with WatchGuard Firebox appliances, enables IT staff to create and store configuration data in the cloud – public or private – and have a new appliance directly shipped to its destination. Once the device arrives, it can connect to the cloud for a secure download of its configuration settings, saving staff travel time and money. This technology is particularly advantageous for large distributed enterprises where managing a multitude of devices efficiently across multiple locations and geographies is critical.
EASY TO MANAGE AND UNDERSTAND
Firebox T Series appliances are not only easy to initially configure and deploy, they are also designed with an emphasis on centralized management, making ongoing policy and network management simple and straightforward. WatchGuard Dimension, which is included with purchase, provides a suite of big data visibility and reporting tools that instantly identify and distill key network security threats, issues and trends so you can take immediate preventive or corrective action. Security is complex, running it doesn’t have to be.
FEATURES & BENEFITS
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
WATCHGUARD FIREBOX T55 FIREWALL
TOTAL NETWORK PROTECTION
Small businesses and remote locations have long been thought of as soft targets for attackers. WatchGuard Firebox T35 and T55 tabletop appliances bring enterprise-level network security to those small office/branch office and small retail environments that matches the reality of today’s distributed work style. Our unique product architecture enables smaller businesses to leverage best-in-class security services – from URL filtering and intrusion prevention to application control and data loss prevention – minus the cost and complexity of managing multiple single-point solutions.
QUICK AND SIMPLE DEPLOYMENT
Cloud-based RapidDeploy technology, a configuration and deployment tool that comes standard with WatchGuard Firebox appliances, enables IT staff to create and store configuration data in the cloud – public or private – and have a new appliance directly shipped to its destination. Once the device arrives, it can connect to the cloud for a secure download of its configuration settings, saving staff travel time and money. This technology is particularly advantageous for large distributed enterprises where managing a multitude of devices efficiently across multiple locations and geographies is critical.
EASY TO MANAGE AND UNDERSTAND
Firebox T Series appliances are not only easy to initially configure and deploy, they are also designed with an emphasis on centralized management, making ongoing policy and network management simple and straightforward. WatchGuard Dimension, which is included with purchase, provides a suite of big data visibility and reporting tools that instantly identify and distill key network security threats, issues and trends so you can take immediate preventive or corrective action. Security is complex, running it doesn’t have to be.
FEATURES & BENEFITS
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
WATCHGUARD FIREBOX T15 WIRELESS FIREWALL
TOTAL NETWORK PROTECTION
Small businesses and remote locations have long been thought of as soft targets for attackers. WatchGuard Firebox T35 and T55 tabletop appliances bring enterprise-level network security to those small office/branch office and small retail environments that matches the reality of today’s distributed work style. Our unique product architecture enables smaller businesses to leverage best-in-class security services – from URL filtering and intrusion prevention to application control and data loss prevention – minus the cost and complexity of managing multiple single-point solutions.
QUICK AND SIMPLE DEPLOYMENT
Cloud-based RapidDeploy technology, a configuration and deployment tool that comes standard with WatchGuard Firebox appliances, enables IT staff to create and store configuration data in the cloud – public or private – and have a new appliance directly shipped to its destination. Once the device arrives, it can connect to the cloud for a secure download of its configuration settings, saving staff travel time and money. This technology is particularly advantageous for large distributed enterprises where managing a multitude of devices efficiently across multiple locations and geographies is critical.
EASY TO MANAGE AND UNDERSTAND
Firebox T Series appliances are not only easy to initially configure and deploy, they are also designed with an emphasis on centralized management, making ongoing policy and network management simple and straightforward. WatchGuard Dimension, which is included with purchase, provides a suite of big data visibility and reporting tools that instantly identify and distill key network security threats, issues and trends so you can take immediate preventive or corrective action. Security is complex, running it doesn’t have to be.
FEATURES & BENEFITS
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
WATCHGUARD FIREBOX T55 WIRELESS FIREWALL
Overview
Small businesses and remote locations have long been thought of as soft targets for attackers. The WatchGuard T55 Firebox Firewall tabletop appliance bring enterprise-level network security to those small office/branch office and small retail environments that matches the reality of today's distributed work style.Perfect as stand-alone solutions for a small office, The WatchGuard T55 Firebox Firewall are ideal for larger organizations that want to extend easy-to-use, full UTM protection for remote workers and smaller sites. With WatchGuard Total Security Services, this appliance are small-footprint, cost-effective security powerhouses that deliver nearly every feature present in WatchGuard’s higher end UTM appliances, including all security capabilities such as ransomware protection and data loss prevention.
Key Features
- Includes a one (1) year standard support licence subscription.
- Boosts five (5) Gigabit Ethernet RJ45 LAN interfaces.
- No need to compromise protection for strong performance or vice versa.
- Support high-speed LAN backbone infrastructures and Gigabit WAN connections.
- Best-of-breed security components into one platform for stronger security at big cost savings.
- Firewall throughput up to 1Gbps and VPN throughput upto 360Mbps to keep traffic moving.
- Brings enterprise-level network security to small offices and retail environments.
- Cloud-based RapidDeploy technology taking the delay out of the firewall deployment process.
- Allows small businesses to have access to enterprise-grade security.
WATCHGUARD FIREBOX T70 WIRELESS FIREWALL
Overview:
- Get Industry-leading Performance with the Firebox T70
- Many organizations today are dependent on fast, reliable and secure Internet connectivity, but are struggling to find network security solutions that can keep up with their ever growing needs. While many rack-mount solutions can keep up with today’s fastest fiber-to-the-premises speeds, there are not currently any tabletop security appliances available that have this capability, especially when running with additional security services enabled. This makes it difficult for SMBs and distributed enterprises to harness these powerful Internet speeds with the complete UTM protection they require.
The Fastest Tabletop Available
The WatchGuard Firebox T70 is the fastest performing tabletop appliance available on the market today. The T70 is the only tabletop appliance that is capable of running full UTM services at over 1 gigabit per second, enabling you to keep up with lightning-fast fiber broadband speeds.
The WatchGuard Firebox T70 will make network slowdown concerns a thing of the past, with blazing-fast performance capable of delivering full UTM protection at over 1 gigabit per second. With the release of the WatchGuard Firebox T70 tabletop network security appliance, customers can now enjoy the fast throughput that they want, with the industry-leading security that they need. The WatchGuard T70 is also one of the only tabletop appliances available today that provides users two Power-over-Ethernet (PoE) ports enabling power to peripheral devices, such as wireless access points and security cameras.
WATCHGUARD FIREBOX M270 WIRELESS FIREWALL
Overview:
Up to 8 Gbps firewall throughput, 2.6 Gbps UTM throughput
Because smaller companies are generally less protected and easier to break into, small business has become the new big target for cyber attacks. The Firebox® M270 and M370 firewalls are specifically engineered to defend all types of small businesses against attacks that are no less fierce than those targeting larger organizations. Our unique product architecture enables SMBs to leverage best-in-class security services – from URL filtering and intrusion prevention to application control and data loss prevention - without the cost and complexity of running multiple single-point solutions. The M270 and M370 are part of WatchGuard’s award-winning Firebox security platform. The platform not only provides the most complete suite of unified security controls on the market today, it has consistently been the first to offer solutions for addressing new and evolving network threats including advanced malware and ransomware.
Blazing Fast Performance
Firebox M270 and M370 Unified Threat Management (UTM) solutions are up to 3 times faster than competing products with all security layers turned on, and up to 94 percent faster performing HTTPS inspection, according to the independent test lab Miercom. This ensures you never have to compromise network security for performance.
Quick And Simple Deployment
SMBs usually have smaller, less technical staff, which can make network expansion challenging. RapidDeploy – a powerful, cloud-based deployment and configuration tool – comes standard with WatchGuard Firebox appliances. With it, IT staff can create and store configuration data in the cloud – public or private – and have the appliance directly shipped to its destination. Once the device arrives, it can connect to the cloud for a secure download of its configuration settings, saving your staff travel time and money.
Easy To Manage And Understand
The M270 and M370 are not only easy to initially configure and deploy, they are also designed with an emphasis on centralized management, making ongoing policy and network management simple and straightforward. WatchGuard Dimension, included with purchase, provides a suite of big data visibility and reporting tools that instantly identify and distill key network security threats, issues and trends so you can take immediate preventive or corrective action. Security is complex, running it doesn’t have to be.
SonicWall TZ600 Firewall
Performance Overview:
- Security Processor: 4x 1.4 GHz
- Memory (RAM): 1 GB
- 1 GbE Copper interfaces : 10
- Expansion : Expansion Slot (Rear), 2 USB
- Firewall inspection throughput: 1.5 Gbps
- Full DPI throughput: 500 Mbps
- Application inspection throughput:1.1 Gbps
- IPS throughput : 1.1 Gbps
- Anti-malware inspection throughput : 500 Mbps
- IMIX throughput : 900 Mbps
- SSL Inspection and Decryption (DPI SSL) :200 Mbps
- VPN throughput : 1.1 Gbps
- Connections per second : 12,000
- Maximum connections (SPI) : 150,000
- Maximum connections (DPI) : 125,000
- Single Sign-On (SSO) Users : 500
- VLAN interfaces : 50
- SonicPoints supported (Maximum) : 24
VPN :
- Site-to-Site VPN Tunnels : 50
- IPSec VPN clients (Maximum) : 2 (25)
- SSL VPN licenses (Maximum) : 2 (200)
- Virtual assist bundled (Maximum) : 1 (30-day trial)
- Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
- Key exchange : Diffie Hellman Groups 1, 2, 5, 14
- Route-based VPN : RIP, OSPF
- Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
- NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
- Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware : McAfee®
- Comprehensive Anti-Spam Service : Supported
- Application Intelligence and Control : Yes
- Application Visualization : Yes
Networking:
- IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
- QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
- Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- Local user database : 150
- VoIP : Full H.323v1-5, SIP
- Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
- Certifications : VPNC, IPv6 (Phase 2)
- Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
- Common Access Card (CAC) : Supported
- High Availability : Active/Standby with stateful synchronization
Hardware:
- Form factor : Desktop
- Power Supply (W) : 36W external
- Maximum power consumption (W) : 13.4 / 17.7
- Input power : 100 to 240 VAC, 50-60 Hz, 1 A
- Total heat dissipation : 45.9 / 60.5 BTU
- Dimensions : 3.5x15x22.5cm
- Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
- WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
- Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
- MTBF (Years) : 20 / 12
- Environment : 40-105° F, 0-40° C
- Humidity : 5-95% non-condensing
Fortinet FortiGate 40F Firewall
- Firewall Throughput (1518/512/64 byte UDP): 5 / 5 / 5 Gbps
- IPsec VPN Throughput (512 byte) 1: 4.4 Gbps
- IPS Throughput (Enterprise Mix) 2: 1 Gbps
- NGFW Throughput (Enterprise Mix) 2, 4: 800 Mbps
- Threat Protection Throughput (Ent. Mix) 2, 5: 600 Mbps
- Firewall Latency: 4 µs
- Concurrent Sessions: 700,000
- New Sessions/Sec: 35,000 Firewall Policies :5,000
- Max G/W to G/W IPSEC Tunnels: 200
- Max Client to G/W IPSEC Tunnels: 250
- SSL VPN Throughput: 490 Mbps
- Concurrent SSL VPN Users (Recommended Maximum, Tunnel Mode): 200
- SSL Inspection Throughput (IPS, avg. HTTPS) 3: 310 Mbps
- Application Control Throughput (HTTP 64K) 2: 990 Mbps
- Max FortiAPs (Total / Tunnel): 10 / 5
- Max FortiSwitches: 8
- Max FortiTokens: 500
- Virtual Domains ( Default/Max): 10 / 10
- Interfaces: 5x GE RJ45
- Power Supplies: Single AC PS
- Form Factor: Desktop
Fortinet FortiGate 30E Firewall
- Firewall Throughput (1518/512/64 byte UDP): 0.95 Gbps
- IPsec VPN Throughput (512 byte) 1: 75 Mbps
- IPS Throughput (Enterprise Mix) 2: 300 Mbps
- NGFW Throughput (Enterprise Mix) 2, 4: 200 Mbps
- Threat Protection Throughput (Ent. Mix) 2, 5: 150 Mbps
- Firewall Latency: 130 µs
- Concurrent Sessions: 900,000
- New Sessions/Sec: 15000
- Firewall Policies: 5000
- Max G/W to G/W IPSEC Tunnels: 200
- Max Client to G/W IPSEC Tunnels: 250
- SSL VPN Throughput: 35 Mbps
- Concurrent SSL VPN Users (Recommended Maximum, Tunnel Mode): 100
- SSL Inspection Throughput (IPS, avg. HTTPS) 3: 125 Mbps
- Application Control Throughput (HTTP 64K) 2: 400 Mbps
- Max FortiAPs (Total / Tunnel): 2 / 2
- Max FortiSwitches: 8
- Max FortiTokens: 500
- Virtual Domains ( Default/Max): 5 / 5
- Interfaces: 5x GE RJ45
- Power Supplies: Single AC PS
- Form Factor: Desktop
- Variants: WiFi, 3G4G, LENC
SonicWall NSv 25 Firewall
- Firewall Throughput : 2.5Gbps
- UTM Throughput : 550Mbps
- IPS Throughput : 1.25Gbps
- AV Throughput : 550Mbps
- IMIX Throughput : 850Mbps
- VPN Throughput : 550Mbps
- Concurrent SPI Connections : 50,000
- Concurrent DPI Connections : 50,000
- New Connections per Second : 5,000
- SSL Inspection / Decryption : 750Mbps
SonicWall NSv 50 Firewall
- Interfaces: 4 x 2.5-GbE SFP, 4 x 2.5-GbE, 12 x 1-GbE, 1 GbE Management Console
- Management : CLI, SSH, GUI, GMS
- Nodes Supported : Unrestricted
- RAM : 2 GB
- Site-to-Site VPN Tunnels : 1,000
- Global VPN Clients (Maximum) : 50 (1,000)
- SSL VPN NetExtender Clients (Maximum) : 2 (350)
- VLAN Interfaces : 256
- SonicPoints Wireless Controller : Standard
- WWAN Failover (4G/LTE) : Standard
- Network Switch Management : Standard
- Firewall Inspection Throughput : 3.0 Gbps
- Full DPI Throughput (GAV/GAS/IPS) : 600 Mbps
- Application Inspection Throughput : 1.4 Gbps
- IPS Throughput : 1.4 Gbps
- Anti-Malware Inspection Throughput : 600 Mbps
- IMIX Throughput : 700 Mbps
- SSL DPI Throughput : 300 Mbps
- VPN Throughput : 1.5 Gbps
- Latency : 38 ?s
- Maximum SPI Connections : 1M
- Maximum DPI Connections : 500K
- Default/Maximum Connections (DPI SSL) : 12,000/13,500
- New Connections/Sec : 15,000
- Logging and Reporting : Analyzer, Local Log, Syslog
- Network Traffic Visualization : Standard
- Netflow/IPFIX Reporting : Standard
- SNMP : Standard
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, Terminal Services, Citrix
- Dynamic Routing : BGP, OSPF, RIP
Fortinet 7121F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Security Appliance
- Shape Factor: 16U Rack-mountable 8-slot chassis
- Product Description: Fortinet Fortinet 7121F-2 - security appliance - with 5 years FortiCare 24X7 Service + 5 years FortiGuard
- Processor: Fortinet FortiASIC CP9/NP7
- Threat protection: 520 Gbps
- Hard Disk: 4 TB x 4
- Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 400 Gigabit Ethernet
- Included Accessories: 4 x SR 10Gbps SFP+ transceivers
- Power Supply : AC 200-240 V (50/60 Hz)
- Power Redundancy: Yes
- Performance: IPS throughput (enterprise traffic mix): 675 Gbps ¦ NGFW throughput (enterprise traffic mix): 550 Gbps ¦ Threat protection throughput (enterprise traffic mix): 520 Gbps ¦ Firewall throughput (1518-byte UDP): 1.89 Tbps ¦ Firewall throughput (512-byte UDP): 1.88 Tbps ¦ Firewall throughput (64-byte UDP): 1.129 Tbps ¦ Firewall latency (64-byte UDP): 7.5 µs ¦ Firewall throughput: 1680 Mpps ¦ VPN throughput (512-bit IPSec): 630 Gbps ¦ VPN throughput (SSL): 13.7 Gbps ¦ SSL inspection throughput: 540 Gbps ¦ Application control throughput: 1.5 Tbps
- Capacity: Concurrent TCP sessions: 1000000000 ¦ New TCP sessions per second: 9000000 ¦ Firewall policies: 200000 ¦ Gateway to gateway IPSec VPN Tunnels: 40000 ¦ Client to gateway IPSec VPN tunnels: 260000 ¦ Concurrent SSL VPN users: 30000 ¦ SSL inspection CPS: 480000 ¦ SSL inspection concurrent sessions: 100000000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 500 ¦ Number of FortiToken devices: 20000 ¦ Number of FortiSwitches: 300
- Dimensions (WxDxH): 17.3 x 26.6 x 28.6 inches
- Weight: 203.09 kg
- Bundled Services: 5 years FortiCare 24X7 Service + 5 years FortiGuard
Fortinet 7081F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Security Appliance
- Shape Factor: 12U Rack-mountable 8-slot chassis
- Product Description: High-performance security-driven network for large enterprises and service providers.
- Processor: Fortinet FortiASIC CP9/NP7
- Threat protection: 312 Gbps
- Hard Disk: 4x 4 TB SSD (onboard storage)
- Data Link Protocol: 400 GE QSFP-DD, 100 GE QSFP28, 40 GE QSFP+, 25 GE SFP28, 10 GE SFP+
- Included Accessories: 2x Management Module, 6x hot swappable redundant PSU (2500WAC), 3x FG-7081F FAN module (for FG-7081F-DC)
- Power Supply: 2500WAC (redundant)
- Power Redundancy: Hot swappable redundant PSU
- Performance: IPv4 Firewall Throughput: 1.89 / 1.88 / 1.129 Tbps, IPv6 Firewall Throughput: 1.89 / 1.88 / 1.129 Tbps, Firewall Latency: 7.5 ?s, Firewall Throughput (Packet per Second): 1680 Mpps
- Dimensions (WxDxH): 543.9 x 440 x 675.5 mm
- Weight: 165.68 kg
- Bundled Services: FortiCare Premium and FortiGuard Enterprise Protection (or Unified Threat Protection) for various durations (1, 3, or 5 years)
Fortinet 6001F Firewall
- Brand: Fortinet
- Device Type: Network Security Appliance
- Frame Factor: 3U Rackmount 8-slot chassis
- Product Description: The FortiGate 6001F is a high-performance NGFW designed for large enterprises and service providers. It provides advanced threat protection, SSL inspection, and high-throughput for deployments at the network edge, data center, and internal segments.
- Processor: Fortinet FortiASIC CP9/NP6
- Threat Protection Throughput: 30/10/100 Gbps (default/per FPC/max)
- Hard Disk: No internal storage specified
- Data Link Protocol: Supports multiple 40/100 GE QSFP28, 1/10/25 GE SFP28, 1/10 GE SFP+, and GE RJ45 interfaces
- Included Accessories: 2x SFP+ (SR 10 GE) transceivers included
- Power Supply: 2 x DC power supplies
- Power Redundancy: Not specified
- Performance: IPS Throughput: 51/17/170 Gbps (default/per FPC/max), NGFW Throughput: 45/15/150 Gbps (default/per FPC/max)
- Dimensions (WxDxH): 5.10 x 17.25 x 26.21 inches
- Weight: 35.5 kg
- Bundled Services: The FortiGate 6001F can be purchased with various service bundles, including FortiCare Premium and FortiGuard Enterprise Protection, Unified Threat Protection (UTP), and Advanced Threat Protection
Fortinet 4800F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Security Appliance
- Shape Factor: 2U Rackmount 8-slot chassis
- Product Description: High-performance NGFW with 12x 100GE/40GE QSFP28 slots and 18x 25GE/10GE SFP28 slots
- Processor: SPU NP7 and CP9 processors
- Threat Protection throughput: 70 Gbps
- Hard Disk: N/A
- Data Link Protocol: 100GE, 40GE, 25GE, 10GE
- Included Accessories: N/A
- Power Supply: 4 AC power supplies
- Power Redundancy: N/A
- Performance: Firewall Throughput: Up to 320 Gbps, IPS Throughput: Up to 80 Gbps, VPN Throughput: Up to 140 Gbps
- New Sessions/Second (TCP): Up to 25 Million, SSL-VPN Throughput: 18 Gbps, SSL Inspection Throughput (IPS, avg. HTTPS): 63 Gbps, Application Control Throughput (HTTP 64K): 180 Gbps, Virtual Domains (Default / Maximum): 10 / 500
- Dimensions (WxDxH):6.89 x 17.13 x 26.10
- Weight: 41.2 kg
- Bundled Services: 5 years FortiCare 24X7 Service + 5 years FortiGuard
Fortinet 4400F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Security Appliance
- Shape Factor: 4 RU Rackmount 8-slot chassis
- Product Description: The Fortinet 4400F Series is a high-performance network firewall designed for security-driven networking and SD-WAN. It features a dedicated module for generating, storing, and authenticating cryptographic keys, and hardware-based security mechanisms to protect against malicious software and phishing attacks.
- Processor: SPU NP7 and CP9 processors
- Threat protection: 75 Gbps
- Hard Disk: 2x 2TB SSD (included)
- Data Link Protocol: Supports multiple GE RJ45, 25 GE SFP28 / 10 GE SFP+ / GE SFP, and 100 GE QSFP28 / 40 GE QSFP+ slots
- Included Accessories: USB Management and Console Port, 2 x GE RJ45 Management Ports, 2 x 25 GE SFP28 / 10 GE SFP+ / GE SFP High Availability Slots, 2 x 25 GE SFP28 / 10 GE SFP+ / GE SFP AUX Slots, 16 x 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots, 12 x 100 GE QSFP28 / 40 GE QSFP+ Slots
- Power Supply: AC Power Supply (2000W) and DC Power Supply (optional)
- Power Redundancy: Supports high availability configurations, including active-active and active-passive clustering
- Performance:IPsec VPN Performance: 1,310 Gbps (512 byte), NGFW Performance: 94 Gbps, Threat Protection Performance: 75 Gbps, SSL Inspection Performance: 3,86 Gbps
- Application Control Performance: 2,140 Gbps, CAPWAP Performance: 63 Gbps
- Concurrent Sessions: 210 Million (TCP), 700 Million * New Sessions/Second (TCP)
- Dimensions (WxDxH): 6.97 x 17.20 x 26.17 inches (177 x 437 x 665 mm)
- Weight: 37.1 kg
- Bundled Services: FortiGuard Services, including AI/ML-based threat protection and Zero Trust Network Access (ZTNA) enforcement.
Fortinet 4200F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Firewall
- Shape Factor: 3RU Rackmount 8-slot chassis
- Product Description: The Fortinet 4200F series delivers high performance next generation firewall (NGFW) capabilities with multiple high-speed interfaces, high-port density, and high throughput. It is ideal for deployments at the enterprise edge, hybrid data center core, and across internal segments.
- Processor: SPU NP7 and CP9 hardware accelerated
- Threat protection: 45 Gbps
- Hard Disk: 2x 2TB SSD (included in FG-4201F model)
- Data Link Protocol: Supports multiple GE RJ45, 25 GE SFP28 / 10 GE SFP+ / GE SFP, and 100 GE QSFP28 / 40 GE QSFP+ slots
- Included Accessories: 2 x GE RJ45 Management Ports, USB Port, Console Port
- Power Supply: Internal AC or DC power supplies (2 included)
- Power Redundancy: Supports redundant power supplies
- Performance: Firewall Throughput: 800 Gbps, IPS Throughput: 52 Gbps, NGFW Throughput: 47 Gbps, Threat Protection Throughput: 45 Gbps
- Dimensions (WxDxH): 17.20 x 26.17 x 5.22 inches
- Weight: 27.1 kg
- Bundled Services: Fortinet's Security-Driven Networking approach provides tight integration of the network to security, including application control, SSL inspection, and advanced threat protection
Fortinet 3700F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Firewall
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: Fortinet Fortinet 3700F - security appliance
- Processor: Fortinet FortiASIC CP9/NP7
- Threat protection: 75 Gbps
- Data Link Protocol:Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 50 Gigabit Ethernet, 200 Gigabit Ethernet, 400 Gigabit Ethernet
- Performance: IPS throughput (enterprise traffic mix): 86 Gbps ¦ NGFW throughput (enterprise traffic mix): 80 Gbps ¦ Threat protection throughput (enterprise traffic mix): 75 Gbps ¦ Firewall throughput (1518-byte UDP): 589Gbps ¦ Firewall throughput (512-byte UDP): 589Gbps ¦ Firewall throughput (64-byte UDP): 420 Gbps ¦ IPv6 firewall throughput (1518-byte UDP): 589Gbps ¦ IPv6 firewall throughput (512-byte UDP): 589Gbps ¦ IPv6 firewall throughput (64-byte UDP): 420 Gbps ¦ Firewall latency (64-byte UDP): 3.56µs ¦ Firewall throughput: 630 Mpps ¦ VPN throughput (512-bit IPSec): 160 Gbps ¦ VPN throughput (SSL): 16 Gbps ¦ SSL inspection throughput: 55 Gbps ¦ Application control throughput: 190Gbps ¦ CAPWAP throughput: 65 Gbps
- Capacity: Concurrent TCP sessions: 140000000 ¦ New TCP sessions per second: 930000 ¦ Firewall policies: 200000 ¦ Gateway to gateway IPSec VPN Tunnels: 40000 ¦ Client to gateway IPSec VPN tunnels: 200000 ¦ Concurrent SSL VPN users: 30000 ¦ SSL inspection CPS: 57000 ¦ SSL inspection concurrent sessions: 15000000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 500 ¦ Number of FortiSwitches: 300 ¦ Number of FortiAP devices: 4096 ¦ Number of FortiAP devices (tunnel): 2048 ¦ Number of FortiToken devices: 20000
- Included Accessories: 2 x SR 10Gbps SFP+ transceivers
- Power:AC 100-240 V (50/60 Hz)
- Power Redundancy: Yes
- Dimensions (WxDxH): 17.4 in x 23.9 in x 3.5 in
- Weight: 21.40 Kg
- Bundled Services: Fortinet's Security-Driven Networking approach provides tight integration of the network to security, including application control, SSL inspection, and advanced threat protection
Fortinet 3500F Firewall
- Firewall Brand: Fortinet
- Device Type: Network Firewall
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: The Fortinet 3500F series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high-throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments.
- Processor: SPU NP7 and CP9 hardware accelerated
- Threat protection: 63 Gbps
- Hard Disk: Not specified
- Data Link Protocol: 6x 100GE/40GE QSFP28 slots, 32x 25GE/10GE SFP28 slots
- Included Accessories: 2x 10GE RJ45 Management Ports
- Power Supply: 2 AC power supplies
- Power Redundancy: Not specified
- Performance: Firewall Throughput: Up to 600 Gbps
- Dimensions (WxDxH): 17.4 x 21.9 X 3.5
- Weight: 21.30 kg
- Bundled Services:
- Fortinet's Security-Driven Networking approach provides tight integration of the network to security, including application control, SSL inspection, and advanced threat protection
- Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
- Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
- Prevent and detect against known and unknown attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services
Fortinet 3200F Firewall
- Firewall Brand: Fortinet
- Device Type: Firewall
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: High-performance security appliance for data centers and hybrid IT environments
- Processor: Two NP7 processors (NP#0 and NP#1)
- Threat protection: 45 Gbps
- Hard Disk: No specific details on Hard Disk capacity or type
- Data Link Protocol: Supports various data link protocols, including advanced threat protection, intrusion prevention, application control, web filtering, and more
- Power Supply: 2 AC power supplies
- Power Redundancy: Yes, with dual power supplies for redundancy
- Performance: Threat Protection: 45 Gbps, IPS Throughput: 63 Gbps, NGFW Throughput: 47 Gbps
- Dimensions (WxDxH): 3.5 x 17.44 x 23.9 inche
- Weight:20 kg
- Bundled Services: FortiGuard Security Services for real-time threat intelligence updates, Integrated security fabric architecture for seamless integration with other Fortinet security solutions
Fortinet 3000F Firewall
- Firewall Brand:: Fortinet
- Device Type:: Firewall
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: High-performance next generation firewall (NGFW) for large enterprises and service providers
- Processor: SPU NP7 and CP9 hardware accelerated processors
- Threat protection: 33 Gbps
- Hard Disk: FG-3001F model includes 2x 1TB SSD
- Data Link Protocol: Supports various data link protocols including 100 GE, 40 GE, 25 GE, 10 GE, and GE
- Included Accessories: 2x SFP+ (SR 10 GE) transceivers included
- Power Supply: Dual AC power supplies
- Power Redundancy: Yes, with dual redundant power supplies
- Performance: Firewall Throughput: 397 Gbps IPS Throughput: 236 Gbps, NGFW Throughput: 234 Gbps Threat Protection Throughput: 233 Gbps
- Dimensions (WxDxH): 17.44 x 21.89 x 3.5 inches
- Weight: 16.9 kg
- Bundled Services: FortiGuard security subscription services available, FortiCare premium support services available
Fortinet 2600F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW)
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: The Fortinet 2600F is a high-performance next-generation firewall designed to provide best-in-class security and performance for large enterprises and service providers. It is powered by AI/ML-based FortiGuard Services and an integrated security fabric platform, enabling coordinated, automated, end-to-end threat protection across all use cases.
- Processor: SPU NP7 and CP9 hardware accelerated
- Threat protection: 25 Gbps
- Hard Disk: 2TB onboard storage (for the FG-2601F model)
- Data Link Protocol: Multiple GE RJ45, 25 GE SFP28 / 10 GE SFP+ / GE SFP, and 100 GE QSFP28 / 40 GE QSFP+ slots
- Included Accessories: None specified
- Power Supply: Dual AC power supplies
- Power Redundancy: Yes, dual AC power supplies provide redundancy
- Performance: Firewall: 31 Gbps, NGFW: 27 Gbps, Threat Protection: 25 Gbps
- Dimensions (WxDxH): 3.5 x 17.25 x 21.1 inches (88.4 x 438 x 536 mm)
- Weight: 14.0 kg
- Bundled Services: FortiCare Premium, FortiGuard Enterprise Protection, FortiGuard Unified Threat Protection (UTP),These specifications are based on the data sheets from AVFirewalls.com and Fortinet
Fortinet 1800F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW)
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: High-performance NGFW for large enterprises and service providers, delivering advanced threat protection and SSL inspection capabilities.
- Processor: SPU NP7 and CP9 accelerated
- Threat protection: 15 Gbps
- Hard Disk: 2x 1TB on board SSD storage (for Fortinet 1801F models)
- Data Link Protocol: Multiple GE RJ45, 25 GE SFP28 / 10 GE SFP+ / GE SFP, and 40 GE QSFP+ slots
- Included Accessories: None specified
- Power Supply: Dual AC power supplies (for FG-1800F models), dual DC power supplies (for FG-1800F-DC and FG-1801F-DC models)
- Power Redundancy: Yes, for all models
- Performance: IPsec VPN performance: up to 198 Gbps, IPS performance: up to 17 Gbps, SSL Inspection performance: up to 11 Gbps, NGFW performance: up to 9.1 Gbps
- Dimensions (WxDxH): 3.5 in x 17.25 in x 21.1 inches
- Weight: 13.7 kg
- Bundled Services: FortiCare Premium and FortiGuard Enterprise Protection (available with various term options)
Fortinet 1000F Firewall
- Firewall Brand: Fortinet
- Device Type: Security appliance, Next Generation Firewall (NGFW)
- Shape Factor: 2RU Rackmount 8-slot chassis
- Product Description: Enables building security-driven networks with deep integration into data centers and hybrid IT architectures. Powered by AI/ML-based FortiGuard services and the Fortinet Security Fabric platShape for automated threat protection.
- Processor: Dedicated security processors (SPU)
- Threat protection: 13 Gbps
- Hard Disk: 2x 480 GB SSD (FG-1001F model only)
- Data Link Protocol: 100 Gigabit Ethernet, 40 GE, 25 GE, 10 GE, 5 GE, 2.5 GE, GE
- Included Accessories: 2x SFP transceivers
- Power Supply: Dual hot-swappable power supplies
- Power Redundancy: Yes
- Performance: Firewall throughput: 20 Gbps, IPS throughput: 19 Gbps, NGFW throughput: 15 Gbps, Threat Protection throughput: 13 Gbps
- Dimensions (WxDxH): 17.4 x 17.6 x 3.5 inches
- Weight: 9.95 Kg
- Bundled Services: FortiGuard AI/ML-powered security services, The Fortinet 1000F delivers high-performance security with flexible 100 GE connectivity options and hardware acceleration for demanding data center and enterprise edge deploym
Fortinet 900G Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW)
- Shape Factor: 1RU rack-mountable
- Product Description: A high-performance security appliance designed for large enterprises and data centers, providing comprehensive security and networking capabilities.
- Processor: SPU vSPU processors
- Threat protection: 20 Gbps
- Hard Disk: No onboard storage; supports external storage
- Data Link Protocol: 25 GE SFP28, 10 GE SFP+, GE SFP, and GE RJ45
- Included Accessories: 2x SFP transceivers
- Power Supply: Dual hot-swappable power supplies (AC, 100–240VAC, 50/60 Hz)
- Power Redundancy: Yes
- Performance: IPS throughput: 26 Gbps, NGFW throughput: 22 Gbps, Threat Protection throughput: 20 Gbps
- Dimensions (WxDxH): 1.5 x 17.0 x 15.0 inches
- Weight: 7.5 kg
- Bundled Services: FortiGuard AI/ML-powered security services,The Fortinet 900G is designed to provide robust security and networking capabilities for large-scale enterprise and data center deployments, leveraging Fortinet's patented /SPU / vSPU processors and AI/ML-powered FortiGuard services
Fortinet 600F Firewall
- Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW), Secure SD-WAN
- Frame Factor: 1U rack-mountable
- Product Description: Protects against cyber threats with system-on-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution
- Processor: SPU NP7 and CP9 hardware accelerated
- Threat protection: 10.5 Gbps
- Hard Disk: No onboard storage; supports external storage
- Data Link Protocol: 4x 25G SFP28 slots, 4 x 10GE SFP+ slots, 18 x GE RJ45 ports (including 1 x MGMT port, 1 X HA port, 16 x switch ports), 8 x GE SFP slots
- Power Supply: Dual AC power supplies
- Power Redundancy: Yes
- Performance: Firewall throughput: 140 Gbps, IPS throughput: 12 Gbps, NGFW throughput: 9 Gbps, Threat Protection throughput: 8 Gbps
- Dimensions (WxDxH): 1.75 x 17.0 x 15.0 inches
- Weight: 7.08 kg
- Bundled Services: FortiCare Premium and FortiGuard Enterprise Protection (IPS, AI-based Inline Malware Prevention, Advanced Malware Protection, Inline CASB Database, Data Loss Prevention, Application Control, URL, DNS & Video Filtering, Antispam, Attack Surface Security, and FortiConverter Service)
- The FortiGate 600F delivers high-performance security and networking capabilities for mid-sized to large enterprise deployments, with flexible connectivity options and advanced security features powered by Fortinet's Security Processing Unit (SPU) technology
Fortinet 400F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW), Secure SD-WAN
- Shape Factor: 1 RU rack-mountable
- Product Description: A high-performance security appliance designed for mid-sized to large enterprises, providing comprehensive security and networking capabilities with AI/ML-powered FortiGuard services.
- Threat protection: 9 Gbps
- Processor: SPU /vSPU processors
- Hard Disk: No onboard storage; supports external storage
- Data Link Protocol: 16 x GE RJ45 ports, 8 x GE SFP slots, 4 x 10GE SFP+ slots, 4 x 10GE SFP+ Ultra Low Latency slots
- Included Accessories: 2x SFP transceivers
- Power Supply: Dual hot-swappable power supplies (AC, 100–240VAC, 50/60 Hz)
- Power Redundancy: Yes
- Performance: IPS Throughput: 12 Gbps, NGFW Throughput: 10 Gbps, Threat Protection Throughput: 9 Gbps, IPv4 Firewall Throughput: 79.5 Gbps, IPv6 Firewall Throughput: 79.5 Gbps, Firewall Latency: 4.19 ?s / 2.5 ?s*, Firewall Throughput (Packet per Second): 105 Mpps, Concurrent Sessions (TCP): 7.8 Million, New Sessions/Second (TCP): 500 000, Firewall Policies: 10 000, IPsec VPN Throughput: 55 Gbps, SSL-VPN Throughput: 3.6 Gbps, SSL Inspection Throughput: 8 Gbps, Application Control Throughput: 28 Gbps, CAPWAP Throughput: 65 Gbps
- Dimensions (WxDxH): 1.75 x 17.0 x 15.0 inches
- Weight: 6.5 kg
- Bundled Services: FortiCare Essentials, FortiCare Premium, FortiCare Elite, FortiGuard Security Services, and FortiConverter Service, The Fortinet 400F is designed to provide robust security and networking capabilities for mid-sized to large enterprise deployments, leveraging Fortinet's patented /SPU / vSPU processors and AI/ML-powered FortiGuard services
Fortinet 200G Firewall
- Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW)
- Frame Factor: 1U rack-mountable
- Product Description: The FortiGate 200G Series combines AI-powered security and machine learning to deliver Threat Protection at any scale, providing deep visibility into networks and securing applications, users, and devices with advanced edge protection and secure SD-WAN capabilities.
- Processor: NP7Lite (SP5) Security Processing Unit
- Threat protection: 6.4 Gbps
- Hard Disk: No onboard storage; supports external storage
- Data Link Protocol: 10 x GE RJ45 ports, 4 x GE SFP slots, 8 x 5/2.5/GE RJ45 ports, 8 x 10/GE SFP+/SFP slots
- Included Accessories: Not specified
- Power Supply: Dual non-swappable AC Power Supplies
- Power Redundancy: Yes
- Performance: Firewall Throughput: 39 Gbps, NGFW Throughput: 7 Gbps, Threat Protection Throughput: 6.4 Gbps, IPS Throughput: 8 Gbps, VPN Throughput: 35 Gbps
- Dimensions (WxDxH): 1.73 x 17.01 x 13.47 inches
- Weight: 4.6 kg
- Bundled Services: AI-powered FortiGuard Services, deep visibility into applications, users, and devices, and integrated Fortinet Security Fabric platform for secure networking at any scale
Fortinet 200F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW)
- Shape Factor: 1U rack-mountable
- Product Description: The Fortinet 200F Series is a high-performance security appliance designed for modern campus environments, providing comprehensive security and networking capabilities with AI-powered FortiGuard Security Services and 5GE ports for Wi-Fi 7 wireless standard.
- Processor: SP5 Security Processing Unit
- Threat protection: 3 Gbps
- Hard Disk: 1x 480 GB SSD
- Data Link Protocol: 2 x GE RJ45 HA/MGMT Ports, 16 x GE RJ45 Ports, 2 x 10 GE SFP+ Slots, 2 x 10 GE SFP+ FortiLink Slots, 8 x GE SFP Slots
- Included Accessories: Not specified
- Power Supply: Dual non-hot swappable AC Power Supplies
- Power Redundancy: Yes
- Performance: Firewall Throughput: 27 Gbps, NGFW Throughput: 3.5 Gbps, Threat Protection Throughput: 3 Gbps, IPS Throughput: 5 Gbps, IPsec VPN Throughput: 13 Gbps, SSL-VPN Throughput: 2 Gbps, SSL Inspection Throughput: 3.4 Gbps, Application Control Throughput: 2.13 Gbps, CAPWAP Throughput: 20 Gbps
- Dimensions (WxDxH): 1.73 x 17.01 x 13.47 inches
- Weight:4.6 kg
- Bundled Services: FortiGuard AI-Powered Security Services, including inline advanced malware prevention, DNS filtering, data loss prevention, and attack surface management
Fortinet 120G Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW) and Secure SD-WAN
- Shape Factor: 1U rack-mountable
- Product Description: The Fortinet 120G Series is a high-performance security appliance designed for modern campus environments, providing comprehensive security and networking capabilities with AI-powered FortiGuard Security Services and 5GE ports for Wi-Fi 7 wireless standard.
- Processor: SP5 Security Processing Unit
- Threat protection: 2.8 Gbps
- Hard Disk: 1x 480 GB SSD
- Data Link Protocol: 18 GE RJ45 ports (including 1 management port and 1 HA port, alongside 16 switch ports), 8 GE SFP slots, 4 10GE SFP+ slots
- Included Accessories: CD
- Power Supply: Dual non-hot swappable AC power supplies
- Power Redundancy: Yes
- Performance: Firewall Throughput: 39 Gbps, NGFW Throughput: 3.1 Gbps, Threat Protection Throughput: 2.8 Gbps, IPS Throughput: 5.3 Gbps, VPN Throughput: 35 Gbps, SSL-VPN Throughput: 6.1 Gbps, SSL Inspection Throughput: 3 Gbps, Application Control Throughput: 2.13 Gbps, CAPWAP Throughput: 20 Gbps
- Dimensions (WxDxH): 1.73 x 17 x 10 inches
- Weight: 5.52 kg
- Bundled Services: FortiCare Premium and FortiGuard Unified Threat Protection (UTP), The Fortinet 120G is designed to provide robust security and networking capabilities for modern campus environments, leveraging Fortinet's patented SP5 processor and AI-powered FortiGuard services
Fortinet 90G Firewall
- Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW) and Secure SD-WAN
- Frame Factor: Desktop
- Product Description: The FortiGate 90G Series combines next-generation firewall and SD-WAN capabilities for distributed enterprises. It delivers consolidated security and networking functionality with various connectivity options and industry-leading performance in a compact Frame Factor.
- Processor: FortiASIC SP5 Security Processing Unit
- Threat protection: 2.2 Gbps
- Hard Disk: Not specified
- Data Link Protocol: 4 x GE RJ45 ports, 2 x GE SFP slots, 2 x 10GE SFP+ slots, 2.5GE and 5GE ports
- Included Accessories: Not specified
- Power Supply: Internal Power Supply Unit
- Power Redundancy: Not specified
- Performance: Firewall Throughput: 20 Gbps, NGFW Throughput: 2.6 Gbps, Threat Protection Throughput: 1.6 Gbps, IPS Throughput: 1 Gbps, SSL-VPN Throughput: 750 Mbps, SSL Inspection Throughput: 500 Mbps, Application Control Throughput: 135,000, CAPWAP Throughput: 15 Gbps
- Dimensions (WxDxH): 1.65 x 8.5 x 7.0
- Weight: 2.72 kg
- Bundled Services: FortiCare Premium Support and FortiGuard Unified Threat Protection (UTP) Bundle with AI-powered security services, The FortiGate 90G delivers robust security and networking capabilities for distributed enterprises, leveraging Fortinet's patented SP5 ASIC and AI-powered FortiGuard services
Fortinet 80F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW) and Secure SD-WAN
- Shape Factor: Desktop
- Product Description: The Fortinet 80F Series provides an application-centric, scalable, and secure SD-WAN solution in a compact, fanless, desktop Shape factor for enterprise branch offices and midsized businesses. It features integrated WiFi-6 (802.11ax) for high-speed wireless connectivity.
- Processor: FortiASIC SP5 Security Processing Unit
- Threat protection: 900 Mbps
- Hard Disk: 1x 128 GB SSD
- Data Link Protocol: 10 GE RJ45 ports (including 2 WAN ports and 2 FortiLink ports), 2 GE SFP ports (shared with 2 WAN ports)
- Included Accessories: Not specified
- Power Supply: External Power Supply Unit
- Power Redundancy: Not specified
- Performance: IPS Throughput: 1.4 Gbps, NGFW Throughput: 1 Gbps, Threat Protection Throughput: 900 Mbps
- Dimensions (WxDxH): 8.50 x 7.01 x 2.36 inches
- Weight: 1.40 kg
- Bundled Services: FortiCare Premium Support and FortiGuard Unified Threat Protection (UTP) or Enterprise Protection (EP) bundles with AI-powered security services,The Fortinet 80F delivers robust security and networking capabilities for enterprise branch offices and midsized businesses, with integrated WiFi-6 and a compact, fanless design
Fortinet 70F Firewall
- Firewall Brand: Fortinet
- Device Type: Next Generation Firewall (NGFW) and Secure SD-WAN
- Shape Factor: Desktop
- Product Description: The Fortinet 70F Series provides a fast and secure SD-WAN solution in a compact fanless desktop Shape factor for enterprise branch offices and mid-sized businesses. It features integrated WiFi-6 (802.11ax) for high-speed wireless connectivity and is designed to provide robust security and networking capabilities.
- Processor: FortiASIC SP5 Security Processing Unit
- Threat protection: 800 Mbps
- Hard Disk: No
- Data Link Protocol: 10 GE RJ45 ports (including 2 WAN ports and 2 FortiLink ports), 2 GE SFP ports (shared with 2 WAN ports)
- Included Accessories: Not specified
- Power Supply: External Power Supply Unit
- Power Redundancy: yes
- Performance:Firewall Throughput: 10.0 Gbps, Threat Protection Throughput: 800 Mbps, IPS Throughput: 1.4 Gbps, Application Control Throughput: 1.8 Gbps, SSL Inspection Throughput: 700 Mbps, VPN Throughput: 6.1 Gbps
- Dimensions (WxDxH): 8.50 x 6.30 x 1.52 inches
- Weight: 1.01 kg
- Bundled Services: FortiGuard Bundles (Advanced Threat Protection, Unified Threat Protection, Enterprise Protection) and FortiCare Premium Support,The Fortinet 70F delivers robust security and networking capabilities for enterprise branch offices and mid-sized businesses, leveraging Fortinet's patented SoC processors and AI/ML-powered FortiGuard services
Cyberoam Sophos XGS 107 Series Firewall
- Brand: Cyberoam Sophos
- Model No: Cyberoam Sophos xgs107 Firewall
- Firewall throughput: 7,000 Mbps
- Firewall IMIX: 3,750 Mbps
- Firewall Latency (64 byte UDP): 6 µs
- IPS throughput: 1,500 Mbps
- Threat Protection throughput: 370 Mbps
- NGFW: 1,050 Mbps
- Concurrent connections: 1,600,000
- Storage Integrated: 64 GB SSD
- Ethernet interfaces (fixed): 8 x GbE copper, 1 x SFP fiber
- Management ports: 1 x COM RJ45, 1 x Micro-USB (cable incl.)
- Other I/O ports: 1 x USB 2.0 (front), 1 x USB 3.0 (rear)
- Number of expansion slots: 0
- Optional add-on connectivity: SFP DSL module (VDSL2), SFP transceivers
- No. of antennas: 2 external
- MIMO capabilities: 2 x 2:2
- Wireless interface: 802.11a/b/g/n/ac (2.4 GHz / 5 GHz)
- Power supply: External auto-ranging AC-DC 100-240VAC, 1.7A@50-60 Hz 12VDC, 5A, 60W
- Power consumption: 107: 26.1 W/89.06 BTU/hr (idle), 107w: 29.8 W/101.68 BTU/hr (idle), 107: 53.9 W/183.91 BTU/hr (max.), 107w: 57.3 W/195.52 BTU/hr (max.)
- Operating temperature: 0°C to 40°C (operating), -20°C to +70°C (storage)
- Humidity: 10% to 90%, non-condensing
- Mounting: Rackmount kit available (to be ordered separately)
- Dimensions (Width x Height x Depth): 230 x 44 x 205.5 mm
- Weight: 1.4 kg/3.09 lbs (unpacked), 2.8 kg/6.17 lbs (packed)
- Warranty: 3 Years Warranty
Cyberoam Sophos XGS 126 Next Gen Firewall
- Brand: Cyberoam Sophos
- Model No: Cyberoam Sophos xgs126 Firewall
- Firewall throughput: 10,500 Mbps
- Firewall IMIX: 5,250 Mbps
- Firewall Latency (64 byte UDP): 8 µs
- IPS throughput: 3,250 Mbps
- Threat Protection throughput: 900 Mbps
- NGFW: 2,500 Mbps
- Concurrent connections: 5,000,000
- New connections/sec: 69,900
- Storage Integrated: 64 GB SSD
- Ethernet interfaces (fixed): 12 x GbE copper, 2 x SFP fiber
- Power-over-Ethernet (fixed): 2 x GbE, (30W max. per port)
- Management ports: 1 x COM RJ45, 1 x Micro-USB (cable incl.)
- Other I/O ports: 1 x USB 2.0 (front), 1 x USB 3.0 (rear)
- Number of expansion slots: 1
- Optional add-on connectivity: SFP DSL module (VDSL2), 3G/4G module/5G module, Second Wi-Fi radio, (XGS 126w/136w only), SFP transceivers
- No. of antennas: 3 external
- MIMO capabilities: 3 x 3:3
- Wireless interface: Wi-Fi 5/802.11a/b/g/n/ac (2.4 GHz / 5 GHz)
- Optional second Wi-Fi module: Wi-Fi 5/802.11a/b/g/n/ac
- Power supply: External auto-ranging AC-DC, 100-240VAC, 2.5A@50-60 Hz, 12VDC, 12.5A, 150W, Optional second redundant power supply
- Power consumption: 126/136: 30 W/102 BTU/hr (idle), 126w/136w: 32 W/109 BTU/hr (idle), 126: 59 W/202 BTU/hr (max.), 126w/136: 62 W/212 BTU/hr (max.), 136w: 65 W/222 BTU/hr (max.)
- PoE addition enabled: 76 W/260 BTU/hr (max.)
- Operating temperature: 0°C to 40°C (operating), -20°C to +70°C (storage)
- Humidity: 10% to 90%, non-condensing
- Mounting: Rackmount kit available
- Dimensions (Width x Height x Depth): 320 x 44 x 213 mm
- Weight: 2.4 kg/5.29 lbs (unpacked), 4.4 kg/9.70 lbs (packed)
- Warranty: 3 Years Warranty
Cyberoam Sophos XGS 136 Next Gen Firewall
- Brand: Cyberoam Sophos
- Model No: Cyberoam Sophos xgs136 Firewall
- Firewall throughput: 11,500 Mbps
- Firewall IMIX: 6,500 Mbps
- Firewall Latency (64 byte UDP): 8 µs
- IPS throughput: 4,000 Mbps
- Threat Protection throughput: 1,000 Mbps
- NGFW: 3,000 Mbps
- Concurrent connections: 6,400,000
- New connections/sec: 74,500
- Storage Integrated: 64 GB SSD
- Ethernet interfaces (fixed): 10 x GbE copper, 2 x 2.5 GbE copper, 2 x SFP fiber
- Power-over-Ethernet (fixed): 2 x 2.5 GbE, (30W max. per port)
- Management ports: 1 x COM RJ45, 1 x Micro-USB (cable incl.)
- Other I/O ports: 1 x USB 2.0 (front), 1 x USB 3.0 (rear)
- Number of expansion slots: 1
- Optional add-on connectivity: SFP DSL module (VDSL2), 3G/4G module/5G module, Second Wi-Fi radio (XGS 126w/136w only), SFP transceivers
- No. of antennas: 3 external
- MIMO capabilities: 3 x 3:3
- Wireless interface: Wi-Fi 5/802.11a/b/g/n/ac (2.4 GHz / 5 GHz)
- Optional second Wi-Fi module: Wi-Fi 5/802.11a/b/g/n/ac
- Power supply: External auto-ranging AC-DC, 100-240VAC, 2.5A@50-60 Hz, 12VDC, 12.5A, 150W, Optional second redundant power supply
- Power consumption: 126/136: 30 W/102 BTU/hr (idle), 126w/136w: 32 W/109 BTU/hr (idle), 126: 59 W/202 BTU/hr (max.), 126w/136: 62 W/212 BTU/hr (max.), 136w: 65 W/222 BTU/hr (max.)
- PoE addition enabled: 76 W/260 BTU/hr (max.)
- Operating temperature: 0°C to 40°C (operating), -20°C to +70°C (storage)
- Humidity: 10% to 90%, non-condensing
- Mounting: Rackmount kit available
- Dimensions (Width x Height x Depth): 320 x 44 x 213 mm
- Weight: 2.4 kg/5.29 lbs (unpacked), 4.4 kg/9.70 lbs (packed)
SonicWall TZ270 Wireless Network Firewall
- Brand: Sonicwall
- Model No: SonicWall TZ270 Wireless Firewall
- Firewall Throughput: 2 Gbps
- Threat Prevention Throughput: 750 Mbps
- Interfaces: 8x1GbE, 2x2.5/5/10GbE
- IPS Throughput: 1 Gbps
- Maximum Connections: 1.5 Million
- VPN Throughput: 750 Mbps
- Power Supply: Optional redundant power for continuous service reliability
- Power Redundancy: Yes
- Storage: Built-in and expandable up to 256 GB
- Dimensions: 3.5 x 13.5 x 19 cm
- Weight: 0.82 kg (1.81 lbs)
- Warranty: 3 Years Warranty
SonicWall TZ370 Wireless Network Firewall
- Brand: Sonicwall
- Model No: SonicWall TZ370 Wireless Firewall
- Wireless Support: 2x2 802.11ac Wave 2
- Interfaces: 8x1GbE, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 3 Gbps
- IPS Throughput: 1.5 Gbps
- Threat Prevention Throughput: 1 Gbps
- VPN Throughput: 1.38 Gbps
- Maximum Connections: 900,000
- Power Options: Standard single external power supply, optional redundancy
- Dimensions: 3.5 x 13.5 x 19 cm
- Weight: 0.85 kg (1.87 lbs)
- Warranty: 3 Years Warranty
SonicWall TZ470 Wireless Network Firewall
- Brand: Sonicwall
- Model No: SonicWall TZ470 Wireless Firewall
- Wireless Support: 2x2 802.11ac Wave 2
- Interfaces: 8x1GbE, 2x2.5G SFP+, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 3.5 Gbps
- IPS Throughput: 2 Gbps
- Threat Prevention Throughput: 1.5 Gbps
- VPN Throughput: 1.5 Gbps
- Maximum Connections: 1,000,000
- Power Options: External power supply, optional redundancy
- Dimensions: 3.5 x 13.5 x 19 cm
- Weight: 0.87 kg (1.92 lbs)
- Warranty: 3 Years Warranty
SonicWall TZ570 Wireless Network Firewall
- Brand: Sonicwall
- Model No: SonicWall TZ570 Wireless Firewall
- Wireless Support: 2x2 802.11ac Wave 2
- Interfaces: 8x1GbE, 2x5G SFP+, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 4 Gbps
- IPS Throughput: 2.5 Gbps
- Threat Prevention Throughput: 2 Gbps
- VPN Throughput: 1.8 Gbps
- Maximum Connections: 1,250,000
- Power Options: 60W external, optional redundant power supply
- Dimensions: 3.5 x 15 x 22.5 cm
- Weight: 0.99 kg (2.18 lbs)
- Warranty: 3 Years Warranty
SonicWall TZ670 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall TZ670 Wireless Firewall
- Interfaces: 8x1GbE, 2x10G SFP+, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 5 Gbps
- IPS Throughput: 3 Gbps
- Threat Prevention Throughput: 2.5 Gbps
- VPN Throughput: 2.1 Gbps
- Maximum Connections: 1,500,000
- Power Options: 60W external, optional redundant power supply
- Dimensions: 3.5 x 15 x 22.5 cm
- Weight: 0.97 kg (2.14 lbs)
- Warranty: 3 Years Warranty
SonicWall NSa 2700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSa 2700 Firewall
- Operating System: SonicOS 7.0
- Interfaces: 16x1GbE, 3x10G SFP+, 2 USB 3.0, 1 Console, 1 Management port
- Storage: 64GB M.2
- Firewall Inspection Throughput: 5.5 Gbps
- Threat Prevention Throughput: 3.0 Gbps
- Application Inspection Throughput: 3.6 Gbps
- IPS Throughput: 3.4 Gbps
- Anti-Malware Inspection Throughput: 2.9 Gbps
- TLS/SSL Inspection and Decryption Throughput (DPI SSL): 800 Mbps
- IPSec VPN Throughput: 2.10 Gbps
- Connections per Second: 21,500
- Maximum Connections (DPI): 500,000
- Warranty: 3 Years Warranty
SonicWall NSa 3700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSa 3700 Firewall
- Operating System: SonicOS 7.0.1
- Interfaces: 24x1GbE, 6x10G SFP+, 4x5G SFP+, 2 USB 3.0, 1 Console, 1 Management port
- Storage: 128GB M.2
- Firewall Inspection Throughput: 5.5 Gbps
- Threat Prevention Throughput: 3.5 Gbps
- Application Inspection Throughput: 4.2 Gbps
- IPS Throughput: 3.8 Gbps
- Anti-Malware Inspection Throughput: 3.5 Gbps
- TLS/SSL Inspection and Decryption Throughput (DPI SSL): 850 Mbps
- IPSec VPN Throughput: 2.2 Gbps
- Connections per Second: 22,500
- Maximum Connections (SPI): 2,000,000
- Maximum DPI-SSL Connections: 150,000
- Maximum Connections (DPI): 750,000
- Site-to-Site VPN Tunnels: 3,000
- IPSec VPN Clients (max): 50 (1000)
- SSL VPN Licenses (max): 2 (500)
- Encryption/Authentication: DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
- Key Exchange: Diffie Hellman Groups 1, 2, 5, 14v
- Route-based VPN: RIP, OSPF, BGP
- Certificate Support: Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
- VPN Features: Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN Client Platforms Supported: Microsoft Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10
- NetExtender: Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect: Apple iOS, Mac OS X, Google Android, Kindle Fire, Chrome, Windows 8.1 (Embedded)
- Deep Packet Inspection Services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Application Visualization: Yes
- Application Control: Yes
- Capture Advanced Threat Protection: Yes
- High Availability: Active/Passive with stateful synchronization
- Form Factor: 1U Rack Mountable
- Power Supply: 90W
- Maximum Power Consumption (W): 36.3
- Input Power: 100-240 VAC, 50-60 Hz
- Total Heat Dissipation: 123.78 BTU
- Dimensions: 43 x 32.5 x 4.5 (cm) / 16.9 x 12.8 x 1.8 (in)
- Weight: 4.6 kg / 10.2 lbs
- Warranty: 3 Years Warranty
SonicWall NSa 4700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSa 4700 Firewall
- Interfaces: 8x1GbE, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 3 Gbps
- IPS Throughput: 1.5 Gbps
- Threat Prevention Throughput: 1 Gbps
- VPN Throughput: 1.38 Gbps
- Maximum Connections: 900,000
- Power Options: Standard single external power supply, optional redundancy
- NetExtender: Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect: Apple iOS, Mac OS X, Google Android, Kindle Fire, Chrome, Windows 8.1 (Embedded)
- Deep Packet Inspection Services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Application Visualization: Yes
- Application Control: Yes
- Dimensions: 3.5 x 13.5 x 19 cm
- Weight: 0.82 kg (1.81 lbs)
- Warranty: 3 Years Warranty
SonicWall NSa 5700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSa 5700 Firewall
- Interfaces: 8x1GbE, 2x5G SFP+, 2 USB 3.0, 1 Console
- Firewall Inspection Throughput: 4 Gbps
- IPS Throughput: 2.5 Gbps
- Threat Prevention Throughput: 2 Gbps
- VPN Throughput: 1.8 Gbps
- Maximum Connections: 1,250,000
- Power Options: 60W external, optional redundant power supply
- NetExtender: Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect: Apple iOS, Mac OS X, Google Android, Kindle Fire, Chrome, Windows 8.1 (Embedded)
- Deep Packet Inspection Services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
- Application Visualization: Yes
- Application Control: Yes
- Dimensions: 3.5 x 15 x 22.5 cm
- Weight: 0.97 kg (2.14 lbs)
- Warranty: 3 Years Warranty
SonicWall NSa 6700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSa 6700 Firewall
- Operating System: SonicOS 7.0
- Interfaces: 2x40G SFP/SFP+, 8x25G, 4x10G/5G/2.5G/1G SFP+, 4x10G/5G/2.5G/1G Cu, 16x1GbE Cu, 2 USB 3.0, 1 Console, 1 Management port
- Storage: 256GB Built-in, Expandable up to 1TB
- Firewall Inspection Throughput: 36 Gbps
- Threat Prevention Throughput: 19 Gbps
- Application Inspection Throughput: 20 Gbps
- IPS Throughput: 20 Gbps
- Anti-Malware Inspection Throughput: 18.5 Gbps
- TLS/SSL Inspection and Decryption Throughput (DPI SSL): 9 Gbps
- IPSec VPN Throughput: 19 Gbps
- Connections per Second: 153,000
- Maximum Connections (SPI): 8,000,000
- Maximum DPI-SSL Connections: 750,000
- Maximum Connections (DPI): 6,000,000
- Site-to-Site VPN Tunnels: 6,000
- IPSec VPN Clients (max): 2000 (6000)
- SSL VPN Licenses (max): 2 (1500)
- Global VPN Client Platforms Supported: Windows 10
- NetExtender: Windows 10 and Linux
- Mobile Connect: Apple iOS, Mac OS X, Google Android, Kindle Fire, Chrome, Windows 8.1 (Embedded)
- Comprehensive Anti-Spam Service: Supported
- Application Visualization: Yes
- Application Control: Yes
- Local User Database: 3200
- VoIP: Full H323-v1-5, SIP
- High Availability: Active/Passive with stateful synchronization
- Form Factor: 1U Rack Mountable
- Fans: 2 (removable)
- Power Supply: 1x350W
- Maximum Power Consumption (W): 139.2
- Input Power: 100-240 VAC, 50-60 Hz
- Total Heat Dissipation: 474.7 BTU
- Dimensions: 43 x 46.5 x 4.5 (cm) / 16.9 x 18.1 x 1.8 (in)
- Weight: 8.1 kg / 17.9 lbs
- Warranty: 3 Years Warranty
SonicWall NSa 9450 Network Firewall
- We guarantee the highest level of performance from your firewall. The Firewalls.com proprietary method of setting up new SonicWall NSa 9450 Firewall security appliances has been developed exclusively by our support team with the customer in mind. We have developed a 50-step checklist to secure your appliance. The process begins by discussing at length the needs and expectations that you bring to the table, SonicWall NSa 9450 Firewall identifying the specific objectives that must be accomplished with your appliance. By working closely with you throughout the configuration journey, we ensure that we devise a configuration plan which aligns with your requests and unique challenges. A smooth transition plan is mapped out and followed to achieve the highest level of service, ensuring a safe and seamless deployment.
- The pre-installation survey we utilize is time-tested and sound. Our vast network security experience and SonicWall NSa 9450 firewall configuration expertise offers you the peace of mind that you will receive a product and service tailored perfectly to your needs. We take the time to explore exactly what you expect from your security appliance.
- Working from home is more prevalent than ever. Ensuring that your SonicWall NSa 9450 Firewall is small business data is secure, even with a majority of your work force off premise, can be a challenge. Appropriate VPN design, implentation, and management, along with accurate system reporting, are all complex and crucial aspects that affect your overall satisfaction with the appliance. Rest assured that we will set up and test VPN tunnels with the necessary precision to allow your users seamless remote network access.
- Our Configuration Service comes at zero risk to you. Our Reseller Ratings reviews are verifiable proof that we generate great results for hundreds of small, medium, and enterprise companies nationwide. We are so confident in our services that we offer a 100% money back guarantee if you’re not completely satisfied with your configuration service.
SonicWall NSa 9650 Network Firewall
- We guarantee the highest level of performance from your firewall. The Firewalls.com proprietary method of setting up new SonicWall NSa 9650 Firewall security appliances has been developed exclusively by our support team with the customer in mind. We have developed a 50-step checklist to secure your appliance. The process begins by discussing at length the needs and expectations that you bring to the table, SonicWall NSa 9650 Firewall identifying the specific objectives that must be accomplished with your appliance. By working closely with you throughout the configuration journey, we ensure that we devise a configuration plan which aligns with your requests and unique challenges. A smooth transition plan is mapped out and followed to achieve the highest level of service, ensuring a safe and seamless deployment.
- The pre-installation survey we utilize is time-tested and sound. Our vast network security experience and SonicWall NSa 9650 firewall configuration expertise offers you the peace of mind that you will receive a product and service tailored perfectly to your needs. We take the time to explore exactly what you expect from your security appliance.
- Working from home is more prevalent than ever. Ensuring that your SonicWall NSa 9650 Firewall small business data is secure, even with a majority of your work force off premise, can be a challenge. Appropriate VPN design, implentation, and management, along with accurate system reporting, are all complex and crucial aspects that affect your overall satisfaction with the appliance. Rest assured that we will set up and test VPN tunnels with the necessary precision to allow your users seamless remote network access.
- Our Configuration Service comes at zero risk to you. Our Reseller Ratings reviews are verifiable proof that we generate great results for hundreds of small, medium, and enterprise companies nationwide. We are so confident in our services that we offer a 100% money back guarantee if you’re not completely satisfied with your configuration service.
SonicWall NSSP 13700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSSP 13700 Firewall
- Operating system: SonicOS 7.0.1
- Interfaces: 2x100/40-GbE QSFP28, 8x25/10/5/2.5-GbE, SFP28, 4x10/5/2.5-GbE, SFP+, 4x10/5/2.5/1-GbE Cu, 16x1-GbE, 2 USB 3.0, 1 Console, 1 Mgmt. port
- Storage: 1.5TB
- SSO Users: 100,000
- Firewall Inspection Throughput: 60 Gbps
- Threat Prevention Throughput: 45.5 Gbps
- IPS Throughput: 48 Gbps
- TLS/SSL Inspection Throughput: 16.5 Gbps
- VPN Throughput: 29 Gbps
- Maximum Connections: 25 million SPI
- Warranty: 3 Years Warranty
SonicWall NSSP 15700 Network Firewall
- Brand: Sonicwall
- Model No: SonicWall NSSP 15700 Firewall
- Operating system: SonicOS 7.0
- Interfaces: 6 x 100-GbE QSFP28, 4 x 40-GbE QSFP+, 16 x 10 GbE SFP+
- Storage: 2 x 480 GB SSD
- SSO Users: 100,000
- Firewall Inspection Throughput: 105 Gbps
- Threat Prevention Throughput: 82 Gbps
- IPS Throughput: 76.5 Gbps
- TLS/SSL Inspection Throughput: 21 Gbps
- VPN Throughput: 32 Gbps
- Maximum Connections: 80 million SPI
- Warranty: 3 Years Warranty
Watchguard Firebox NV5 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox NV5 Firewall
- Firewall (IMIX): 150 Mbps
- VPN (IMIX): 62 Mbps
- Firewall (UDP 1518): 410 Mbps
- VPN (UDP 1518): 200 Mbps
- Interfaces: 10/100/1000 3
- I/O interfaces: 1 Serial / 1 USB
- Concurrent Connections: 73,000
- New Connections per second: 8,500
- VLANs: 10
- WSM licenses (incl): 0
- SD-WAN: Multi-wan failover, dynamic path selection, jitter/ loss/ latency measurement, load sharing
- Dynamic Routing: RIP, OSPF, BGP
- High Availability: N/A
- QoS: 802.1Q, DSCP, IP Precedence
- Traffic Management: By policy
- Branch Office: VPN 10
- Mobile: VPN 10
- Product Dimensions (W x D x H): 7.5” x 6.0” x 1.25” (190 x 152 x 32 mm)
- Product Weight: 1.98 lbs (0.9 kg)
- Power: 100-240 VAC Autosensing
- Power Consumption: 12 Watts
- MTBF: 1,101,388 hours
- Warranty: 5 Years Warranty
Watchguard Firebox T25 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox T25 Firewall
- UTM (full scan): 2 403 Mbps
- Firewall (IMIX): 900 Mbps
- VPN (IMIX): 300 Mbps
- HTTPS Content Inspection(IPS enabled): 216 Mbps
- Antivirus: 472 Mbps
- IPS (full scan): 525 Mbps
- Firewall (UDP 1518): 3.14 Gbps
- VPN (UDP 1518): 1.02 Gbps
- Interfaces: 10/100/1000 5
- I/O interfaces: 1 Serial/2 USB
- Concurrent connections: 1,300,000
- Concurrent connections (Proxy): 285,000
- New connections per second: 16,000
- VLANs: 10
- WSM licenses (incl): 0
- EDR Core licenses: 5
- Branch Office VPN: 10
- Mobile VPN: 10
- SD-WAN: Multi-WAN failover, dynamic path selection, jitter/loss/latency measurement
- Dynamic Routing: RIP, OSPF, BGP
- High Availability: Active/passive, active/active
- QoS: 802.1Q, DSCP, IP Precedence
- Traffic: Management By policy or application
- Product Dimensions (W x D x H): 8” x 8.5” x 1.7” (203.2 mm x 215.9 mm x 43.2 mm)
- Product Weight: T25: 1.94 lbs (0.88 kg), T25-W: 1.98 lbs (0.9 kg)
- Power: 100-240 VAC Autosensing
- Power Consumption: 24 Watts
- MTBF: 1,101,388 hours
- Warranty: 5 Years Warranty
Watchguard Firebox T45 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox T45 Firewall
- UTM (full scan): 2 557 Mbps
- Firewall (IMIX): 1.44 Gbps
- VPN (IMIX): 460 Mbps
- HTTPS Content Inspection (IPS enabled): 301 Mbps
- Antivirus: 874 Mbps
- IPS (full scan): 716 Mbps
- Firewall (UDP 1518): 3.94 Gbps
- VPN (UDP 1518): 1.58 Gbps
- Interfaces: 10/100/1000 5
- I/O interfaces: 1 Serial/2 USB
- Concurrent connections: 3,850,000
- Concurrent connections (Proxy): 285,000
- New connections per second: 26,500
- VLANs: 50
- WSM licenses (included): 0
- EDR Core licenses: 20
- Branch Office VPN: 30
- Mobile VPN: 30
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 8” x 8.5” x 1.7” (203.2 mm x 215.9 mm x 43.2 mm)
- Product Weight T45/ T45-PoE: 1.94 lbs (0.88 kg), T45-W-PoE: 1.98 lbs (0.9 kg)
- Power: 100-240 VAC Autosensing
- Power Consumption: No PoE: 24 Watts, With PoE: 60 Watts
- MTBF: 157,751 hours
- Warranty: 5 Years Warranty
Watchguard Firebox T85 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox T85 Firewall
- UTM (full scan): 2 943 Mbps
- Firewall (IMIX): 2.40 Gbps
- VPN (IMIX): 680 Mbps
- HTTPS Content Inspection(IPS enabled): 3 576 Mbps
- Antivirus: 1.53 Gbps
- IPS (full scan): 1.28 Gbps
- Firewall (UDP 1518): 4.96 Gbps
- VPN (UDP 1518): 2.04 Gbps
- Interfaces: 10/100/1000 8
- I/O interfaces: 1 Serial/2 USB
- Concurrent connections: 3,850,000
- Concurrent connections (Proxy): 290,000
- New connections per second: 35,500
- VLANs: 75
- WSM licenses (incl): 0
- EDR Core licenses: 50
- Branch Office VPN: 60
- Mobile VPN: 60
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 8.09” x 11.41” x 1.7” (205.5mm x 290mm x 43 mm)
- Product Weight: 5.82 lbs (2.6 kg)
- Power: 90-264 VAC Autosensing
- Power Consumption: No PoE: 27 Watts, 2x PoE: 96 Watts
- MTBF: 1,155,348 hours
- Warranty: 5 Years Warranty
Watchguard Firebox M290 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M290 Firewall
- UTM (full scan): 1.18 Gbps
- VPN (IMIX): 800 Mbps
- HTTPS Content Inspection (IPS enabled): 3 696 Mbps
- Antivirus: 1.47 Gbps
- IPS (full scan): 1.3 Gbps
- Firewall (UDP 1518): 5.8 Gbps
- VPN (UDP 1518): 2.4 Gbps
- Interfaces: 10/100/1000: 8x1 Gb
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 3,500,000
- New connections per second: 34,000
- VLANs: 100
- WSM licenses (incl): 4
- EDR Core Licenses: 75
- Branch Office VPN: 75
- Mobile VPN: 75
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 12.08” x 17.24” x 1.73” (307 mm x 438 mm x 44 mm)
- Product Weight: 8.04 lbs (3.65 kg)
- Power: Single PSU -65W, 90-264VAC~, 1.0A/1.5A, 47-63Hz
- Power Consumption: 110V AC power: 75W at 45 °C with 57% fan speed
- MTBF: 623,087 hours
- Warranty: 5 Years Warranty
Watchguard Firebox M390 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M390 Firewall
- UTM (full scan): 2.4 Gbps
- VPN (IMIX): 1.8 Gbps
- HTTPS Content Inspection(IPS enabled): 1.32 Gbps
- Antivirus: 3.1 Gbps
- IPS (full scan): 3.3 Gbps
- Firewall (UDP 1518): 18.0 Gbps
- VPN (UDP 1518): 5.2 Gbps
- Interfaces: 10/100/1000: 8x1 Gb
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 4,500,000
- New connections per second: 98,000
- VLANs: 250
- WSM licenses (incl): 4
- EDR Core Licenses: 150
- Branch Office VPN: 250
- Mobile VPN: 250
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 12.08” x 17.24” x 1.73” (307 mm x 438 mm x 44 mm)
- Product Weight: 8.04 lbs (3.65 kg)
- Power: Single PSU -120W, 90-264VAC~, 2.2A/2.4A, 47-63Hz
- Power Consumption: 110V AC power: 76W at 45 °C with 64% fan speed
- MTBF: 578,655 hours
- Warranty: 5 Years Warranty
Watchguard Firebox M590 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M590 Firewall
- UTM (full scan): 3.3 Gbps
- VPN (IMIX): 2.2 Gbps
- HTTPS Content Inspection(IPS enabled): 1.9 Gbps
- Antivirus: 5.0 Gbps
- IPS (full scan): 4.6 Gbps
- Firewall (UDP 1518): 20.0 Gbps
- VPN (UDP 1518): 6.84 Gbps
- Interfaces: 10/100/1000: 8x1Gb & 2xSFP+
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 6,000,000
- New connections per second: 132,000
- VLANs: 750
- WSM licenses (incl): 4
- EDR Core Licenses: 250
- Branch Office VPN: 500
- Mobile VPN: 500
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 12.08” x 17.24” x 1.73” (307 mm x 438 mm x 44 mm)
- Product Weight: 9.92 lbs (4.5 kg)
- Power: Dual PSU -150W, G0937-120-1250-1, 90-264VAC~, 2.2A/2.4A, 47-63Hz
- Power Consumption: 110 V AC power: 75 W at 45 °C with 54% fan speed
- MTBF: 443,771 hours
- Warranty: 5 Years Warranty
Watchguard Firebox M690 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M690 Firewall
- UTM (full scan): 4.6 Gbps
- VPN (IMIX): 3.2 Gbps
- HTTPS Content Inspection(IPS enabled): 2.9 Gbps
- Antivirus: 6.2 Gbps
- IPS (full scan): 5.8 Gbps
- Firewall (UDP 1518): 29.7 Gbps
- VPN (UDP 1518): 10.0 Gbps
- Interfaces: 10/100/1000: 8x1Gb & 2xSFP+ & 2x10Gb multispeed
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 15,000,000
- New connections per second: 146,000
- VLANs: 1000
- WSM licenses (incl): 4
- EDR Core Licenses: 250
- Branch Office VPN: 1000
- Mobile VPN: 1000
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 12.08” x 17.24” x 1.73” (307 mm x 438 mm x 44 mm)
- Product Weight: 9.92 lbs (4.5 kg)
- Power: Dual PSU -150W, G0937-120-1250-1, 90-264VAC~, 2.2A/2.4A, 47-63Hz
- Power Consumption: 110 V AC power: 87 W at 45 °C with 66% fan speed
- MTBF: 337,443 hours
- Warranty: 5 Years Warranty
Watchguard Firebox M4800 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M4800 Firewall
- UTM (full scan): 6.8 Gbps
- VPN (IMIX): 4.8 Gbps
- HTTPS Content Inspection(IPS enabled): 4.2 Gbps
- Antivirus: 12.5 Gbps
- IPS (full scan): 8.1 Gbps
- Firewall (UDP 1518): 49.6 Gbps
- VPN (UDP 1518): 16.4 Gbps
- Interfaces: 10/100/1000: 8x1Gb
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 15,000,000
- New connections per second: 254,000
- VLANs: 1,000
- WSM licenses (incl): 9
- EDR Core Licenses: 250
- Branch Office VPN: 5000
- Mobile VPN: 10,000
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 17” x 18.5” x 1.8” (438 mm x 468 mm x 44 mm)
- Product Weight: 17.6 lbs (8 kg)
- Power: Dual power supplies 300W, 100-240VAC/ 5-3A/ 50-60Hz
- Power Consumption: 130 W
- MTBF: 63,983 hours @77°F (25 °C)
- Warranty: 5 Years Warranty
Watchguard Firebox M5800 Business Firewall
- Brand: Watchguard
- Model No: Watchguard Firebox M5800 Firewall
- UTM (full scan): 11.3 Gbps
- VPN (IMIX): 5.2 Gbps
- HTTPS Content Inspection(IPS enabled): 4.9 Gbps
- Antivirus: 22.0 Gbps
- IPS (full scan): 12.5 Gbps
- Firewall (UDP 1518): 87.0 Gbps
- VPN (UDP 1518): 18.8 Gbps
- Interfaces: 10/100/1000: 8 x 1 Gb and 4 x 10 Gb
- I/O interfaces: 1 serial/ 2 USB
- Concurrent connections: 30,800,000
- New connections per second: 328,000
- VLANs: Unrestricted
- WSM licenses (incl): 9
- EDR Core Licenses: 250
- Branch Office VPN: Unrestricted
- Mobile VPN: Unrestricted
- Firewall: Stateful packet inspection, TLS decryption, proxy firewall
- Application proxies: HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy
- Threat protection: DoS attacks, fragmented & malformed packets, blended threats
- Filtering options: Browser Safe Search, Google for Business
- Product Dimensions (W x D x H): 17” x 22.8” x 1.8” (438 mm x 580 mm x 44 mm)
- Product Weight: 26.5 lbs (12 kg)
- Power: Dual power supplies 300W, 100-240VAC/ 6-3A/ 47-63Hz
- Power Consumption: 193 W
- MTBF: 86,999 hours @ 77°F(25 °C)
- Warranty: 5 Years Warranty
