Lenovo Tape Drives
IBM LTO Ultrium 8 Tape Drive
- Media type : Linear serpentine recording half-inch cartridge
- Data capacity : 12 TB native Up to 30 TB with 2.5:1 data compression
- Cartridge models : LTO Ultrium 8 12 TB rewritable data cartridge
- LTO Ultrium 8 12 TB non-erasable non-rewritable WORM cartridge
- Total tape thickness : 5.6 µ (0.00022 in.)
- Tape length : 960 m (3 149.61 ft)
- Cartridge size (L x W x D) : 102.0 mm x 105.4 mm x 21.55 mm (4.0 in. x 4.1 in. x 0.8 in.)
- Data cartridge weight : 200 g (0.441 lb)
- LTO Ultrium 8 data cartridge : 3589-652 (p/n 01PL041), 3589-552 (p/n 01PL041L)
- LTO Ultrium 8 WORM cartridge : 3589-672 (p/n 01PL042), 3589-572 (p/n 01PL042L)
- LTO Ultrium universal cleaning cartridge : 3589-004 (p/n 35L2086)
- Limited lifetime warranty : Free from defects in manufacturing and material defects for the useful life of the product or until end of support of the product
IBM LTO Ultrium 6 Tape Drive
- Media type : Linear serpentine recording half-inch cartridge
- Data capacity : 2.5 TB native Up to 6.25 TB with 2.5:1 data compression
- Cartridge models : LTO Ultrium 6 2.5 TB rewritable Data Cartridge LTO Ultrium 6 2.5 TB non-erasable non-rewritable WORM Cartridge
- Tape length : 885 m (2903 ft)
- Cartridge size (L x W x D) : 102.0 mm x 105.4 mm x 21.5 mm (4.02 in. x 4.15 in. x 0.85 in.)
- Data cartridge weight : 200 g (0.441 lb)
- Cleaning cartridge weight : 115 g (0.254 lb)
- Safety characteristics Toxicity: nonhazardous to human health in anticipated use
- Flammability: self-extinguishing per UL94
- Operating conditions : 10°C – 45°C (50°F – 113°F); 10% – 80% RH; 26°C (79°F) wet bulb maximum
- Short-term storage conditions : 16°C – 35°C (61°F – 95°F); 20% – 80% RH; 26°C (79°F) wet bulb maximum
- Long-term storage conditions : 16°C – 25°C (61°F – 77°F); 20% – 50% RH; 26°C (79°F) wet bulb maximum
- Shipping conditions : -23°C – 49°C (-9°F – 120°F); 20% – 80% RH; 26°C (79°F) wet bulb max
- Cartridge disposal : Classified as nonhazardous waste per EPA regulation 40CFR261;
- Can be disposed of as normal office trash
- LTO Ultrium 6 Data Cartridge : 3589-650 (p/n 00V7590)
- LTO Ultrium 6 WORM Cartridge : 3589-670 (p/n 00V7591)
- LTO Ultrium Universal Cleaning Cartridge : 3589-004 (p/n 35L2086)
- Limited lifetime warranty : Free from defects in manufacturing and materials defects for the useful life of the product
IBM LTO Ultrium 7 Tape Drive
- Product Details:Manufacturer : IBM
- Format : LTO Ultrium 7 Tape
- IBM Part No : 38L7302
- Native Capacity : 6TB
- Compressed : Up to 15TB (assuming 2.5:1 Compression)
- Data Rate : 300 MB/s (native), 750 MB/s (with 2.5:1 compression) with Generation 7 drive
- Tape Length : 960 meters
- Archival Life : 30 Years
- Load/Unload Cycles : 20 000
- Warranty : Limited Lifetime Warranty by IBM
Lenovo ThinkSystem DS Series Dual IOM SFF Expansion Unit Storage Enclosure
- 24 Supported Devices
- 1 x USB Cable
- BSMI CNS 13438 Class A ICES-003 EN55024 CCC RoHS EN 60950-1 FCC Part 15 A GB 17625.1 GB 9254 Class A VCCI Class A EAC NMB-3 Class
- A GB 4943.1 RCM MSIP NOM-019 UL/CSA60950-1 CNS 14336-1 EN 55032 Class A
- Rack Mounting Kit
- Storage Enclosure Device Type
- 24 (total) / 24 (free) x hot-swap - 2.5" SFF Expansion Bays
- 6 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644)
- 2 x internal power supply - hot-plug Power Device
- AC 120/230 V - 50/60 Hz Voltage Required
- 580 Watt Power Provided
- 3 Years Onsite Warranty
Lenovo ThinkSystem DS Series Dual IOM LFF Expansion Unit Storage Enclosure
- 3.5" LFF Form Factor
- 8.9 cm LFF Form Factor (metric)
- 1XUSB Cable
- 36 pin 4x Mini SAS HD (SFF-8644) Connector Type
- Rack Mounting Kit
- Storage Enclosure Device Type
- 24 (total) / 24 (free) x hot-swap - 3.5" LFF Expansion Bays
- Serial Attached SCSI 3
- 12 Supported Devices / Modules Qty
- 2 x internal power supply - hot-plug Power Device
- AC 120/230 V - 50/60 Hz Voltage Required
- 580 Watt Power Provided
- 3 Years Onsite Warranty
Lenovo ThinkSystem DS2200 Dual Controller Hard Drive Array
- Product Details:
- SFF FC/iSCSI Dual Controller Unit Model
- Hot-Plug
- 2 x RAID Type
- 8 GB Buffer Size
- 4 Host Channels
- Rack Mountable
- Fibre Channel iSCSI
- Rack Mounting Kit
- 2M Height
- Black Color Category
- 24 Supported Devices
- Serial Attached SCSI 3
- RAID 0 RAID 1 RAID 10 RAID 5 RAID 6
- Serial Attached SCSI 3 Interface Type
- 580 Watt Power Provided
- AC 120/230 V Nominal Voltage
- 50/60 Hz Frequency Required
- 36 pin 4x Mini SAS HD (SFF-8644), RJ-45 SFP/SFP+, mini-USB Type B Connector Type
- Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel SAS 12Gb/s management serial Interface
- 16Gb Fibre Channel 8Gb Fibre Channel iSCSI (1 GbE), iSCSI (10 GbE)
- 3 Years Onsite Warranty
IBM TS2270 H7S Tape Drive Model
- Model 6160 H7S-One LTO Ultrium 7 tape drive 6Gbps SAS interface
- LTO Ultrium 7 Tape Drive Type
- 6TB native
- 15TB with 2.5:1 Compression
- 1 Number of Tape Drives
- 1 Number of Tape Cartridges
- Up to 300MBps Native Data Transfer Rate
- Read and write: LTO Ultrium 7 6TB data cartridge LTO Ultrium 6 2.5TB data cartridge
- Read only: LTO Ultrium 5 1.5TB data cartridge
- LTO Ultrium cleaning cartridge
- 4.3kg (9.5lbs) Weight
- 100 – 240V ac 50 – 60Hz auto-ranging Power Requirements
- 21.3cm x 5.8cm x 33.2cm (8.39in. x 2.29in. x 13.07in.)
- 3 Years Limited Warranty
IBM TS2260 H6S Tape Drive Model
- Model 6160 H6S-One LTO Ultrium 6 tape drive 6 Gbps SAS interface
- LTO Ultrium 6 Tape Drive Type
- 2.5TB native
- 6.25TB with 2.5:1 Compression
- 1 Number of Tape Drives
- 1 Number of Tape Cartridges
- Up to 160MBps Native Data Transfer Rate
- Read and write: LTO Ultrium 6 LTO Ultrium 5
- Read only: LTO Ultrium 4
- LTO Ultrium cleaning cartridge
- 4.3kg (9.5lbs) Weight
- 100 – 240V ac 50 – 60Hz auto-ranging Power Requirements
- 21.3cm x 5.8cm x 33.2cm (8.39in. x 2.29in. x 13.07in.)
- 3 Years Limited Warranty
Lenovo ThinkSystem DS2200 Storage Array
- SFF FC/iSCSI Dual Controller Unit Model
- Hot-Plug
- 2 x RAID Type
- 8 GB Buffer Size
- 4 Host Channels
- Rack Mountable
- Fibre Channel iSCSI
- Rack Mounting Kit
- 2M Height
- Black Color Category
- 24 Supported Devices
- Serial Attached SCSI 3
- RAID 0 RAID 1 RAID 10 RAID 5 RAID 6
- Serial Attached SCSI 3 Interface Type
- 580 Watt Power Provided
- AC 120/230 V Nominal Voltage
- 50/60 Hz Frequency Required
- 36 pin 4x Mini SAS HD (SFF-8644), RJ-45 SFP/SFP+, mini-USB Type B Connector Type
- Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel SAS 12Gb/s management serial Interface
- 16Gb Fibre Channel 8Gb Fibre Channel iSCSI (1 GbE), iSCSI (10 GbE)
- 3 Years Onsite Warranty
Lenovo IBM TS2270 Tape Drive Model H7S
- Model 6160 H7S-One LTO Ultrium 7 tape drive, 6Gbps SAS interface
- LTO Ultrium 7 Tape Drive Type
- 6TB native
- 15TB with 2. 5:1 Compression
- 1 Number of Tape Drives
- 1 Number of Tape Cartridges
- Up to 300MBps Native Data Transfer Rate
- Read and write: LTO Ultrium 7, 6TB data cartridge, LTO Ultrium 6, 2. 5TB data cartridge
- Read only: LTO Ultrium 5, 1. 5TB data cartridge
- LTO Ultrium cleaning cartridge
- 4. 3kg (9. 5lbs) Weight
- 100 – 240V ac, 50 – 60Hz auto-ranging Power Requirements
- 21. 3cm x 5. 8cm x 33. 2cm (8. 39in. x 2. 29in. x 13. 07in. )
- 3 Years Limited Warranty
Lenovo IBM TS2260 Tape Drive Model H6S
- Model 6160 H6S-One LTO Ultrium 6 tape drive, 6 Gbps SAS interface
- LTO Ultrium 6 Tape Drive Type
- 2. 5TB native
- 6. 25TB with 2. 5:1 Compression
- 1 Number of Tape Drives
- 1 Number of Tape Cartridges
- Up to 160MBps Native Data Transfer Rate
- Read and write: LTO Ultrium 6, LTO Ultrium 5
- Read only: LTO Ultrium 4
- LTO Ultrium cleaning cartridge
- 4. 3kg (9. 5lbs) Weight
- 100 – 240V ac, 50 – 60Hz auto-ranging Power Requirements
- 21. 3cm x 5. 8cm x 33. 2cm (8. 39in. x 2. 29in. x 13. 07in. )
- 3 Years Limited Warranty
Lenovo ThinkSystem DS2200 SFF FC iSCSI Dual Controller Unit Hard Drive Array
- SFF FC/iSCSI Dual Controller Unit Model
- Hot-Plug
- 2 x RAID Type
- 8 GB Buffer Size
- 4 Host Channels
- Rack Mountable
- Fibre Channel, iSCSI
- Rack Mounting Kit
- 2M Height
- Black Color Category
- 24 Supported Devices
- Serial Attached SCSI 3
- RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
- Serial Attached SCSI 3 Interface Type
- 580 Watt Power Provided
- AC 120/230 V Nominal Voltage
- 50/60 Hz Frequency Required
- 36 pin 4x Mini SAS HD (SFF-8644), RJ-45, SFP/SFP+, mini-USB Type B Connector Type
- Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel, SAS 12Gb/s, management, serial Interface
- 16Gb Fibre Channel, 8Gb Fibre Channel, iSCSI (1 GbE), iSCSI (10 GbE)
- 3 Years Onsite Warranty
Lenovo ThinkSystem DS2200 LFF FC iSCSI Dual Controller Unit Hard Drive Array
- Hard drive array
- Rack-mountable - 2U Enclosure Type
- 8Gb Fibre Channel, iSCSI (1 GbE), iSCSI (10 GbE), 16Gb Fibre Channel
- 4 Host Channels
- 3 Years Onsite Warranty
- 12 (max) Installed Devices / Modules Qty
- SAS-3 Supported Drives
- 2 x RAID (SAS 12Gb/s) - RAID 0, 1, 5, 6, 10 Storage Controller
- No HDD
- AC 120/230 V - 50/60 Hz Power
- 17. 4 in x 24. 8 in x 3. 5 in Dimensions (WxDxH)
- 70. 55 lbs Weight
- 3 Years Onsite Warranty
Lenovo ThinkSystem DS Series Dual IOM SFF Expansion Unit Storage Enclosure
- 24 Supported Devices
- 1 x USB Cable
- BSMI CNS 13438 Class A, ICES-003, EN55024, CCC, RoHS, EN 60950-1, FCC Part 15 A, GB 17625. 1, GB 9254 Class A, VCCI Class A, EAC, NMB-3 Class A, GB 4943. 1, RCM, MSIP, NOM-019, UL/CSA60950-1, CNS 14336-1, EN 55032 Class A
- Rack Mounting Kit
- Storage Enclosure Device Type
- 24 (total) / 24 (free) x hot-swap - 2. 5" SFF Expansion Bays
- 6 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644)
- 2 x internal power supply - hot-plug Power Device
- AC 120/230 V - 50/60 Hz Voltage Required
- 580 Watt Power Provided
- 3 Years On-site Warranty
Lenovo 00NV426 Rack Shelf Mounting Kit For System Storage TS2250 Tape drive
- Part Number: 00NV426
- 6160 Rack Mount Shelf Kit w/PDU Line Cord
- Rack shelf mounting kit| Designed For: IBM System Storage TS2250 Tape Drive Model H5S
- IBM System Storage TS2260 Tape Drive H6S
- IBM System Storage TS2360 Tape Drive Model S63
Lenovo 00NA009 Mini SAS Data Transfer Cable
- Part Number: 00NA009
- Product Name : 2 m Mini SAS/Mini SAS 1x Cable (host SFF-8088 to target SFF-8088)
- Product Type : Data Transfer Cable
- Device Supported : Hard Drive
- Dimensions : 29.2 x 30.5 x 3.8 cm
- Weight : 454 g
Lenovo 00WF771 Ultrium 7 Data Cartridges 5 Pack
- Part Number: 00WF771
- Product Name : Ultrium 7 Data Cartridges 5 Pack
- Product Type : Data Cartridge
- Storage Capacity : 6.25 TB
- Native Storage Capacity : 6 TB
Lenovo 00NA025 LTO Ultrium 6 Data Cartridges 5 Pack
- Part Number: 00NA025
- Product Name : Ultrium 6 Data Cartridges 5 Pack
- Product Type : Data Cartridge
- Storage Capacity : 6.25 TB
- Native Storage Capacity : 2.50 TB
Lenovo 00NA023 LTO Ultrium 5 Data Cartridges 5 Pack
- Part Number: 00NA023
- Product Name : Ultrium 5 Data Cartridges 5 Pack
- Product Type : Data Cartridge
- Storage Capacity : 1.5 TB / 3.0 TB
- Native Storage Capacity : 1.50 TB
Lenovo 00NA059 2.8m 10A 240V C13 to IS 6538 Line Cord
- Part Number: 00NA059
- Product Name : 2.8m, 10A/240V, C13 to IS 6538 (India) Line Cord
- Product Type : Standard Power Cord
- Device Supported : Drive Cabinet
- Limited Warranty : 1 Year
Lenovo IBM TS2250 Tape Drive Model H5S
- Part Number : 6160S5E
- Tape Drive Type : IBM LTO Ultrium 5
- Physical Capacity : 1.5TB Native; 3.0TB with 2:1 compression
- Weight : 4.3kg (9.5lbs)
- Limited Warranty : Three-year limited warranty, customer-replaceable unit and on-site service in most countries, next business day 9x5, service upgrades available
IBM LTO Ultrium 7 Data Cartridge
- Media type : Linear serpentine recording half inch cartridge
- Data capacity : 6 TB native Up to 15 TB with 2.5:1 data compression
- Cartridge models : LTO Ultrium 7 6 TB rewritable data cartridge
- Tape length : 960 m (3,149 ft)
- Total tape thickness : 5.6 µ (0.00022 in.)
- Data cartridge weight : 200 g (0.441 lb)
- Limited Warranty : 1 year Warranty
IBM TS4300 Tape Library
- Form factor: 3U
- Physical capacity: 12TB native capacity/up to 30TB compressed capacity (LTO8)
- 6TB native capacity/up to 15TB compressed capacity (LTO7)
- 2.5TB native capacity/up to 6.25TB compressed capacity (LTO6)
- Network interface: Ethernet
- Power supply: 1 standard power supply, optional 2nd redundant supply
- Hot-swap components: Power supplies, tape drives
- Systems management: Storage Management Initiative Specification (SMI-S) enabled
- Operating systems supported: Selected IBM servers and other Linux and Microsoft Windows open-system servers
- Limited warranty: 3-year in-warranty coverage of select parts
- Weight: Base module maximum 28kg (61.5 lb) Expansion module maximum 22.6kg (49.6 lb)
- Dimensions (H x W x D): 114mm (4.48 in.) x 446mm (17.56 in.) x 873mm (34.37 in.)
IBM TS2280 Tape Drive
- Available configuration: Model 6160-H8S—One LTO Ultrium 8 tape drive, 6Gbps SAS interface
- Tape drive type: LTO Ultrium 8
- Physical capacity: 12TB native; 30TB with 2.5:1 compression
- Number of tape drives: 1
- Number of tape cartridges: 1
- Data transfer rate: Up to 300MBps native, up to 750MBps with 2.5:1 compression
- Weight: 4.3kg
- Power requirements: 100 – 240V ac, 50 – 60Hz auto-ranging
- Dimensions (W x H x D): 213 mm x 58 mm x 332 mm (8.4 in. x 2.3 in. x 13.1 in.)
- Warranty: 3-year limited warranty, customer replaceable unit (CRU) and on-site service in most countries, next-business-day 9x5, service upgrades available
IBM TS2290 6160 H9S Tape Drive
- Tape Drive Brand: IBM
- Tape Drive Product: IBM TS2290 Tape Drive
- Tape Drive Configuration: Model 6160 H9S - LTO Ultrium 9 tape drive, 12Gbps SAS interface
- Physical capacity: 18TB native; 45TB with 2.5:1 compression
- Number of tape drives / cartridges: 1/1
- Data transfer rate: Up to 300MBps native, up to 750MBps with 2.5:1 compression
- Media type: Read and write: LTO Ultrium 9 18TB data cartridge
- Power Consumption: 100 – 240V ac, 50 – 60Hz auto-ranging
- Tape Drive Weight: 4.3kg
- Product Size(W x H x D): 213 mm x 58 mm x 332 mm (8.4 in. x 2.3 in. x 13.1 in.)
- Warranty: 3year Warranty, customer replaceable unit (CRU) and on-site
